SD750
HARDWARE AND INSTALLATION
MANUAL
LOW VOLTAGE VARIABLE SPEED DRIVE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Power Electronics SD750

Summary of Contents for Power Electronics SD750

  • Page 1 SD750 HARDWARE AND INSTALLATION MANUAL LOW VOLTAGE VARIABLE SPEED DRIVE...
  • Page 3 Variable Speed Drive Hardware and Installation Manual Edition: April 2021 SD75MTHW01II Rev. I...

  • Page 4: About This Manual

    This manual contains important instructions for the installation and maintenance of Power Electronics SD750 variable speed drives. TARGET AUDIENCE This manual is intended for qualified customers who will install, operate, and maintain Power Electronics SD750 variable speed drives. Only trained electricians may install and commission the drives.
  • Page 5 Accessories. Misprints correction. The equipment and technical documentation are periodically updated. Power Electronics reserves the right to modify all or part of the contents of this manual without previous notice. To consult the most updated information of this product, you may access our website www.power-electronics.com, where the latest version of this manual can be downloaded.

  • Page 6: Table Of Contents

    SD750 POWER ELECTRONICS TABLE OF CONTENTS ABOUT THIS MANUAL ..........................2 ACRONYMS ..............................7 SAFETY SYMBOLS ............................. 9 SAFETY INSTRUCTIONS .......................... 10 TORQUE AND SCREW SIZING ......................... 15 INTRODUCTION ........................... 16 CONFIGURATION TABLE & STANDARD RATINGS ................. 17 Configuration table ..........................17 Standard ratings ..........................
  • Page 7 Power connection and wiring ......................53 Reference cable section ........................60 Ground connection ..........................68 EMC installation requirements ......................69 Introduction ............................69 SD750 compliance........................... 70 Connection ............................70 Protections ............................71 Short circuit ............................71 Ground fault protection ........................73 Motor thermal protection ........................
  • Page 8 SD750 POWER ELECTRONICS ACCESSORIES ..........................104 Codes and description ........................104 Communication boards ........................104 Expansion boards ..........................104 Mechanical accessories ........................105 IP20 connection boxes ........................105 Plinths 105 Other accessories ..........................106 Dynamic braking unit b150 ......................106 DECLARATION OF CONFORMITY CE ....................

  • Page 9: Acronyms

    POWER ELECTRONICS SD750 ACRONYMS The terms commonly used in the documentation of Power Electronics’ products are listed in the table below. Please notice this is a general series of terms and it encompasses all our product divisions (industrial, solar, storage, and electric mobility), thus, some of the following expressions may not apply to this particular manual.
  • Page 10 SD750 POWER ELECTRONICS ACRONYM MEANING Residual Current Device Residual Current Monitor RFID Radio Frequency Identification State Of Charge – referred to battery State Of Health – referred to battery. It compares the actual state of the battery to its initial conditions.

  • Page 11: Safety Symbols

    POWER ELECTRONICS SD750 SAFETY SYMBOLS Always follow safety instructions to prevent accidents and potential hazards from occurring. In this manual, safety messages are classified as follows: Identifies potentially hazardous situations where dangerous voltage may be present, which if not avoided, could result in minor personal injury, serious injury or death.

  • Page 12: Safety Instructions

    In order to appropriately use the drive, please, follow all instructions described in the installation manual which refer to transportation, installation, electrical connection, and commissioning of the equipment. Power Electronics accepts no responsibility or liability for partial or total damages resulting from incorrect use of equipment.
  • Page 13 POWER ELECTRONICS SD750 WARNING Both wiring and periodic inspections must be carried out at least 10 minutes after disconnecting the input power. To remove the front cover, make sure that the red "DC Link" LED is off. Then remove the metal cover from the terminals and check the following with a multimeter: •...
  • Page 14 These WEEEs should be managed accordingly with a Hazardous Waste Agent. Power Electronics promotes good environmental practices and recommends that all its products sold outside of the European Union, once they reach the end of their life, are separated and the WEEE managed according to the particular country applicable legislation (especially: electronic cards, capacitors, and other electronic devices).
  • Page 15 SAFETY • Before operating the drive, read this manual thoroughly to gain an understanding of the unit. If any doubt exists, please contact POWER ELECTRONICS, (902 40 20 70 / +34 96 136 65 57) or your nearest agent. •...
  • Page 16 Power Electronics and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information.

