Table of Contents

Advertisement

Quick Links

1
. . . . . . . . . . . . . . . . . . . . . . 5
2
2.1
General . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2
Environmental tips. . . . . . . . . . . . . . . . . 8
3
. . . . . . . . . . . . . . . . . . . . . . . . 11
3.1
Fire prevention . . . . . . . . . . . . . . . . . . 11
3.1.1
Avoidance of fire risks . . . . . . . . . . . . . 11
3.1.2
Fire-fighting . . . . . . . . . . . . . . . . . . . . . 11
3.1.3
In case of fire. . . . . . . . . . . . . . . . . . . . 11
3.2
General . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3
Road safety . . . . . . . . . . . . . . . . . . . . . 12
3.4
Towing. . . . . . . . . . . . . . . . . . . . . . . . . 14
3.5
Gas system . . . . . . . . . . . . . . . . . . . . . 14
3.5.1
General instructions . . . . . . . . . . . . . . 14
3.5.2
Gas bottles . . . . . . . . . . . . . . . . . . . . . 15
3.6
Electrical system . . . . . . . . . . . . . . . . . 16
3.7
Water system . . . . . . . . . . . . . . . . . . . 16
4
4.1
Initial start-up. . . . . . . . . . . . . . . . . . . . 17
4.2
Registration . . . . . . . . . . . . . . . . . . . . . 17
4.3
Payload . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3.1
Terms . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3.2
Calculating the payload. . . . . . . . . . . . 21
4.3.3
4.3.4
4.3.5
Bike rack . . . . . . . . . . . . . . . . . . . . . . 24
4.4
Entrance step . . . . . . . . . . . . . . . . . . . 25
4.5
and side panes . . . . . . . . . . . . . . . . . . 26
4.6
PVC-floor covering . . . . . . . . . . . . . . . 26
4.7
Television . . . . . . . . . . . . . . . . . . . . . . 27
4.8
Branch block (model I) . . . . . . . . . . . . 27
4.9
Bonnet (model I) . . . . . . . . . . . . . . . . . 28
4.10
(model I) . . . . . . . . . . . . . . . . . . . . . . . 28
4.11
4.12
Snow chains . . . . . . . . . . . . . . . . . . . . 29
4.13
Road safety . . . . . . . . . . . . . . . . . . . . . 30
5
5.1
Driving the motorhome . . . . . . . . . . . . 33
5.2
Driving speed . . . . . . . . . . . . . . . . . . . 34
5.3
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.4
Seat belts . . . . . . . . . . . . . . . . . . . . . . 35
5.4.1
5.5
front passenger's seat. . . . . . . . . . . . . 36
5.6
Headrests . . . . . . . . . . . . . . . . . . . . . . 36
5.7
Seating arrangement. . . . . . . . . . . . . . 36
5.8
Tablet holder . . . . . . . . . . . . . . . . . . . . 37
5.9
Electrical window winder . . . . . . . . . . 37
5.10
sexternal mirrors . . . . . . . . . . . . . . . . . 38
5.11
Filling up with diesel . . . . . . . . . . . . . . 38
EN
Capron - 04-17 - CAP-0017-01
. . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . 17
. . . . . . . . . . . 33
6
6.1
Handbrake . . . . . . . . . . . . . . . . . . . . . . 39
6.2
Entrance step. . . . . . . . . . . . . . . . . . . . 39
6.3
Ramps . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.4
Supports . . . . . . . . . . . . . . . . . . . . . . . 39
6.4.1
General instructions . . . . . . . . . . . . . . . 39
6.4.2
Steady legs . . . . . . . . . . . . . . . . . . . . . 40
6.5
240 V connection . . . . . . . . . . . . . . . . . 40
6.6
Refrigerator . . . . . . . . . . . . . . . . . . . . . 40
7
. . . . . . . . . . . . . . . . . . . . . . . . 41
7.1
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.1.1
conversion door, outside . . . . . . . . . . . 41
7.1.2
Conversion door, inside . . . . . . . . . . . . 42
7.1.3
7.1.4
conversion door, extendable . . . . . . . . 43
7.2
External flaps . . . . . . . . . . . . . . . . . . . . 43
7.2.1
Flap lock, elliptical-shaped. . . . . . . . . . 44
7.3
Ventilation . . . . . . . . . . . . . . . . . . . . . . 44
7.4
Windows . . . . . . . . . . . . . . . . . . . . . . . 45
7.4.1
Sliding window without lock . . . . . . . . . 45
7.4.2
automatic hinges . . . . . . . . . . . . . . . . . 46
7.4.3
and side panes . . . . . . . . . . . . . . . . . . 47
7.4.4
Blind and insect screen . . . . . . . . . . . . 48
7.4.5
Sunroof with rotary hinges . . . . . . . . . . 49
7.4.6
7.5
Skylights . . . . . . . . . . . . . . . . . . . . . . . 51
7.5.1
Skylight with snap latch . . . . . . . . . . . . 52
7.5.2
7.6
Tables . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.6.1
fold-out leg . . . . . . . . . . . . . . . . . . . . . . 55
7.6.2
Lift-off table . . . . . . . . . . . . . . . . . . . . . 56
7.7
Lamps . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.7.1
LED lamp (model I) . . . . . . . . . . . . . . . 57
7.8
TV unit . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.9
Beds. . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.9.1
Overcab bed . . . . . . . . . . . . . . . . . . . . 59
7.9.2
Pull-down bed . . . . . . . . . . . . . . . . . . . 60
7.9.3
Bunk bed . . . . . . . . . . . . . . . . . . . . . . . 61
7.9.4
7.9.5
7.10
for sleeping . . . . . . . . . . . . . . . . . . . . . 63
7.10.1
Central seating group . . . . . . . . . . . . . 63
7.10.2
Front bench seat with divan. . . . . . . . . 64
7.10.3
lengthwise seat . . . . . . . . . . . . . . . . . . 65
7.10.4
Contents
. . . . . . 39
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Capron T58 and is the answer not in the manual?

Questions and answers

Related Manuals for Fiat Capron T58

Summary of Contents for Fiat Capron T58

  • Page 1: Table Of Contents

    Contents Warranty Pitching the motorhome ..... . 5 ..39 Handbrake ..... . 39 Introduction .
  • Page 2 Contents Gas system 10.4 Refrigerator.....103 ....67 10.4.1 Refrigerator ventilation grill .
  • Page 3 Contents Maintenance Helpful notes ....129 ....147 13.1 Inspection work ....129 16.1 Traffic rules in foreign countries.
  • Page 4 Contents Capron - 04-17 - CAP-0017-01...

