SECTION 9:
WIRING THE SOCKETS, JACKS & POTS
PLEASE NOTE:
SPACE IS VERY LIMITED IN A TWEED CHASSIS. THINK AHEAD WHEN SOLDERING
THE LEADS INTO PLACE AND STAY ORGANIZED. FOLLOW THE WIRING DIAGRAM AND WORK FROM
THE FRONT OF THE CHASSIS TO THE BACK AND FROM THE POWER TRANSFORMER END OVER.
Solder the B+ wire
the board to pin 8 of the rectifier. Verify that you
have 2 wires on pin 8 of the rectifier socket
Using the Wiring Diagram
tube sockets starting from the power tubes and
work your way across the chassis towards the pre-
amp tubes.
Referring to the Wiring Diagram
the input jacks. This is one of the most problematic
FUSE INDICATOR
HOLDER LAMP
6
5
7
4
8
3
2 1
5Y3
from the lower left eyelet of
, begin wiring the
, install and wire