  • Page 17: Torque And Screw Sizing

    Screwing should be tightened correctly only when necessary, i.e. when the factory marks are not in place. For small screws that do not have marks, the good electrical praxis will determine if it is loose. Power Electronics recommends the use of Zinc Steel quality 8.8 bolts for internal connections in general, DC and earth connections included.

  • Page 18: Introduction

    With a built-in energy efficiency calculator, the SD750 series will help you to monitor, analyze and optimize your processes for energy saving and to contribute to the digital transformation of your industry into a “Smart Industry”.

  • Page 19: Configuration Table & Standard Ratings

    CONFIGURATION TABLE & STANDARD RATINGS Configuration table To consult the configuration table of SD750 drives manufactured by Power Electronics, please refer to the latest brochure (visit http://www.power-electronics.com). Standard ratings Voltages in the standard ratings shown in the following tables are the three-phase input voltages for the drive.

  • Page 20: 400Vac

    1250 1580 2370 SD75S2250 5BCDE 1200 1750 2250 1000 1450 1800 2700 SD75S2750 5BCDE 1500 2200 2750 1200 1750 2200 3300 SD75S3100 5BCDE 1750 2450 3100 1400 2000 2500 3750 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 21: 440Vac

    1250 1436 2155 SD75S2250 5BCDE 1200 1750 2045 1000 1450 1636 2455 SD75S2750 5BCDE 1500 2200 2500 1200 1750 2000 3000 SD75S3100 5BCDE 1750 2450 2818 1400 2000 2273 3409 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 22: 480Vac

    1250 1317 1975 SD75S2250 5BCDE 1200 1750 1875 1000 1450 1500 2250 SD75S2750 5BCDE 1500 2200 2292 1200 1750 1833 2750 SD75S3100 5BCDE 1750 2450 2583 1400 2000 2083 3125 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 23: 525Vac

    1500 1420 2130 SD75S1850 6BCDE 1400 1800 1850 1250 1700 1500 2250 SD75S2200 6BCDE 1600 2100 2200 1400 1800 1800 2700 SD75S2500 6BCDE 1800 2400 2500 1600 2100 2000 3000 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 24: 600Vac

    1700 1420 2130 SD75S1850 6BCDE 1600 2200 1850 1500 2000 1500 2250 SD75S2200 6BCDE 1900 2500 2200 1600 2200 1800 2700 SD75S2500 6BCDE 2200 2900 2500 1900 2500 2000 3000 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 25: 690Vac

    2000 1420 2130 SD75S1850 6BCDE 1800 2400 1850 1700 2200 1500 2250 SD75S2200 6BCDE 2100 2750 2200 1800 2400 1800 2700 SD75S2500 6BCDE 2200 3000 2500 2100 2750 2000 3000 Consult availability with Power Electronics. CONFIGURATION TABLE & STANDARD RATINGS...

  • Page 26: Technical Characteristics

    [2]: For operation frequencies higher than 100Hz consult Power Electronics. [3]: Valid for frames 3 to 11, depending on the SD750 rated power. Optional filter available for frames 1 and 2. [4]: SC: Shielded cable, USC: Unshielded Cable. Follow Power Electronics installation recommendations. For greater cable lengths, consult Power Electronics.
  • Page 27 POWER ELECTRONICS SD750 SD750S SERIES DIGITAL INPUTS 6 programmable, Active high (24Vdc). Isolated power supply DIGITAL OUTPUTS 3 programmable changeover relays (250Vac, 8A or 30Vdc, 8A) 3 programmable differential inputs: 0 – 20mA, 4 – 20mA, 0 – 10Vdc and ±10Vdc, PT100...
  • Page 28 SD750 POWER ELECTRONICS SD750S SERIES CERTIFICATIONS CE, cTick, UL, cUL, Marine certifications (under request) EMC Directive (2004/108/CE) ELECTROMAGNETIC COMPATIBILITY IEC/EN 61800-3 LVD Directive (2006/95/CE) REGULATIONS IEC/EN 61800-2 General requirements DESIGN AND CONSTRUCTION IEC/EN 61800-5-1 Safety IEC/EN 60146-1-1 Semiconductors IEC 60068-2-6 – Vibration...

