FUJITSU Server PRIMEQUEST 3800E2
3.System Board (SB)
I/O Unit #0
Disk Unit #1
Disk Unit #0
Disk Unit_M #0
1x System Board is included in the Base Unit.
Max. 4x System Board can be mounted per Base Unit.
MC-3HSBD1 / MCX3HSBD1 (LD)
- Min. 1 x SB needs to be mounted. Max. 4 x SB can be mounted per Base Unit.
- The System Board does not include a security chip called TPM.
- Neither CPU nor memory module is included. CPU and memory need to be ordered separately.
Min. 2 x CPU and 2 x memory module need to be mounted on each System Board.
Max. 12 x memory modules (24 x DIMMs) can be mounted.
The following opitions can be installed only in System Board #0.
eLCM Activation License (no load)
MC-6KMA11 / MCX6KMA11 (LD)
- For PRIMEQUEST 3800E2
- One License per system
The following functions are NOT available for the System Board with TPM.
- Reserved SB
TPM module V2.0
MC-6HTP31 / MCX6HTP31(LD)
- Available except for China
- One for System Board
USB Flash Device & M.2 Flash Device
5 of 42
System Configuration Guide
July 2019, Ver.2.0