  • Page 5: Warranty

    Warranty Warranty certificate 1Warranty Vehicle data Model: Car manufacturer/type of engine: Serial number: Delivery date: Initial registration: Purchased from company: Expiry of the warranty period: Key number: Chassis number: Customer address: Surname, Christian name: Street, house number: Postal code, town: Dealer's stamp and signature We reserve the right to alter the construction, equipment and the scope of delivery.
  • Page 6 Warranty Capron - 04-17 - CAP-0017-01...

  • Page 7: Introduction

    Introduction Please read this instruction manual completely before 2Introduction using the vehicle for the first time! Always keep this instruction manual in the vehicle. Also inform all other users of the safety regulations. The non-observance of this symbol can lead to personal injury. The non-observance of this symbol can lead to damage being caused to, or inside the vehicle.

  • Page 8: General

    Introduction General The motorhome is a product of Capron GmbH. The vehicle is constructed in accordance with the latest technology and the recognised safety regulations. Nevertheless, personal injury may result and the vehicle may be damaged if the safety instructions in this instruction manual are not followed.
  • Page 9 Introduction When parked, do not allow the engine to run more than necessary. When running idle, a cold engine releases more contaminants than usual. The running temperature of the engine is achieved more quickly whilst the vehicle is in motion. Use an environmentally-friendly WC chemical agent for the WC which can also be biologically degraded and only use small doses.
  • Page 10 Introduction Capron - 04-17 - CAP-0017-01...

  • Page 11: Safety

    Safety Chapter overview 3Safety This chapter contains important safety instructions. The safety instructions are for the protection of persons and property. The instructions address the following topics: fire prevention and what to do in case of fire general care of the vehicle road safety of the vehicle towing gas system of the vehicle...

  • Page 12: General

    Safety General The oxygen in the vehicle interior is used up by breathing and the use of gas operated appliances. That is why the used air must be replaced per- manently. For this purpose, forced ventilation options (e.g. skylights with forced ventilation) are fitted to the vehicle.
  • Page 13 Safety During the journey, persons are only to sit on the permitted seats (see chapter 5). The authorised number of seats is stipulated in the vehicle documents. Seat belts must be worn by all passengers. Fasten your seat belts before the beginning of the journey and keep them fastened during the journey.

  • Page 14: Towing

    Safety Towing Care is to be taken when connecting and detaching a trailer. Risk of acci- dent and injury! No persons are to be between the towing vehicle and the trailer during positioning for connecting and detaching. Gas system 3.5.1 General instructions The operator of the gas system is responsible for the performance of recurring inspections and for complying with the maintenance intervals.

  • Page 15: Gas Bottles

    Safety Ignition safety valves must close within 1 minute after the gas flame has extinguished. A clicking sound is audible. Check function from time to time. The built-in gas devices are exclusively meant for use with propane or butane gas or a mixture of both. The gas pressure regulator as well as all built-in gas devices are designed for a gas pressure of 30 mbar.

  • Page 16: Electrical System

    Safety Use the gas pressure regulator defroster if the temperature falls below 5 °C. Use only 11 kg or 5 kg gas bottles. Camping gas bottles with built-in check valve (blue bottle with max. 2.5 or 3 kg content) are can be used in exceptional cases with a safety valve.

  • Page 17: Before The Journey

    Before the journey Chapter overview 4Before the journey This chapter contains important information which has to be noted before com- mencing your journey or carrying out any tasks before the journey. The instructions address the following topics: initial start-up registration calculating the payload correct loading of the vehicle and bike rack towing...

  • Page 18: Payload

    Before the journey Payload Overloading the vehicle and wrong tyre pressure can cause tyres to burst. You can lose control of the vehicle (see section 14.6). The maximum permissible gross weight and the weight including special equipment fitted at the factory (actual weight) is shown in the vehicle documents, but not the weight of the loaded vehicle (see section 4.3.1).
  • Page 19 Before the journey Mass in ready-to-drive The mass in ready-to-drive condition is the weight of the ready-to-drive condition standard vehicle (excluding special equipment fitted at the factory). The mass in ready-to-drive condition is made up as follows: Unladen weight (mass of the empty vehicle) with factory-installed standard equipment (excluding special equipment fitted at the factory) Driver's weight Basic equipment weight...
  • Page 20 Before the journey Conventional load The conventional load is the weight specified by the manufacturer for the pas- sengers. Conventional load means: 75 kg are calculated for every seat specified by the manufacturer, regardless of how much the passengers actually weigh. The driver's seat is already included as part of the mass in ready-to-drive condition and must not be calculated as part of the conventional load.

  • Page 21: Calculating The Payload

    Before the journey 4.3.2 Calculating the payload The payload calculation at the factory is partly based on all-inclusive weights. For safety reasons, the maximum permissible gross weight in a laden condition must not be exceeded. The maximum permissible gross weight and the weight including special equipment fitted at the factory (actual weight) is shown in the vehicle documents, but not the weight of the loaded vehicle (see section 4.3.1).

  • Page 22: Loading The Vehicle Correctly

    Before the journey The actual payload is the difference between the maximum permissible gross weight in laden condition and the weighed vehicle weight. This can be used to determine the weight that remains for the personal equip- ment: Determine the weight of the passengers and subtract it from the value for the actual payload.

  • Page 23: Rear Garage/Rear Storage Space

    Before the journey Calculating axle loads: Multiply the distance between storage space and front axle (A) with the weight of the load in the storage space (G) and divide the result by the wheelbase (R). The result is the weight of the load in the storage space on the rear axle.

  • Page 24: Bike Rack

    Before the journey 4.3.5 Bike rack Observe the permissible axle loads and maximum permissible gross weight when loading the bike rack. Bicycles may not jut out beyond the maximum width of the vehicle. Adjust the attachments for the bikes accordingly. Load the bike rack with bicycles only.

  • Page 25: Entrance Step

    Before the journey Entrance step Before commencing the journey and after short interruptions of the journey, ensure that the entrance step is completely retracted. Do not stand in the direct range of the entrance step while it is being retracted or extended. Do not step on the entrance step until it has extended completely.

  • Page 26: Roman Shade For Windscreen And Side Panes

    Before the journey Emergency operation If the electric drive of the entrance step fails, follow the directions below to manually retract the entrance step: Pull out the securing splint from the connection to the engine. Release the rectangular connection to the engine using a suitable object (e.g.

  • Page 27: Television

    Before the journey Television Before commencing the journey, store the television securely. Before commencing the journey, ensure that the antenna is in park posi- tion. Danger of accidents! Park position means: The antenna points towards the back, is fully lowered and is locked in this position. Branch block (model I) The living area heater and the heater of the base vehicle can be coupled or disconnected from each other (via a branch block).

  • Page 28: Bonnet (Model I)

    Before the journey Bonnet (model I) When the bonnet is open, there is a risk of injury in the engine compart- ment. Even if the engine was switched off some time ago, it might still be hot. Danger of burns! Do not work in the engine compartment while the engine is running.