  • Page 29: Dimensions

    POWER ELECTRONICS SD750 DIMENSIONS NOTICE Consult drives input supply voltage in section TECHNICAL CHARACTERISTICS. Dimensions of frame 1 DIMENSIONS (mm) WEIGHT (kg) 497,6 16,7 DIMENSIONS...

  • Page 30: Dimensions Of Frame 2

    SD750 POWER ELECTRONICS Dimensions of frame 2 DIMENSIONS (mm) WEIGHT (kg) 474,3 212,4 DIMENSIONS...

  • Page 31: Dimensions Of Frame 3

    POWER ELECTRONICS SD750 Dimensions of frame 3 DIMENSIONS (mm) WEIGHT (kg) Φ 27,6 838,5 827,2 11,4 61,2 DIMENSIONS...

  • Page 32: Dimensions Of Frame 4

    SD750 POWER ELECTRONICS Dimensions of frame 4 DIMENSIONS (mm) WEIGHT (kg) 1251 464,5 85,05 DIMENSIONS...

  • Page 33: Dimensions Of Frame 5

    POWER ELECTRONICS SD750 Dimensions of frame 5 DIMENSIONS (mm) WEIGHT (kg) 1715 168,25 DIMENSIONS...

  • Page 34: Dimensions Of Frame 6

    SD750 POWER ELECTRONICS Dimensions of frame 6 DIMENSIONS (mm) WEIGHT (kg) 1715 286,52 DIMENSIONS...

  • Page 35: Dimensions Of Frame 7

    POWER ELECTRONICS SD750 Dimensions of frame 7 DIMENSIONS (mm) WEIGHT (kg) 1667,4 1715 1132 1096 1220 1602 441,3 DIMENSIONS...

  • Page 36: Dimensions Of Frame 8

    SD750 POWER ELECTRONICS Dimensions of frame 8 DIMENSIONS (mm) WEIGHT (kg) 1667 1715 1482 1220 1602 576,37 DIMENSIONS...

  • Page 37: Dimensions Of Frame 9, 10 And 11

    Dimensions of frame 9, 10 and 11 Frames 9 to 11 of SD750 are made up of several modules of smaller frames, depending on the power required by the customer. Therefore, the overall dimensions of the equipment will vary according to the number of modules and their size.

  • Page 38: 525Vac - 690Vac

    SD750 POWER ELECTRONICS 525Vac – 690Vac BASE MODEL CODE TOTAL WIDTH Nº PULSES FRAME CODE COMBINATION (INDIVIDUAL EQUIPMENT) SD750680 6BDEF 1 x T8 SD75S0680 6 1482 SD750825 6BDEF 1 x T8 SD75S0825 6 1482 SD750930 6BDEF 2 x T7 SD75S0570 6...
  • Page 39 POWER ELECTRONICS SD750 Below are two configuration examples and their dimensions. Example 1 SD750 frame 9 composed of two modules of frame 7. DIMENSIONS (mm) 1666,4 2274 1132 DIMENSIONS...
  • Page 40 SD750 POWER ELECTRONICS Example 2 SD750 frame 11 composed of two modules of frame 8. DIMENSIONS (mm) 1667 5958 1482 DIMENSIONS...

  • Page 41: Reception, Handling And Transportation

    Otherwise, the equipment can be damaged and lead to personal injury. Reception Power Electronics’ equipment are carefully tested and packed for shipment. In the event of damage to the unit during transportation notify the transport agency and Power Electronics: 902 40 20 70 (International +34 96 136 65 57) or your nearest agent, within 24h from receipt of the goods.

