Memory - Fujitsu PRIMEQUEST 3800E2 System Configuration Manual

FUJITSU Server PRIMEQUEST 3800E2

5.Memory

PSU#0
PSU#1 PSU#2
SB #0
SB #1
CPU CPU
Memory
Memory
x12 slots x12 slots
I/O Unit #0
I/O Unit
#1
PCI Slots
x4
LAN
port
Disk Unit #0
HDD/SSD
RAID
Card
FBU
Disk
Disk Unit_M #0
Unit_M
#1
HDD/SSD
RAID
Card
FBU
PSU_M
MMB #0 MMB #1
PSU#3
SB #3
SB #2
I/O Unit
I/O Unit
#3
#2
Disk Unit #1
Disk
Disk
Unit_M Unit_M
#2 #3
PSU_M
#0 #1
- At least one set of memory (2 DIMMs) must be installed for each CPU.
- Max 6 sets of memory (12 DIMMs) can be installed for each CPU.
32GB Memory (16GB 1Rx4 DDR4 RDIMM x2)
MC-3CE611 / MCX3CE611 (LD)
64GB Memory (32GB 2Rx4 DDR4 RDIMM x2)
MC-3CE711 / MCX3CE711 (LD)
128GB Memory (64GB 2Rx4 DDR4 RDIMM x2)
MC-3CE811 / MCX3CE811 (LD)
128GB Memory (64GB 4Rx4 DDR4 LRDIMM x2)
MC-3CE821 / MCX3CE821 (LD)
256GB Memory (128GB 8Rx4 DDR4 LRDIMM 3DS x2)
MC-3CE911 / MCX3CE911 (LD)
512GB Memory (256GB 8Rx4 DDR4 LRDIMM 3DS x2)
MC-3CEA11 / MCX3CEA11 (LD)
* 256GB 8R LRDIMM can not be installed on a CPU with a
memory limit of 1TB.
128GB DDR-T DCPMM(NVM/LRDIMM)
Special Release
256GB DDR-T DCPMM(NVM/LRDIMM)
Special Release
512GB DDR-T DCPMM(NVM/LRDIMM)
Special Release
If configuration of PRIMEQUEST3800E2 includes a DCPMM, it is
necessary to check validity of DCPMM installation.
For request of configuration check, please submit request to the
contact point for PRIMEQUEST.
Memory Mounting
9 of 42
System Configuration Guide
July 2019, Ver.2.0