  • Page 29: Checking Engine Oil Level (Model I)

    Before the journey 4.11 Checking engine oil level (model I) Fig. 8 Oil dipstick (engine oil) The oil dipstick for the engine oil is located in the engine compartment, behind the front crossbeam. The oil dipstick is marked in red. Further information can be found in the instruction manual of the base vehicle.

  • Page 30: Road Safety

    Before the journey 4.13 Road safety Check tyre pressure before a journey or every 2 weeks. Wrong tyre pressure causes excessive wear and can lead to damage or even to tyre burst. You can lose control of the vehicle (see section 14.6). Before commencing the journey, work through the checklist: Checks Checked...
  • Page 31 Before the journey Checks Checked Housing body, inside Windows and skylights closed and locked Television removed from the support and securely stored Television antenna retracted (if one is built in) Loose parts stored away or fixed in position Open storage spaces empty Sink cover is stored securely Refrigerator door secured Refrigerator set to 12 V operation...
  • Page 32 Before the journey Capron - 04-17 - CAP-0017-01...

  • Page 33: During The Journey

    During the journey Chapter overview 5During the journey This chapter contains instructions on how to drive the motorhome. The instructions address the following topics: driving speed brakes seat belts seats and headrests seating arrangement writing and reading rest electrical window winder electrically adjustable external mirrors filling the tank Driving the motorhome...

  • Page 34: Driving Speed

    During the journey Driving speed The vehicle is equipped with a powerful engine. This means there are sufficient reserves in difficult traffic situations. This high power enables a high maximum speed and requires above-average driving ability. The vehicle provides a large contact surface for wind. A sudden cross- wind can be especially dangerous.

  • Page 35: Seat Belts

    During the journey Seat belts The vehicle is equipped with seat belts in the living area on the seats for which seat belts are compulsory by law. National regulations apply to fastening of seat belts. Fasten your seat belts before the beginning of the journey and keep them fastened during the journey.

  • Page 36: Driver's Seat And Front Passenger's Seat

    During the journey Driver's seat and front passenger's seat Before commencing the journey, rotate all swivel seats in the direction of travel and lock in position. The seats must remain fixed in position during the journey and are not to be rotated. The driver's seat and the front passenger's seat are part of the base vehicle.

  • Page 37: Tablet Holder

    During the journey Tablet holder If the driver's attention is distracted from the road, there is a danger of accidents. Do not install or operate the tablet or the smartphone during the journey. Fig. 11 Tablet holder A folding tablet holder is installed at the centre of the dashboard. The tablet holder is suitable for tablets and smartphones with a display size of 10"...

  • Page 38: Electrically Adjustable Sexternal Mirrors

    During the journey 5.10 Electrically adjustable external mirrors Depending on the model, the vehicle is equipped with two electrically adjust- able and heated external mirrors. The switches for external mirror adjustment and the mirror heater are on the dashboard. Fig. 13 Switch (electrically adjustable external mirrors) Adjusting the mirror:...

  • Page 39: Pitching The Motorhome

    Pitching the motorhome Chapter overview 6Pitching the motorhome This chapter contains instructions on how to pitch the vehicle. The instructions address the following topics: handbrake entrance step operation of the supports 240 V connection refrigerator Pitch the vehicle so that it is as horizontal as possible. Use ramps where necessary.

  • Page 40: Steady Legs

    Pitching the motorhome 6.4.2 Steady legs Depending on the model, the hexagonal nut has a joint, which can be used to bring the attached socket spanner into a more convenient position for turning. In order to ensure their correct function, clean and grease the interior tubes of the steady legs regularly.

  • Page 41: Living

    Living Chapter overview 7Living This chapter contains instructions about living in the vehicle. The instructions address the following topics: opening and closing the doors and external flaps ventilation of the vehicle opening and closing the windows and blinds opening and closing the skylights converting tables lamps use of the beds...

  • Page 42: Conversion Door, Inside

    Living 7.1.2 Conversion door, inside Fig. 16 Door lock of conversion door, inside, locked Opening: Pull lever (Fig. 16,2). Locking: Push the safety knob (Fig. 16,1) in. 7.1.3 Driver's door, inside (model I) Fig. 17 Door lock (driver's door, inside) Opening: Pull on the handle (Fig.

  • Page 43: Insect Screen On The Conversion Door, Extendable

    Living 7.1.4 Insect screen on the conversion door, extendable Open the insect screen completely before closing the conversion door. Fig. 18 Insect screen Closing: Pull out the insect screen completely by the bar (Fig. 18,1). Opening: Push the insect screen into its initial position by the bar (Fig. 18,1). External flaps Before commencing the journey, close all external flaps and lock them.

  • Page 44: Flap Lock, Elliptical-Shaped

    Living 7.2.1 Flap lock, elliptical-shaped During rain, water can penetrate the opened flap lock. Therefore close the lock handle. Fig. 19 Flap lock (elliptical-shaped, closed) Opening: Insert key into locking cylinder (Fig. 19,1) and turn a quarter turn in an anti- clockwise direction.

  • Page 45: Windows

    Living Condensation Ensure that there is a continuous exchange of air by providing frequent and efficient ventilation. This is the only method for ensuring that condensation is not formed during cool weather. During the colder season, a pleasant living cli- mate is created if heating output, air distribution and ventilation are synchro- nised.

  • Page 46: Hinged Window With Automatic Hinges

    Living 7.4.2 Hinged window with automatic hinges Open the window completely, to release the lock. If the locking device is not released and the window is closed nevertheless, there is the danger of the window breaking due to the massive counter-pressure. When opening the hinged windows, ensure that there are no torsional forces.

  • Page 47: Roman Shade For Windscreen And Side Panes

    Living To place the hinged window into the "continuous ventilation" position: Press the safety knob (Fig. 23,1) and keep it pressed. Turn the catch lever (Fig. 23,3) a quarter turn towards the centre of the window. Lightly open the hinged window outwards. Return the catch lever to its initial position.

  • Page 48: Blind And Insect Screen

    Living 7.4.4 Blind and insect screen Open blinds before commencing the journey. When the blinds are closed, vibrations can damage the spring shaft. Depending on the window size, the blinds are fitted with one or two han- dles. The windows are fitted with a blind and an insect screen. The blind and insect screen are adjusted separately.

  • Page 49: Sunroof With Rotary Hinges

    Living 7.4.5 Sunroof with rotary hinges When opening the sunroof, ensure that there are no torsional forces. Open and close the sunroof evenly. Fig. 27 Catch lever in "closed" position Fig. 28 Sunroof with rotary hinges, open Opening: Turn the catch lever (Fig. 27,3) a quarter turn towards the centre of the window.

  • Page 50: Roman Shade And Insect Screen

    Living To place the sunroof into the "continuous ventilation" position: Turn the catch lever (Fig. 29,3) a quarter turn towards the centre of the window. Slightly open the sunroof outwards. Return the catch lever to its initial position. The locking catch (Fig. 29,2) has to be moved into the recess of window catch (Fig.