  • Page 42: Extended Storage

    SD750 is delivered vertically. Frames 1 and 2 are delivered in a cardboard box. From frame 3 they are delivered fastened to a wooden pallet. Frames 3 and 4 are covered with a cardboard box and from frames 5 with a wooden box.
  • Page 43 In case of doubt about how to manipulate and transport equipment composed by several modules, consult Power Electronics. RECEPTION, HANDLING AND TRANSPORTATION...
  • Page 44 SD750 POWER ELECTRONICS Lifting and transporting the equipment RECEPTION, HANDLING AND TRANSPORTATION...

  • Page 45: Mechanical Installation

    Environmental ratings Power Electronics recommends following the instructions in this manual carefully to ensure a correct operation of the drive. The installer is responsible for performing a proper installation in order to comply with the ambient conditions of the VFD. In addition, the installer is solely responsible for complying with the local regulations.

  • Page 46: Drive Mounting

    Do not fully tighten bolts yet. Mount the unit with the top two bolts and then fully tighten the mounting bolts. Make sure the SD750 is flat on the mounting surface.

  • Page 47: Stand Alone Drives

    The walls adjoining the drive must be of a non-flammable material. Attach the SD750 to the wall or floor using the L brackets on both sides of the drive. The brackets have Ø11 hole diameters and are located on the legs and rear.

  • Page 48: Clearances

    SD750 POWER ELECTRONICS Clearances If the equipment is installed inside a cabinet, ensure that the hot air expelled from the VFD is evacuated outside. This hot air could be sucked back and cause the drive to overheat. To ensure proper ventilation avoid air recirculation and maintain the minimum clearances indicated below.
  • Page 49 SD750 In case of drives frame 9 to 11, they must be installed side-to-side and following the minimum distances between modules (values in mm). Minimum clearances between modules, SD750 frame 9 to 11 REF. DESCRIPCIÓN Minimum distance necessary to open both doors at the same time.

  • Page 50: Cooling

    The main heat sources inside the equipment correspond to: losses in the bridge rectifier (IGBTs), the input filter and the output dV/dt filter. The SD750 series has an overall efficiency higher than 98%, so losses due to heat dissipation correspond to 2% of the power supplied by the equipment.
  • Page 51 0.122 Heat dissipation The heat generated by the SD750 depends on the carrier frequency (Hz), the grid frequency and the load. It can be estimated by the following equation, considering the worst case at rated power condition. [W] = 0,02 · P...

  • Page 52: Power Connection

    Read and understand this manual thoroughly before performing any operations. Use a power supply according to the selected drive. AC Power The SD750 drives are available for TN, TT Supply or IT grids (floating earth). Check the serial number to ensure the correct drive selection.

  • Page 53: Topology

    The SD750 drive includes a power and a control board that are responsible for the rectifier bridge trip, inverter bridge trip, soft load management, DC bus voltage control and motor operation. In addition, the control card integrates terminals such as communication ports, digital and analogue inputs and outputs, colour touch-screen display, alphanumeric display, etc.
  • Page 54 SD750 POWER ELECTRONICS The following schemes illustrate the SD750 internal power structure. SD750 frames 1 and 2 power electronics. SD750 frames 3 and 4 power electronics SD750 frames 5 to 11 power electronics POWER CONNECTION...

