Ready for your next build?
TWEED CHAMP 5F1 STYLE COMBO
TWEED DELUXE 5E3 STYLE COMBO
MOJOTONE TWEED BASSMAN 5F6-A STYLE COMBO
BLACKFACE PRINceTON REVERB
BLACKFACE DELUXE REVERB
18
Mojotone's Tweed Champ Style Amp Kit is based on the beloved 5 watt amp from the
1950s. These amps were perfect for recording and were featured on a wide array of
recordings from Joe Walsh's "Rocky Mountain Way" all the way to Derek & the Dominos'
"Layla." Modeled after the historic Class-A 6V6 platform, this amp delivers warm tones
that are harmonically rich and have a beautiful low volume crunch. SKU # G1TCK910
Class Type: Single Ended Class A All Tube Amplifier
Output: ~5W
Circuit: 5F1
Mojotone's Tweed Deluxe Style Amp is based on the popular 5E3 circuit from the 1950s
and is by far our most popular amplifier. These amps were originally designed as medium
power amps that would allow a musician to plug in more than one amplified instrument at
a time. At higher volumes, this amp produces saturated tones that were adopted as signature
tones for the likes of Billy Gibbons, Neil Young, Don Felder, and Larry Carlton. SKU # G1FTD819
Class Type: Class A/B all Tube Amplifier
Output: ~15 watts
Circuit:5E3
Mojotone's Tweed Bassman Style Amp is based on the late 50s 5F6-A circuit which seems
to be the most commonly used of the Bassman circuits. These 40 Watt amps are known
for their bold and pristine clean sounds as well as their classic unmistakeable dirt. The
Bassman is extremely versatile and has been used by tons of iconic guitarists from Mike
McCready, of Pearl Jam fame, all the way to Stevie Ray Vaughan himself. SKU # G1TWK942
Class Type: A/B all Tube Amplifier
Output: ~40 watts
Circuit: 5F6-A
STYLE COMBO
®
The Blackface Princeton Reverb has been a staple in guitar tone since its inception in 1964. The
Princeton Reverb was essentially all the good parts of its predecessor, the Tweed Princeton, but
with a long-spring reverb and tube-driven tremolo circuit added. Over the years the Princeton
Reverb has worked its way into the gear repertoire of many renowned guitarists such as Ryan
Adams, Larry Carlton, Glen Campbell, and Tommy Tedesco. SKU # G1BPR108
Class A/B All Tube Amplifier
Output: ~12-15 Watts
Circuit: AA1164
STYLE COMBO
®
One of our most popular amps, the Mojotone Deluxe Reverb Style Kit, is based on arguably
the most widely used guitar amp of all time. Just about every iconic guitarist imaginable has
played through a Deluxe Reverb at some point or another, but this amp has been specifically
touted by artists such as Mike Campbell, Vince Gill, Jackson Brown, and even Elvis Costello.
SKU # G1BDR092
Class Type: A/B All Tube Amplifier
Output: ~22 Watts
Circuit: AB763
BUILD. MODIFY. REPAIR.
Bias Type: Cathode Biased
Build time: 4 hours
Difficulty:
Bias Type: Cathode Biased
Build Time: 5 hours
Difficulty:
Bias Type: Fixed
Build Time: 6 hours
Difficulty:
Bias Type: Fixed
Build Time: 5 hours
Difficulty:
Bias Type: Fixed with an adjustable bias potentiometer
Build Time: 7 hours
Difficulty:
