Chassis Preparation; Section 5: Chassis Preparation - Mojotone Tweed Champ Manual

SECTION 5:

Chassis preparation

PLEASE NOTE:
ALL PARTS LISTED IN THE CHASSIS PREP SECTION STARTS AT ONE END OF
THE CHASSIS AND COMPLETES ON THE OPPOSITE END, BOTH TOP AND BOTTOM.
Mount the power transformer
using its pre-assembled hardware and
your 1/2" nut driver. The transformer
will be recessed
rectangular cutout in the "belly" of the
chassis.
Install rubber grommets
output transformer leads.
Mount the output transformer
using the (2) 8-32 x 1⁄4" screws and
corresponding keps nuts onto the
outside of the chassis next to the power
transformer (output transformer is not
recessed). Install the transformer so that
Red Blue
the and
the grommet closest to the power
transformer. The
the grommet furthest from the power
transformer. The screws will go through
the outside of the chassis, and the nuts
will be installed in the inside. Use a
screwdriver and adjustable wrench to
tighten.
1 AMP
FUSE
6
FLATTENED VIEW OF INSIDE OF CHASSIS
through the
POWER TRANSFORMER
in holes for
wires go through
wire goes through
1
FUSE INDICATOR
HOLDER LAMP
POTENTIOMETER
OCTAL TUBE SOCKETS
6
5
7
4
8
3
2 1
GROUND
LUG
5Y3
Mount the fuse holder
assembled hardware and adjustable wrench.
Install fuse.
Solder the two 100Ω resistors on the
indicator lamp
assembled hardware and adjustable wrench.
2
BUILD. MODIFY. REPAIR.
INPUT JACKS
RUBBER GROMMETS
9-PIN TUBE SOCKET
6
5
7
4
8
3
2 1
SPEAKER
JACK
6V6
using its pre-
then mount it using its pre-
SIDE
VIEW
BOTTOM
VIEW
8
9
7
6
1
5 2
4 3
12AX7