  • Page 55: Power Connection And Wiring

    POWER ELECTRONICS SD750 Power connection and wiring CAUTION The following installation recommendations are suitable for TN and TT grids. For IT grids refer the dedicated section. Otherwise, you could cause damage to equipment and personnel. Wiring and periodic inspections should be performed at least 10 minutes after disconnecting the input power.
  • Page 56 SD750 POWER ELECTRONICS In the case of frames 9 to 11, power connections must be made as shown in the following diagrams. Power wiring connection for variable speed drives composed of two modules Power wiring connection for variable speed drives composed of three modules...
  • Page 57 POWER ELECTRONICS SD750 Power wiring connection for variable speed drives composed of four modules NOTICE To perform the fiber optic connections between modules, refer to the manual of the fiber optic board (SD75MA07). POWER CONNECTION...
  • Page 58 SD750 POWER ELECTRONICS The input terminals L1, L2, L3 and PE (drive power supply), output terminals U, V, W and PE (motor power supply) must be introduced through the metal plates situated in the bottom part of the cabinet. Do not drill or mechanize the vents.
  • Page 59 POWER ELECTRONICS SD750 The following figures show the recommended cable type and bundling. Recommended cable type and bundling NOTICE The number of three phase plus neutral cable hose (U, V, W, PE) to the motor should be equal to the number of IGBTs in the drive, having one 4-wire cable hose by each IGBTs block.
  • Page 60 SD750 POWER ELECTRONICS Recommended cable bundling scheme CAUTION Line voltage (input supply) must never be connected to U, V and W terminals. Otherwise, the drive may get be damaged. It is absolutely necessary that the installer ensures correct compliance with the laws and regulations in force in the countries or areas where the drive is to be installed.
  • Page 61 POWER ELECTRONICS SD750 Cable routing distances Power Electronics recommends installing separately the following circuits, whether in cable racks, trays or in different wire ducts: • Single-wire signal or data cables with V< 60V • Single-wire cables with 60V<V< 230V •...

  • Page 62: Reference Cable Section

    “Power terminals”. The following tables show the reference cable section for each SD750 frame, based on the internal drive sections. The installer must consider the cable cross-section, cable type, wiring method and ambient conditions to select the appropriate cable to be installed between the drive and the motor.
  • Page 63 POWER ELECTRONICS SD750 400Vac – multipulses (12, 18 and 24) I(A) I (A) Reference cable Nº Reference cable FRAME CODE section for ground rated maximum PULSES section (mm²) at 40ºC at 40ºC cable (mm²) SD751550 5BCDE 1550 1890 2x(3x(3x240)) 3x240...
  • Page 64 SD750 POWER ELECTRONICS 440Vac – 6 pulses I(A) I (A) Reference cable Reference cable FRAME CODE rated maximum section for ground section (mm²) at 40ºC at 40ºC cable (mm²) SD75S0006 5BCDE 3x(1x6) SD75S0008 5BCDE 3x(1x6) SD75S0011 5BCDE 3x(1x6) SD75S0015 5BCDE...
  • Page 65 POWER ELECTRONICS SD750 480Vac – 6 pulses I(A) I (A) Reference cable FRAM Reference cable CODE rated maximum section for ground section (mm²) at 40ºC at 40ºC cable (mm²) SD75S0006 5BCDE 3x(1x6) SD75S0008 5BCDE 3x(1x6) SD75S0011 5BCDE 3x(1x6) SD75S0015 5BCDE...
  • Page 66 1710 2x(3x(3x240)) 3x240 SD75S1550 6BCDE 1550 1905 3x(3x(2x240)) 2x240 SD75S1750 6BCDE 1750 2130 3x(3x(2x240)) 2x240 SD75S1850 6BCDE 1850 2250 3x(3x(2x240)) 2x240 SD75S2200 6BCDE 2200 2700 3x(3x(3x240)) 3x240 SD75S2500 6BCDE 2500 3000 4x(3x(2x240)) 2x240 Consult availability with Power Electronics. POWER CONNECTION...
  • Page 67 1260 2x(3x(2x240)) 2x240 SD75S1200 6BCDE 1200 1425 2x(3x(2x240)) 2x240 SD75S1400 6BCDE 1400 1710 2x(3x(3x240)) 3x240 SD75S1550 6BCDE 1550 1905 3x(3x(2x240)) 2x240 SD75S1750 6BCDE 1750 2130 3x(3x(2x240)) 2x240 SD75S1850 6BCDE 1850 2250 3x(3x(2x240)) 2x240 Consult availability with Power Electronics. POWER CONNECTION...
  • Page 68 1710 2x(3x(3x240)) 3x240 SD75S1550 6BCDE 1550 1905 3x(3x(2x240)) 2x240 SD75S1750 6BCDE 1750 2130 3x(3x(2x240)) 2x240 SD75S1850 6BCDE 1850 2250 3x(3x(2x240)) 2x240 SD75S2200 6BCDE 2200 2700 3x(3x(3x240)) 3x240 SD75S2500 6BCDE 2500 3000 4x(3x(2x240)) 2x240 Consult availability with Power Electronics. POWER CONNECTION...
  • Page 69 POWER ELECTRONICS SD750 690Vac – multipulses (12, 18 and 24) I(A) I (A) Reference cable Nº Reference cable FRAME CODE section for ground rated maximum PULSES section (mm²) at 40ºC at 40ºC cable (mm²) SD75S0930 6BCDE 1125 2x(3x(2x240)) 2x240 SD75S1050 6BCDE...