  • Page 51: Skylights

    Living Skylights Depending on the model, skylights with or without forced ventilation are fitted to the vehicle. If a skylight is fitted without forced ventilation, the forced venti- lation is performed using mushroom-shaped vents. The apertures for forced ventilation must always be kept open. Never cover or block forced ventilations with objects such as e.g.

  • Page 52: Skylight With Snap Latch

    Living 7.5.1 Skylight with snap latch Fig. 31 Skylight with snap latch The skylight can be pushed upwards either from one side or from both sides. Opening: Pull on the handle (Fig. 31,3). Fold insect screen (Fig. 31,4) downward. Push the snap latch (Fig. 31,1) towards the inside of the skylight. At the same time use the handle (Fig.

  • Page 53: Heki Skylight (Mini And Midi)

    Living Forced ventilation Depending on the equipment, the skylight will be equipped with a forced ven- tilation (Fig. 33,1). The skylights with forced ventilation are installed in the living area and in the toilet compartment. Fig. 33 Forced ventilation 7.5.2 Heki skylight (mini and midi) Fig.
  • Page 54 Living Fig. 36 Heki skylight in ventilation Fig. 37 Ventilation position locking position mechanism Ventilation position The Heki skylight can be put in two ventilation positions: Bad weather position (Fig. 36,1) and central position (Fig. 36,2). Depending on the model, the sky- light can be locked in the central position with both left and right latches (Fig.

  • Page 55: Tables

    Living Tables 7.6.1 Suspension table with fold-out leg Fig. 38 Moving/extending the suspen- Fig. 39 Table top extension sion table Moving the table in the Raise the front of the table top until the detent mechanism (Fig. 38,3) on direction of travel: the retainer is free.

  • Page 56: Lift-Off Table

    Living Fig. 40 Bed foundation The table's fold-out leg enables it to be used as a bed foundation. Conversion to bed Slightly raise the front of the table top (Fig. 40,1). foundation: Press the release knob (Fig. 40,2) and fold the lower part of the fold-out leg (Fig.

  • Page 57: Lamps

    Living Lamps The light switches have different layouts according to the model. The light switches are located either in the entrance area, directly on the corre- sponding lamp or next to the lamp, e.g. in the vicinity of the seating group. 7.7.1 LED lamp (model I) The LED lamps for the pull-down bed are installed on the ceiling above the...
  • Page 58 Living Hold the flat screen and pull the catch pin (Fig. 43,2). Swivel the flat screen downward into the desired position. If it is hard to move the flat screen, open the adjustment knobs (Fig. 43,1) slightly on both sides of the holder. Rotate the flat screen into the desired position.

  • Page 59: Beds

    Living Beds 7.9.1 Overcab bed The maximum permitted overcab bed load is 200 kg. Only use the overcab bed, if the safety net is set up. Never allow small children to remain in the overcab bed without super- vision. But in particular with regard to small children less than 6 years of age, users should ensure that they cannot fall out of the overcab bed.

  • Page 60: Pull-Down Bed

    Living 7.9.2 Pull-down bed The maximum permitted load on the pull-down bed is 250 kg. Load the two cupboards beneath pull-down bed, right and left (if present), with a maximum of 5 kg each. The pull-down bed is not to be used for the storage of luggage. When the bed is not being used, only place the bed linen which is required for two persons in it.

  • Page 61: Bunk Bed

    Living Opening the pull-down bed: Switch off the lamps on the underside of the pull-down bed. Push the driver's seat and the front passenger's seat all the way forward. Fold over the back cushion of the divan. Open the lock (Fig. 49,1). Use both hands to pull the pull-down bed down as far as it will go.

  • Page 62: Fixed Bed (Gas-Pressure Springs)

    Living Fig. 52 Bunk bed (rear) Converting the bunk bed Pull on the loop (Fig. 52,3) and release the latch (Fig. 52,1). into the rear garage: Pull the slatted frame (Fig. 52,2) together with the mattress forward until it latches in place. Fig.

  • Page 63: Lying Surface Of Rear Single Beds

    Living Opening: Lift the mattress forwards. Lift slatted frame. The gas-pressure springs (Fig. 54,1) hold the slatted frame open. Closing: Press the slatted frame downwards against the resistance of the gas-pres- sure springs. 7.9.5 Lying surface of rear single beds Depending on the equipment, the single beds in the rear may be transformed into a continuous lying surface.

  • Page 64: Front Bench Seat With Divan

    Living 7.10.2 Front bench seat with divan Do not stand on the bedding box extension when it is pulled out. The bed- ding box extension may be damaged thereby. Fig. 57 Prior to conversion Fig. 58 During conversion Fig. 59 After conversion Depending on the model, insert an additional floor plate at the step to the driver's area to obtain an even seating area.

  • Page 65: Front Bench Seat With Lengthwise Seat

    Living 7.10.3 Front bench seat with lengthwise seat Do not stand on the bedding box extension when it is pulled out. The bed- ding box extension may be damaged thereby. Fig. 60 Prior to conversion Fig. 61 During conversion Fig. 62 After conversion Model T: Insert additional floor plate on the step to the driver's area to obtain an even seating area.

  • Page 66: Front Bench Seat (Guest Bed)

    Living 7.10.4 Front bench seat (guest bed) Fig. 63 Prior to conversion Fig. 64 After conversion Turn the driver's seat and push it all the way forward. Convert the table to a bed foundation (see section 7.6.1). Pull the seat cushion forwards. Insert the back cushion between the seat cushion and the rear wall.

  • Page 67: Gas System

    Gas system Chapter overview 8Gas system This chapter contains instructions regarding the gas system of the vehicle. The instructions address the following topics: safety gas consumption changing the gas bottles gas isolator taps The operation of the gas operation appliances of the vehicle is described in chapter 10.
  • Page 68 Gas system Before using the cooker make sure that there is sufficient ventilation. Open a window or the skylight. Do not use gas-operated cooking and baking facilities for heating pur- poses. If there are several gas devices, each gas device must have its own gas isolator tap.

  • Page 69: Gas Bottles

    Gas system Gas bottles Handle full or emptied gas bottles outside the vehicle only with closed regulator tap and attached protective cap. Gas bottles are only to be transported within the designated gas bottle compartment. Place the gas bottles in vertical position in the gas bottle compartment. Fasten the gas bottles so that they are unable to turn or tilt.

  • Page 70: Gas Consumption

    Gas system Gas consumption The data about gas consumption of the individual gas devices is standard average values. Appliances Gas consumption in grams/hour Heater Approx. 170 - 490 g/h Cooker, per cooker Approx. 140 - 165 g/h Refrigerator Approx. 18 g/h Changing gas bottles When changing gas bottles, do not smoke or create any open fire.

