4.CPU

PSU#0 PSU#1 PSU#2
SB #0
SB #1
CPU CPU
Memory Memory
x12 slots
x12 slots
I/O Unit #0
I/O Unit
#1
PCI Slots
x4
LAN
port
Disk Unit #0
HDD/SSD
RAID
Card
FBU
Disk Unit_M #0 Disk
Unit_M
#1
HDD/SSD
RAID
Card
FBU
MMB #0 MMB #1
CPU mounting condition
# of SBs in one PPAR # of CPUs in one PPAR
1SB
2SB
3SB
4SB
- 1 CPU/SB can be configured PPAR that has 1SB only.
1CPU/PPAR can be connected IOU0 and/or IOU1 only.
- Only the same kind of CPU can be installed in the partition.
- Different types of CPUs can be installed in the different partitions.
PSU#3
SB #2 SB #3
I/O Unit
I/O Unit
#3
#2
Disk Unit #1
Disk
Disk
Unit_M Unit_M
#3
#2
PSU_M PSU_M
#0 #1
1 or 2
4
6
8
- 2x CPUs required for one System board except PPAR with 1SB.
- Combinatios of PPAR is only "SB#0 and SB#1" or "SB#2 and SB#3"
when Gold 62xx is mounted on SB.
- Can not mix different CPUs in one partition.
- CPUs with number 'xxxxL' support up to 4.5TB of memory.
CPUs with number 'xxxxM' support up to 2TB of memory.
Intel Xeon Platinum 8280L Processor (28C/2.7GHz/4.5TB/205W)
MC-3BJA41 / MCX3BJA41 (LD)
Intel Xeon Platinum 8280M Processor (28C/2.7GHz/2TB/205W)
MC-3BJA21 / MCX3BJA21 (LD)
Intel Xeon Platinum 8280 Processor (28C/2.7GHz/1TB/205W)
MC-3BJA11 / MCX3BJA11 (LD)
Intel Xeon Platinum 8276L Processor (28C/2.2GHz/4.5TB/165W)
MC-3BKA41 / MCX3BKA41 (LD)
Intel Xeon Platinum 8276M Processor (28C/2.2GHz/2TB/165W)
MC-3BKA21 / MCX3BKA21 (LD)
Intel Xeon Platinum 8276 Processor (28C/2.2GHz/1TB/165W)
MC-3BKA11 / MCX3BKA11 (LD)
Intel Xeon Platinum 8270 Processor (26C/2.7GHz/1TB/205W)
MC-3BKB11 / MCX3BKB11 (LD)
Intel Xeon Platinum 8268 Processor (24C/2.9GHz/1TB/205W)
MC-3BJC11 / MCX3BJC11 (LD)
Intel Xeon Platinum 8260L Processor (24C/2.4GHz/4.5TB/165W)
MC-3BKC41 / MCX3BKC41 (LD)
Intel Xeon Platinum 8260M Processor (24C/2.4GHz/2TB/165W)
MC-3BKC21 / MCX3BKC21 (LD)
Intel Xeon Platinum 8260 Processor (24C/2.4GHz/1TB/165W)
MC-3BKC11 / MCX3BKC11 (LD)
Intel Xeon Platinum 8253 Processor (16C/2.2GHz/1TB/125W)
MC-3BKG11 / MCX3BKG11 (LD)
Intel Xeon Platinum 8256 Processor (4C/3.8GHz/1TB/105W)
MC-3BKN11 / MCX3BKN11 (LD)
CPU(2)
7 of 42
System Configuration Guide
July 2019, Ver.2.0
*(
Number of cores / Frequency / Max. memory per CPU / TDP
)
