Physical; Electrical; Environmental - ProCurve zl Series Installation And Getting Started Manual

Specifications

Physical

Width:
Depth:
Height:
Weight:

Electrical

The Power Supply Shelf automatically adjusts to any voltage between
100-127 and 200-240 volts when using the J8712A power supply, and 200-240
volts only when using the J8713A power supply, and either 50 or 60 Hz.
AC voltage:
Maximum current:
Frequency range:
Maximum continuous
output power:
N o t e
Typical input current for each of the two power supplies when installed in the
Power Supply Shelf is approximately 5A@ 100-127V~ and 2.5A@ 200-240V for
J8712A and 6.4A@ 200-240V~ for J8713A.

Environmental

Operating Temperature:
Non-Operating Temperature -40°C to 70°C (-40°F to 158°F)
Operating Relative humidity:
(non-condensing)
Power Supply Shelf
44.3 cm (17.4 in)
22.76 cm (8.96 in)
13.22 cm (5.2 in)
4.2 kg (9.2 lbs)
J8712A
100–127 volts 200–240 volts 200–240 volts only
12 A 5 A
50/60 Hz 50/60 Hz
875W 875W
Power Supply Shelf
0°C to 55°C (32°F to 131°F)
15% to 95% at 40°C (104°F)
J8713A
10 A
50/60 Hz
1500W
A
A-1