  • Page 71: Gas Isolator Taps

    Gas system Gas isolator taps 1 Refrigerator 2 Cooker 3 Heater/boiler 4 Oven Fig. 66 Symbols for the gas isolator taps A gas isolator tap (Fig. 66) for every gas device is built into the vehicle. The gas isolator taps can be found on the front of the cooker. 1 Gas isolator tap open 2 Gas isolator tap closed 3 Gas pipe...
  • Page 72 Gas system Capron - 04-17 - CAP-0017-01...

  • Page 73: Electrical System

    Electrical system Chapter overview 9Electrical system This chapter contains instructions regarding the electrical system of the vehicle. The instructions address the following topics: safety explanations of terms relating to the battery 12 V power supply living area battery loading the batteries transformer/rectifier panel 240 V power supply...

  • Page 74: Power Supply

    Electrical system Total discharge Total discharge of the battery is imminent, if a battery is completely discharged by an active appliance and by closed circuit current and the off-load voltage falls below 12 V. Total discharge damages the battery. Capacity Capacity refers to the amount of electricity which can be stored in a battery.

  • Page 75: Living Area Battery

    Electrical system 9.3.1 Living area battery Disconnecting and connecting the terminals, as well as changing the living area battery shall only be carried out by qualified personnel. In the event of an incorrect connection, there is the risk of short circuit and fire due to rub- bing cables.

  • Page 76: Charging Batteries Via A 240 V Power Supply

    Electrical system Discharging The living area battery is discharged by the closed circuit current which some electrical appliances continuously require. Total discharge damages the battery. Recharge battery in good time. The self-discharge rate of the battery is dependant on temperature. At 20 to 25 °C the self-discharge rate is approx.
  • Page 77 Electrical system Do not connect the battery cables to the wrong poles (red cable -> positive pole, black cable -> negative pole). Do not actuate the ignition if the terminals of the battery are disconnected. Danger of short circuit! Before disconnecting or connecting the terminals of the battery, switch off the vehicle engine as well as the 240 V and 12 V power supplies and all appliances.

  • Page 78: Transformer/Rectifier (Ebl 119)

    Electrical system Transformer/rectifier (EBL 119) Do not cover the ventilation slots. Danger of overheating! Depending on the model, not all slots for the fuses are occupied. Deviating from the default assignment, the following fuse values are inserted: "Basic light / step": 20 A "Reserve 3": 10 A (fuse for USB socket) Further information can be obtained in the manufacturer's instruction manual.

  • Page 79: Battery Cut-Off Switch

    Electrical system When the vehicle engine is turned off, the transformer/rectifier separates the starter battery electrically from the living area battery. This prevents the 12 V living area appliances from discharging the starter battery. The battery cut-off switch in the transformer/rectifier separates all the appli- ances from the living area battery.

  • Page 80: Battery Monitor

    Electrical system 9.4.3 Battery monitor You must fully recharge a discharged living area battery as soon as possible. The battery monitor in the transformer/rectifier monitors the voltage in the living area battery. If the battery voltage falls below 10.5 V, the battery monitor in the transformer/ rectifier switches off all the 12 V appliances.

  • Page 81: Panel (Lt 100)

    Electrical system Panel (LT 100) Fig. 69 Panel (LT 100) 12 V main switch and green LED Mains connection symbol and yellow LED Button to query the voltage of the living area battery Button to query the fill level in the fresh water tank Button to query the fill level in the waste water tank LED array to display the tank fill level LED array to display the battery voltage...

  • Page 82: Led Array For Battery Voltage

    Electrical system 9.5.2 LED array for battery voltage The LED array (Fig. 69,7) displays the battery voltage of the living area battery as follows: All LEDs are lit: battery is sufficiently charged. Yellow and red LEDs are lit: battery is partly discharged. Only red LED is lit: battery is discharged.

  • Page 83: Led Array For Tank Fill Level

    Electrical system Off-load voltage Measuring the off-load voltage is a simple method to check the condition of the battery. The off-load voltage is the voltage of the battery in idle condition, when current is neither supplied nor consumed. The following table helps to correctly interpret the displayed battery off-load voltage.

  • Page 84: Power Supply

    Electrical system 240 V power supply Only allow qualified personnel to work on the electrical system. Have the vehicle's electrical system checked by a qualified electrician at least once every 3 years. If the vehicle is used frequently, an annual check is recommended.
  • Page 85 Electrical system Fig. 70 240 V fuse box with safety Fig. 71 240 V connection on the cut-out and FI-switch vehicle (CEE socket outlet) Connecting the vehicle: Check whether the power supply device is suitable regarding connection, voltage, frequency and current. Check whether the cables and connections are suitable.

  • Page 86: Fuses

    Electrical system Fuses Only replace defective fuses when the cause of the defect is known and has been remedied. Replace defective fuses only after the power supply has been turned off. Never bridge or repair fuses. Only replace faulty fuses with a new fuse with the same rating. 9.7.1 12 V fuses The appliances connected to the 12 V power supply in the living area are...
  • Page 87 Electrical system Fuses on the living area The fuses are installed in the console of the right-hand seat in the driver's area. battery 1 Jumbo flat fuse 40 A/orange (Fuse protection for living area battery) 2 Flat fuse 2 A/grey (Control 12 V/control unit) Fig.

  • Page 88: 240 V Fuse

    Electrical system 9.7.2 240 V fuse Check the fault current protection switch for each connection to the 240 V power supply, at least once every 6 months. The dimensions, the number of safety cut-outs, and the triggering value of the safety cut-outs of the fuse box may differ from the shown type. The ver- sion of the fuse box depends on the model, the equipment and the country in which the vehicle is put into circulation.

  • Page 89: Appliances

    Appliances Chapter overview 10Appliances This chapter contains instructions regarding the appliances of the vehicle. The instructions refer exclusively to the operation of the appliances. Further information about the appliances can be found in the instruction man- uals for the appliances, included separately with the vehicle. The instructions address the following topics: heater (with boiler function) gas cooker...

  • Page 90: Heater / Production Of Hot Water

    Appliances 10.2 Heater / production of hot water The heater can both heat up the vehicle interior (heating the room air) and heat up the domestic water (boiler function). The following instructions are also valid if the heater is only used as boiler. Never let gas escape unburned due to danger of explosion.

  • Page 91: Safety Switch

    Appliances 10.2.2 Safety switch Fig. 78 Safety switch In vehicles where the waste gas vent for the heater is positioned underneath a hinged window, there is a danger that exhaust gases could get into the vehicle if the hinged window is open. For this reason these vehicles have a safety switch (Fig.

  • Page 92: Heater And Production Of Hot Water (Truma Combi)

    Appliances 10.2.4 Heater and production of hot water (Truma Combi) If the heater is not in operation when there is a risk of frost, empty the domestic water container. The power supply of the heating control system cannot be interrupted by means of the 12 V main switch.

