SECTION 12:

CHASSIS INSTALLATION

Install the 2 chassis mount screws
holes on top of cab. Turn the cabinet upside down
may make it easier for chassis installation.
PRO TIP:
Be mindful of tweed and tolex when
installing. Use painter's tape if you need to at pinch
points for the cab, as it can protect from tearing or
lifting up the tweed covering.
Make sure you do not pinch any wires
the chassis screws/nuts, chassis and cabinet. Do
not over-tighten the chassis screws as it may deform
and weaken the cabinet.
Place the chassis into the cabinet
holes with mount screws.
Install and hand tighten
chassis screws. Do not tighten these two screws
yet. Leave them somewhat loose for chassis
alignment.
CHASSIS REAR PANEL
16
into mount
between
, lining up
the keps nuts for the
12AX7
PLUG SPEAKER
CABLE HERE
12AX7 J11
Hold the upper back panel in place
the chassis back so it is flush against the back panel.
Remove the back panel
two chassis mount screws.
Check chassis alignment
place, adjust as necessary.
Plug speaker into speaker jack
Install the cord strain relief
cabinet using #6 screw.
Install the tubes.
Install the upper and lower back panels
not over-tighten the screws.
5Y3
6V6
6V6
BUILD. MODIFY. REPAIR.
and tighten down the
with the back panel in
..
to the side of the
5Y3
and slide
. Do