  • Page 70: Ground Connection

    SD750 POWER ELECTRONICS Ground connection Before connecting the power conductors, make sure that the chassis of the drive and the adjoining cabinets are connected to ground through the dedicated (PE) terminals. These are situated at both sides of the bottom metal walls of the drive and they are labeled with the earth symbol. Check section “Power Terminals”.

  • Page 71: Emc Installation Requirements

    POWER ELECTRONICS SD750 EMC installation requirements Introduction The EMC European Directive defines electromagnetic compatibility as the capability of an apparatus, an industrial plant, or a system to work satisfactorily in the electromagnetic environment without at the same time causing electromagnetic disturbances in the apparatus, industrial plant or systems present in the same environment.

  • Page 72: Sd750 Compliance

    Environment) by employing optional RFI filters that permit to achieve the C2 category. The SD750 is not a retail unit. It is neither a plug in device nor a movable device and it is intended to be installed and commissioned by qualified personnel. Therefore, C1 category will not be required.

  • Page 73: Protections

    Protections Short circuit The SD750 includes from frame 5 to 11 ultra-fast input protection fuses as standard. Frame 5 includes one fuse per phase with a rated current that depends on the drive’s nominal current. From frame 6 upwards, the fuses per phase depend on the number of modules (frame 5) interconnected. The main characteristics of these fuses are shown in the following table.
  • Page 74 SD750 POWER ELECTRONICS 380-500Vac FUSES PER PHASE FRAME CODE (In) SD75S0320 5BCDE 1x350A SD75S0400 5BCDE 1x450A SD75S0450 5BCDE 2x350A SD75S0570 5BCDE 2x350A SD75S0700 5BCDE 2x450A SD75S0800 5BCDE 3x350A SD75S0900 5BCDE 3x350A SD75S1050 5BCDE 3x450A SD75S1140 5BCDE 4x350A SD75S1400 5BCDE 4x450A...

  • Page 75: Ground Fault Protection

    The SD750 drives are suitable to operate with RCD components Type B, if it is required. The EMC / EMC filters and motor cable lengths increase the earth leakage currents, so the protection range is set according to the installation conditions.

  • Page 76: Dynamic Braking Resistors For Equipment Of Frames 1 And 2

    SD750 POWER ELECTRONICS Dynamic braking resistors for equipment of Frames 1 and 2 Frames 1 and 2 equipment include the built-in dynamic brake as standard. The user should only connect a resistor between terminals +HVDC and B as the following drawing shows.

  • Page 77: Terminals Of The Resistor For Dynamic Brake

    • The maximum cable length between the drive and the external braking resistor is 20m. For other configurations, contact Power Electronics. CAUTION Do not touch the braking resistor during drive operation. It can reach T > 150ºC. If you omit this precaution, there is a high risk of burns and / or abrasion.

  • Page 78: Power Terminals

    SD750 POWER ELECTRONICS Power terminals The following figures show the location of power terminals for each frame of SD750. Connections for frame 1 POWER CONNECTION...

  • Page 79: Connections For Frame 2

    POWER ELECTRONICS SD750 Connections for frame 2 POWER CONNECTION...

  • Page 80: Connections For Frame 3

    SD750 POWER ELECTRONICS Connections for frame 3 DRILL DIAMETER SCREW (mm) METRIC POWER CONNECTION...

  • Page 81: Connections For Frame 4

    POWER ELECTRONICS SD750 Connections for frame 4 DRILL DIAMETER SCREW (mm) METRIC POWER CONNECTION...

  • Page 82: Connections For Frame 5

    SD750 POWER ELECTRONICS Connections for frame 5 DRILL DIAMETER SCREW (mm) METRIC POWER CONNECTION...

  • Page 83: Connections For Frame 6

    POWER ELECTRONICS SD750 Connections for frame 6 DRILL DIAMETER SCREW (mm) METRIC POWER CONNECTION...

  • Page 84: Connections For Frame 7

    SD750 POWER ELECTRONICS Connections for frame 7 DRILL DIAMETER SCREW (mm) METRIC POWER CONNECTION...

  • Page 85: Connections For Frame 8

    POWER ELECTRONICS SD750 Connections for frame 8 DRILL DIAMETER SCREW (mm) METRIC Connections for frame 9, 10 and 11 For the location of the connection plates consult the connection diagrams of frames 6, 7 and 8 as appropriate. POWER CONNECTION...

  • Page 86: Control Connection

    SD750 POWER ELECTRONICS CONTROL CONNECTION Wiring recommendations Before planning the installation, follow and understand the next recommendations. The parallel cable routing should be avoided and the distance between the control wiring and the power wiring should be maximized. It is recommended to route control cables with different voltages in separately cable racks, trays or ducts.

  • Page 87: Control Board Terminals Description

    POWER ELECTRONICS SD750 Control board terminals description CAUTION Any changes to the control board wiring or bridges must be performed at least 10 minutes after disconnecting the input power and after checking the bus voltage (DC Link) is discharged below 30VDC.
  • Page 88 SD750 POWER ELECTRONICS The following figure provides a standard wiring overview of the control terminals. Example of control terminals standard wiring Digital inputs can be configured individually or collectively. Analogue inputs can be configured as comparators. For further information on configurations, please refer to the Software and Programming Manual.
  • Page 89 POWER ELECTRONICS SD750 SEÑAL DESCRIPCIÓN +24Vdc Power supply 24Vdc control card. GND control board. STO 1 Safety input STO 1. TEST 1 Safety common input STO 1. STO 2 Safety input STO 2. TEST 2 Safety common input STO 2.
  • Page 90 SD750 POWER ELECTRONICS It is recommended to use double shielded twisted-pair cable for 24Vdc power supply and safety channels. The shield must be grounded as shown in the examples. When a PNP or NPN input is configured, the rest of digital inputs will have to be the same. This means, PNP and NPN inputs cannot coexist.
  • Page 91 POWER ELECTRONICS SD750 DI6 (PIN13) PTC sensor input mode. It is possible to connect a PTC sensor in the digital input 6 (DI6) so that the equipment acts from a temperature (resistance) value associated to motor’s temperature and to allow enabling cooling or stop motor running.
  • Page 92 SD750 POWER ELECTRONICS AI3 (PIN 21/22) PT100 mode. The AI3 allows configuring a PT100 sensor. With this sensor, motor temperature can be measured continuously. Ground cable screening must be connected only in one end. For further information about parameter configuration, consult the Software and Programming Manual.

  • Page 93: Sto - Safe Torque Off

    STO function is applied, the motor will freely stop by its own inertia. The STO function integrated as standard in the SD750 permits to achieve safety level SIL3 (PLe) for the safe stop function. SIL3 requires the use of an emergency pushbutton The maximum reaction time of STO function is less than 50ms.
  • Page 94 SD750 POWER ELECTRONICS Example 1- Emergency stop push button CAUTION According to EN 60204-1 automatic restart is not allowed after an emergency stop. For this reason, the machine control must prevent an automatic start after an emergency stop. For SIL 3 applications the safety function has to be tested regularly (approximately once per month) in order to detect certain failures.
  • Page 95 POWER ELECTRONICS SD750 Example 2: SIL3 (PLe) Safety door opening for maintenance tasks with manual restart. This function is used to prevent an unexpected restart when a maintenance task is being carried out in a risk area. In this case, the relay’s safety inputs will be connected to a safety interlock switch placed in the door.

  • Page 96: Connection With Atex Motors

    Power Electronics provides a solution for driving ATEX motors such as “Ex nA”, “Ex d” and “Ex p” under the ATEX zone areas illustrated below. For different motor and ATEX zone combinations, consult Power Electronics.
  • Page 97 SD750 As shown in the figure above, the SD750 drive and the ATEX relay must be installed in a safe zone, outside the ATEX zone. This solution is valid for motors with "Ex d" or "Ex p" protection installed in zones 1 and 2, or motors with "EX nA"...

  • Page 98: Modbus Communication

    The purpose of the Serial Communication Bus of the SD750 drive is to integrate the drive itself into a network compatible with the Modbus communications protocol. This is possible using the physical communications ports RS485, Ethernet or USB port.

  • Page 99: Hardware Technical Specifications

    Note: For the installation of the driver in the Host of the SD750 USB, it is only necessary to indicate the driver at the time of the installation. The USB device will be detected by the operating systems XP or later versions. In case of operating systems before W98 / Me, execute a search of new Hardware in the device administrator and complete the installation by indicating the drivers when the computer requires them.

  • Page 100: Ethernet Connection

    SD750 POWER ELECTRONICS Ethernet connection The following diagram shows the common wiring for an Ethernet connection: Ethernet Connection To configure the connection, it is necessary to define the port and default IP address, among others. Refer to the Software and Programming Manual.
  • Page 101 POWER ELECTRONICS SD750 It is recommended to connect the jumper “RS485 USER” at the first and the last device of the RS485 communication network, to connect the end of line resistor. To configure the connection, it is necessary to define the port and default IP address, among others.

  • Page 102: Commissioning

    SD750 POWER ELECTRONICS COMMISSIONING CAUTION Only qualified personnel are allowed to commission the drive. Read carefully and follow the safety instructions of this manual. Failure to do so may result in damage to the equipment and you may suffer an electric shock.
  • Page 103 POWER ELECTRONICS SD750 Verify the configuration of the control modes and the settings (external power supply is required). Connect input power supply. Verify that the display is turned on and check the control parameters (For further information, refer to the Software and Programming Manual).

  • Page 104: Use Of The Display

    POWER ELECTRONICS USE OF THE DISPLAY The SD750 drive has two types of screens, a monochrome graphics and an optional, tactile and color. Both screens provide intuitive data presentation, easy navigation through the control parameters and allow thousands of customized configurations to be stored by the user.

  • Page 105: Maintenance

    SD750 MAINTENANCE The SD750 Series drives are industrial electronic products that contain advanced semiconductor elements. For this reason, temperature, humidity, vibrations and worn components can affect performance. To avoid any possible irregularities, it is recommended to carry out periodic inspections.

  • Page 106: Accessories

    Profinet, Modbus TCP, Ethernet IP, CAN Open, Field Bus, etc.), thanks to its optional boards. Refer to the specific manual of each board for further information. Expansion boards SD750 series is compatible with the most commonly used communication protocols (Profibus, Profinet, Ethernet I/P, CanOPEN...), thanks to its optional boards. ACCESSORIES...

  • Page 107: Mechanical Accessories

    Dimensions of the connection box Plinths SD750 frames 5 and up are stand-alone drives. They can be equipped with optional plinths to attain 2000mm or 2200mm total height. A stand-alone plinth for frame 4 attaining total height of 1712mm is also available.

  • Page 108: Other Accessories

    Other accessories Dynamic braking unit b150 The Dynamic brake permits to control the regenerated energy for series SD750 (integrated in frames 1 and 2). B150 dynamic brake activates an IGBT to discharge the DC bus with external resistors when the DC voltage overpasses a pre-set value. This activation signal can also be sent by the drive in slave mode from the common fiber optic port included in the control board.

  • Page 109: Declaration Of Conformity Ce

    DECLARATION OF CONFORMITY CE DECLARACIÓN DE CONFORMIDAD CE The Company La empresa POWER ELECTRONICS ESPAÑA, S.L. Name Nombre: Address C/ Leonardo Da Vinci, 24-26, 46980 Paterna, Valencia, Spain Dirección: Telephone +34 96 136 65 57 Teléfono: Fax: +34 96 131 82 01...
  • Page 112 24H TECHNICAL ASSISTANCE 365 DAYS A YEAR FIND YOUR NEAREST DELEGATION POWER-ELECTRONICS.COM/CONTACT/...