  • Page 93: Hot-Air Heater And Boiler With Cp Plus Digital Operating Unit

    Appliances Summer operation It is not possible to heat the vehicle in "Summer" operating mode. In this oper- ating mode, only the domestic water is heated up to either 40 °C or 60 °C. Switching production of hot Open the regulator tap on the gas bottle and the gas isolator tap "Heater/ water on: boiler".
  • Page 94 Appliances After being switched off, the display in the control unit may remain active for several minutes since the heater is still running. Operating buttons The operating buttons have the following functions: Button Button operation Function Rotary push Turn to the right Menu is run through from left to right button Values are increased...
  • Page 95 Appliances 1 Heater 2 Hot water 3 Operating mode 4 Fan 5 Service menu 6 Setting the time 7 Warning symbol 8 Lighting (not used here) 9 Timer Fig. 83 Display (operating unit) Switching on the heater: Open the regulator tap on the gas bottle and the gas isolator tap "Heater/ boiler".
  • Page 96 Appliances Operating modes The hot-water heater with the boiler can be operated with various energy sources. Selecting operating mode: Turn rotary push button (Fig. 82,6) until the menu symbol operating mode (Fig. 83,3) flashes. Press rotary push button. Turn rotary push button until the desired operating mode is displayed: Gas operation Electrical operation (900 W) Electrical operation (1800 W)

  • Page 97: Safety/Drainage Valve

    Appliances The service menu contains items that generally only need to be set once (language, background brightness, calibration), as well as information for service centres (version numbers). Fault display The warning symbol (Fig. 83,7) flashes in the event of a warning. The heater continues to operate.

  • Page 98: Wall Flue

    Appliances Keep the water taps open until the water flowing out of the water taps has no bubbles in it. This is the only way to ensure that the domestic water con- tainer is full of water. Close all water taps. Emptying the domestic Set the rotary switch (Fig.

  • Page 99: Electrical Floor Warming Unit

    Appliances 10.2.8 Electrical floor warming unit On models with electrical floor warming unit, never drill holes in the floor or screw in any screws. Careful with sharp objects. There is danger of a power cut or a short circuit due to damage to a heater wire. Do not cover the regulator.

  • Page 100: Cooker

    Appliances 10.3 Cooker During operation of the gas cooker, do not leave the gas cooker unat- tended. Even if the gas cooker cannot be overseen for only a short time (e.g. Visit to the toilet), switch the gas cooker off. Never let gas escape unburned due to danger of explosion.

  • Page 101: Gas Oven With Grill (Thetford Duplex)

    Appliances Fig. 87 Operating controls for gas cooker Switching on: Open the regulator tap on the gas bottle and the gas isolator tap "Cooker". Open the gas cooker lid. Depending on the model, fold out or set up the flame protection. Turn the control knob (Fig.
  • Page 102 Appliances Before using the gas oven for the first time run it for 30 minutes at max- imum temperature without any contents. When the flame goes out, the thermocouple automatically cuts the gas supply. Further information can be obtained in the manufacturer's instruction manual.

  • Page 103: Extractor Hood (Recirculating)

    Appliances 10.3.3 Extractor hood (recirculating) Maintain a distance of 65 cm between the extractor hood and open flames. Do not flambé under the extractor hood. The appliance is connected to the 12 V power supply. Always switch on the extractor hood when cooking. It is advisable to switch on the extractor hood a few minutes before you start cooking.

  • Page 104: Refrigerator Ventilation Grill

    Appliances 10.4.1 Refrigerator ventilation grill Fig. 91 Refrigerator ventilation grill Fig. 92 Refrigerator ventilation grill, (Thetford) large (Thetford) Removal: Move the locking device (Fig. 91,1 or Fig. 92,1) to the middle. Remove refrigerator ventilation grill. 10.4.2 Operation (Thetford) Select only one energy source. Even when the 12 V power supply is switched off, a small electrical power flows which puts an extra load on the living area battery.
  • Page 105 Appliances The refrigerator always requires a 12 V control voltage, regardless of which type of energy it is using. The control voltage is present as soon as the transformer/rectifier is switched on. Therefore the closed circuit current always flows even if the refrigerator is switched off. Always switch off the transformer/rectifier for a temporary lay-up.

  • Page 106: Refrigerator Door Locking Mechanism

    Appliances When operated with 12 V, the refrigerator draws power only from the starter battery of the vehicle. The starter battery only supplies the refrigerator with 12 V when the vehicle engine is running. If the vehicle engine is switched off, the cooling no longer operates.

  • Page 107: Sanitary Fittings

    Sanitary fittings Chapter overview 11Sanitary fittings This chapter contains instructions regarding the sanitary fittings of the vehicle. The instructions address the following topics: water tank waste water tank complete water system toilet compartment toilet 11.1 Water supply, general Fill water tank from supply systems that have been verified to provide drinking water quality.

  • Page 108: Water Tank

    Sanitary fittings 11.2 Water tank Depending on the model, the water tank holds between 97 l and 122 l. For driving safety and for regulatory reasons, when the vehicle is motion the fill quantity must be reduced. If the water is drained using the safety drainage handle (see section 11.2.4), a residual quantity of approximately 20 litres will remain in the water tank.

  • Page 109: Topping Up The Water

    Sanitary fittings Position the vehicle horizontally. Switch on the 12 V power supply on the panel. Fig. 97 Safety/drainage valve open Fig. 98 Safety/drainage valve closed Close the safety/drainage valve. Turn the knob (Fig. 97,1) perpendicular to the safety/drainage valve and push the push button (Fig. 97,2) in. The closed safety/drainage valve is shown in Fig.

  • Page 110: Reducing The Water Quantity For Mobile Operation

    Sanitary fittings 11.2.4 Reducing the water quantity for mobile operation When filling the water tank, observe the maximum permissible gross weight of the vehicle. Luggage must be reduced accordingly when the water tank is full. Handle The handle is installed on the water tank. Fig.

  • Page 111: Emptying The Water System

    Sanitary fittings 11.2.6 Emptying the water system If the vehicle is not used for several days or if it is not heated when there is a risk of frost, empty the entire water system. Make sure that the 12 V power supply on the panel is switched off.

  • Page 112: Position Of The Safety/Drainage Valve

    Sanitary fittings 11.2.7 Position of the safety/drainage valve The position of the safety/drainage valve varies depending on the model. Model Position T58/135 Underneath the bed, in the room next to the heater (accessible through an opening in the cover) T64/348 T60/132 In the wardrobe, bottom compartment in the shelf T65/334...

  • Page 113: Toilet Compartment

    Sanitary fittings Emptying: Place key (Fig. 103,2) onto the square bolt (Fig. 103,1). In order to open the waste water tap, turn the square bolt a quarter turn. Completely empty waste water tank. To close the waste water tap, turn the square bolt back as far as it will go. 11.4 Toilet compartment Do not transport any loads in the shower tray.

  • Page 114: Vario Toilet Compartment

    Sanitary fittings Fig. 106 Clothes rail to dry clothes Clothes rail to dry clothes The folding clothes rail (Fig. 106,1) under the skylight can be used to hang towels and clothes to dry. Shower grate insert The shower grate insert is made of solid wood. The shower grate insert pro- tects the shower tray and provides a dry floor, even after taking a shower.

  • Page 115: Toilet

    Sanitary fittings Fig. 108 Lock, toilet compartment Fig. 109 Securing attachment, shower panelling partition Converting into a shower Enter toilet compartment and close toilet door from the inside and lock. cubicle: Put the latch (Fig. 108,2) in an upright position and unfold the inner part (Fig.
  • Page 116 Sanitary fittings Swivel toilet The flushing of the Thetford toilet is fed directly from the water system of the vehicle. The toilet bowl can be moved into the optimal position. Fig. 110 Thetford toilet bowl (swivelling) Fig. 111 Flush button/indicator lamp (Thetford toilet) The operating unit is located close to the toilet bowl.

  • Page 117: Emptying The Sewage Tank

    Sanitary fittings Emptying: Turn the slide lever (Fig. 112,1) in a clockwise direction. The sliding trap is closed. To empty, the sliding trap in the Thetford toilet must be closed. Remove and empty the Thetford cassette. 11.6.2 Emptying the sewage tank The sewage tank can only be taken out if the sliding trap is closed.

  • Page 118: Winter Operation

    Sanitary fittings 11.6.3 Winter operation Do not use antifreeze. Antifreeze can damage the toilet. If the toilet, the water tank and the sewage tank (cassette) are in a frost-pro- tected part of the vehicle, the toilet can also be used in the winter. If the toilet, the water tank and the sewage tank (cassette) are not in a frost- protected part of the vehicle, empty the water tank, the sewage tank and the water pipes if there is a risk of frost.

  • Page 119: Care

    Care Chapter overview 12Care This chapter contains instructions regarding the care of the vehicle. The instructions address the following topics: exterior of the vehicle interior water system extractor hood winter operation At the end of the chapter there is a checklist of measures you must carry out if you are not going to use the vehicle for an extended period of time.

  • Page 120: Washing The Vehicle

    Care 12.1.3 Washing the vehicle Never clean the vehicle in the car wash. Water can penetrate the refriger- ator grills, the waste gas vent or the forced ventilations. The vehicle could be damaged. Wash the vehicle only on a washing site intended for this purpose. Avoid full sunshine.

  • Page 121: Entrance Step

    Care 12.1.6 Entrance step If the entrance step is lubricated, coarse particles of dirt can settle on the lubri- cant during the journey and cause damage to the operating mechanism of the entrance step. Therefore, do not lubricate the moving parts of the entrance step.

  • Page 122: Water System

    Care Insect screen fabric on the door, windows, and skylights: Always remove insect residues or dirt immediately. Otherwise the fabric could be dam- aged. Wasps and birds could cause damages when feeding on the adhered residues. A microfibre cloth is recommended for the cleaning of the insect screen fabric.

  • Page 123: Disinfecting The Water System

    Care Empty the water system. Close all drainage openings and drain cocks. Fill mixture of water and cleaning agent into the water tank. Observe the manufacturer's instructions regarding the mixing ratio. Open the drain cocks one by one. Leave the drain cocks open until the mixture of water and cleaning agent has reached the respective drain.

  • Page 124: Extractor Hood (Recirculating)

    Care 12.4 Extractor hood (recirculating) Clean the extractor hood grease filter occasionally. How often cleaning is nec- essary depends on how often the extractor hood is used. Do not wait to clean the grease filter until the performance of the extractor hood has noticeably decreased.

  • Page 125: Winter Care

    Care Swivel the filter holder (Fig. 117,2) upwards until it engages. Close the housing as described in "Cleaning the grease filter". Further information can be obtained in the instruction manual for the respective appliance. 12.5 Winter care De-icing salt damages the underbody and the parts open to water spray. We recommend that you wash the vehicle more frequently during wintertime.

  • Page 126: Lay-Up

    Care 12.6 Lay-up 12.6.1 Temporary lay-up If the vehicle has been stationary for a long period (approx. 10 months) have the braking and gas systems checked by an authorised specialist workshop. Take into consideration that water is undrinkable after only a short time. Animal damage to cables can lead to short circuits.

  • Page 127: Winter Lay-Up

    Care Activities Done Gas system Close regulator tap on the gas bottle Close all gas isolator taps Always remove gas bottles from the gas bottle compartment, even if they are empty Electrical system Fully charge living area and starter battery Charge the battery for at least 20 hours before laying up.

  • Page 128: Starting Up The Vehicle After A Temporary Lay-Up Or After Lay-Up Over Winter

    Care Activities Done Water system Clean the water system using a cleaning agent from a specialised store Complete vehicle Arrange the tarpaulins in such a way that the ventilation openings are not covered, or use porous tarpaulins 12.6.3 Starting up the vehicle after a temporary lay-up or after lay- up over winter Go through the following checklist before start-up: Activities...

  • Page 129: Maintenance

    Maintenance Chapter overview 13Maintenance This chapter contains instructions about inspection and maintenance work concerning the vehicle. The maintenance instructions address the following topics: replacing light bulbs At the end of the chapter you will find important instructions on how to obtain spare parts.

  • Page 130: Front Lights

    Maintenance Types of bulbs Different types of bulbs are used in the vehicle. Below, we have described how to change the different types of bulbs. Fig. 118 Types of bulbs Pos. in Fixture type/bulb Changing Fig. 118 type Plug-in fixture To remove, pull out the bulb To mount, push the bulb into the socket with gentle pressure...

  • Page 131: Rear Lights

    Maintenance Open bonnet (see chapter 4). Insert your hand behind the lamp holder of the defective bulb. Turn the lamp holder with the bulb in an anticlockwise direction and remove Turn bulb in an anticlockwise direction and remove from the holder. Put in a new bulb.

  • Page 132: Replacing Bulbs, Internal

    Maintenance Fig. 122 Remove the cover Insert the snap-in lugs of the supplied tool (Fig. 122,1) at the sides of the cover as shown. Remove the cover with the tool. Change the bulb. Applying light pressure, push the cover on the lamp until it snaps into place. 13.4 Replacing bulbs, internal Bulbs and light fittings can be extremely hot.

  • Page 133: Spare Parts

    Maintenance Fig. 125 LED lamp (example) Fig. 126 Awning light LED lights have a very long life. It is not normally necessary to replace a light. Changing bulbs: Contact a dealer or service centre. 13.5 Spare parts Every alteration of the original condition of the vehicle can alter road behaviour and jeopardize road safety.

  • Page 134: Vehicle Identification Plate

    Maintenance 13.6 Vehicle identification plate 1 Type 2 Manufacturer's code and chassis number 3 Maximum permissible gross weight of the vehicle 4 Free 5 Permissible axle load rear 6 Permissible axle load front 7 Maximum permissible gross weight of the vehicle with trailer 8 Serial number Fig.

  • Page 135: Wheels And Tyres

    Wheels and tyres Chapter overview 14Wheels and tyres This chapter contains instructions about the tyres of the motorhome. The instructions address the following topics: tyre selection handling of tyres At the end of the chapter there is a table you can use to find the correct tyre pressure for your vehicle.

  • Page 136: Tyre Selection

    Wheels and tyres Fig. 128 Tighten the wheel nuts or wheel bolts cross-wise Check regularly that the wheel nuts or wheel bolts are firmly seated. Re-tighten the wheel nuts or wheel bolts of a changed wheel after 50 km (30 miles) (Fig. 128). When using new or newly painted wheel rims, re-tighten the wheel nuts or wheel bolts once again after approx.

  • Page 137: Tyre Specifications

    Drive in such a way as to protect your tyres. Avoid braking sharply, revving up too strongly and long journeys on poor roads. 14.5 Tightening torque Wheel rim Tightening torque Fiat base vehicle Steel wheel rim 15" 160 Nm Steel wheel rim 16" 180 Nm Alloy wheel rim 15"...
  • Page 138 Types Tyre size Front air Rear air pressure in pressure in Fiat All types 215/70 R 15 C/CP 4.25 (109/107) Q All types with "Camping" 215/70 R 15 C/CP 4.75...

  • Page 139: Troubleshooting

    Troubleshooting 15.1 Chapter overview 15Troubleshooting This chapter contains instructions about possible faults in your vehicle. The faults are listed with their possible causes and corresponding remedies. The instructions address the following topics: braking system electrical system gas system gas cooker gas oven extractor hood heater (with boiler function)
  • Page 140 Troubleshooting Fault Cause Remedy Starter or living area Jumbo flat fuse (40 A) on Replace jumbo flat fuse battery is not charged the starter or living area (40 A) on the starter or when operated in 240 V battery is defective living area battery mode Charger module in the...

  • Page 141: Gas System

    Troubleshooting Fault Cause Remedy Starter battery is Disconnector relay in the Contact customer service discharged in 12 V transformer/rectifier is operation defective Battery cut-off switch on Set battery cut-off switch the transformer/rectifier is to on switched off No voltage is supplied by Living area battery is Charge living area the living area battery...

  • Page 142: Cooker

    Troubleshooting 15.5 Cooker Fault Cause Remedy Ignition fuse does not Heat-up time is too short Keep control knob operate (flame does not pressed for approx. burn after the control 15 to 20 seconds after knobs are released) ignition Ignition fuse is defective Contact customer service Flame extinguishes when Thermocouple sensor is...
  • Page 143 Troubleshooting Fault Cause Remedy After switching on (winter No operating voltage Check 12 V battery and summer operation) voltage, load battery if none of the LEDs comes necessary Check all electrical plug connectors Appliance fuse or vehicle Check appliance fuse or fuse defective vehicle fuse and replace if necessary...

  • Page 144: Refrigerator

    Troubleshooting 15.8 Refrigerator In the event of a defect contact the nearest customer service workshop of the relevant appliance manufacturer. The list of addresses is enclosed with the accompanying appliance documentation. Only authorised qualified personnel may repair the appliance. For certain faults, indicators also flash on the operating panel. Fault Cause Remedy...

  • Page 145: Water Supply

    Troubleshooting 15.9 Water supply Fault Cause Remedy Leakage water inside the A leak has occurred Identify leak, re-connect vehicle water pipes No water Water tank is empty Replenish drinking water Drain cock not closed Close drain cock 12 V power supply is Switch 12 V power switched off supply on...

  • Page 146: Body

    Troubleshooting Fault Cause Remedy Any change in the taste Tank filled with dirty Clean water system or odour of the water water mechanically and chemi- cally; then disinfect and rinse copiously with drinking water Fuel filled into the water Clean water system tank by mistake mechanically and chemi- cally;...

  • Page 147: Helpful Notes

    Helpful notes Chapter overview 16Helpful notes This chapter contains helpful tips for the journey. The instructions address the following topics: traffic rules in foreign countries road assistance in European countries gas supply in European countries toll regulations in European countries safe ways to spend the night during travel camping in winter At the end of the chapter there is a checklist containing the most important...

  • Page 148: Gas Supply In European Countries

    Helpful notes 16.3 Gas supply in European countries In Europe, there are several different connection systems for gas bottles. It is not always possible to fill or exchange your gas bottles in a foreign country. Get information about the connection system in the country you are travelling to before embarking on your journey, e.g.

  • Page 149: Tips On Staying Overnight Safely During Travel

    Helpful notes 16.5 Tips on staying overnight safely during travel Prudent behaviour is the most important protective measure for insuring a safe night in the motorhome. The risk of thievery is reduced to a minimum when the following basic rules are observed: During high season do not spend the night at highway rest stops or parking areas located along typical vacation routes.

  • Page 150: Travel Checklists

    Helpful notes 16.7 Travel checklists The following checklists will help that nothing important is left at home although not everything on the checklists might be necessary. Do not leave checking of documents (e.g. vehicle papers and information) as well as checking the condition of the vehicle until just before com- mencing the trip.
  • Page 151 Helpful notes Object Object Object Vehicle/tools Waste water Gas tube Snow chains container (winter) Adapter socket Fabric tape Screwdriver CEE adapter Watering can for Current-measuring drinking water instrument Wire Cable reel Wheel chocks Spare wheel Glue First-aid kit Spare lamps Universal pliers Vehicle jack Spare fuses...
  • Page 152 Helpful notes Capron - 04-17 - CAP-0017-01...
  • Page 153 Index 12 V fuses ......86 Brakes ....... . 34 For the Thetford toilet .
  • Page 154 Index Doors Water system ..... . . 122 Conversion door ....41 Water tank .
  • Page 155 Index Gas cooker Cleaning ......121 Fault current protection switch ... . . 84 Switching off .
  • Page 156 Index Lay-up Opening ......53 Temporary ......126 Roman shade .
  • Page 157 Index Refrigerator ......40 Door lock ......106 Off-load voltage .
  • Page 158 Index Safety/drainage valve, position ... . 112 Suspension table ......55 Sanitary fittings .
  • Page 159 Index Extractor hood ..... . 142 Waste water tank ..... . . 112 Furniture flaps .
  • Page 160 Index Capron - 04-17 - CAP-0017-01...

This manual is also suitable for:

Capron t135Capron t348Capron t64Capron t132Capron t334Capron t65 ... Show all

Table of Contents

Save PDF
