- Page 1 Installation and Getting Started Guide ProCurve Switch zl Power Supply Shelf Power over Ethernet Devices www.procurve.com...
- Page 3 ProCurve Switch zl Power Supply Shelf Installation and Getting Started Guide...
- Page 4 Safety Before installing and operating these products, please read the “Installation Precautions” in chapter 2, “Installing and Connecting the ProCurve Switch zl Power Supply Shelf”, and the safety statements in appendix B, “Safety and Regulatory Statements”. Hewlett-Packard Company...
-
Page 5: Table Of Contents
Contents 1 Introducing the ProCurve Switch zl Power Supply Shelf Front of the Unit ..........1-2 LEDs . - Page 6 3 Troubleshooting Basic Troubleshooting Tips ........3-1 Diagnosing with the LEDs .
- Page 7 Australia/New Zealand ........B-8 Japan .
-
Page 9: Introducing The Procurve Switch Zl Power Supply Shelf
Introducing the ProCurve Switch zl Power Supply Shelf The ProCurve Switch zl Power Supply Shelf is an external power supply that can supply backup or extra Power over Ethernet (PoE) power to the Series zl Switches. ProCurve Switch zl Power Supply Shelf... -
Page 10: Front Of The Unit
Introducing the ProCurve Switch zl Power Supply Shelf Front of the Unit Front of the Unit Power and Fault LEDs ProCurve Switch zl Power Supply Shelf J8714A Power Power Fault Fault Power Supply EPS Port Status Status – Device Connected –... -
Page 11: Leds
Introducing the ProCurve Switch zl Power Supply Shelf Front of the Unit LEDs Table 1-1. Power Supply Shelf LEDs State Meaning Power The unit is powered on. (green) The unit is NOT powered on. Also on back panel of the... -
Page 12: Back Of The Unit
EPS Ports on the Power Supply Shelf The Power Supply Shelf has two external power supply ports. You can connect one or two ProCurve zl PoE capable switches to provide PoE power as a primary or backup source. Each port receives the maximum power, depending on which power supply is installed, either 273 W or 900 W. -
Page 13: Eps Port Operation
Introducing the ProCurve Switch zl Power Supply Shelf EPS Port Operation EPS Port Operation The Power Supply Shelf supports two EPS ports that can provide power to PoE capable zl switches through EPS cables. Each external power supply unit can provide additional or redundant PoE power to a zl switch. All internal power supplies have PoE power. -
Page 15: Installing And Connecting The External Power Supply Shelf
(page 2-12) ■ Included Parts The Power Supply Shelf has the following components shipped with them: ■ ProCurve Switch zl Power Supply Shelf Installation and Getting Started Guide, this manual ■ Read Me First ■ Customer Support/Warranty booklet (5990-8862) ■... -
Page 16: Installation Procedures
Installing and Connecting the External Power Supply Shelf Installation Procedures Installation Procedures Summary Follow these steps to install the Power Supply Shelf. The rest of this chapter provides details on these steps. Prepare the installation site (page 2-4). Make sure the physical envi- ronment into which the unit will be installed is properly prepared, including having the correct cabling ready to connect to the unit and having an appropriate location for the unit. -
Page 17: Installation Precautions
Installing and Connecting the External Power Supply Shelf Installation Procedures Installation Precautions: Follow these precautions when installing your Power Supply Shelf: W A R N I N G S ■ The rack or cabinet should be adequately secured to prevent it from becoming unstable and/or falling over. -
Page 18: Prepare The Installation Site
Installing and Connecting the External Power Supply Shelf Installation Procedures 1. Prepare the Installation Site ■ Cabling - Only use the EPS cables supplied with the unit for external power connections to switches. ■ Installation Location - Before installing the unit, plan its location and orientation relative to other devices and equipment: •... - Page 19 Installing and Connecting the External Power Supply Shelf Installation Procedures 8 mm M4 screws Figure 2-1. Attaching brackets to the unit W A R N I N G For safe reliable installation, only use the screws provided in the accessory kit to attach the mounting brackets to the unit. N o t e The mounting brackets have multiple mounting holes and can be rotated allowing for a wide variety of mounting options.
- Page 20 Installing and Connecting the External Power Supply Shelf Installation Procedures Partially install a screw into the top hole of a pair of holes that are 0.5 inches apart in each rack/cabinet upright as shown in the illustration below. Ensure that the screws are at the same level in each upright. Partially install a screw into the top hole of a close (0.5-inch) pair on...
-
Page 21: Horizontal Surface Mounting
Installing and Connecting the External Power Supply Shelf Installation Procedures Install the other screw into the upper hole in each bracket. Tighten these screws. Figure 2-4. Installing top screws into bracket and rack Horizontal Surface Mounting Place the unit on a table or other horizontal surface. The unit comes with rubber feet in the accessory kit that can be used to help keep the unit from sliding on the surface. -
Page 22: Install The Power Supplies
Although mixing power supplies is supported, ProCurve Networking highly recommends that the two types of power supplies are not mixed in the same Power Supply Shelf. See the Procurve Power over Ethernet (PoE) for zl and yl Products Planning and Implementation Guide, page 4-9 for more information. -
Page 23: Connect The Power Supply Shelf To A Switch
Installing and Connecting the External Power Supply Shelf Installation Procedures 4. Connect the Power Supply Shelf to a Switch Connect the EPS cables from the supported network switches to the appro- priate ports on the Power Supply Shelf. Also see “Recommended Connection Topologies”... -
Page 24: Connect Ac Power
Installing and Connecting the External Power Supply Shelf Installation Procedures 5. Connect AC Power Connect the AC power cord supplied with the Power Supply Shelf to the power connector on the back of the unit, and then into a properly grounded electrical outlet. -
Page 25: Verify Correct Operation
When the Power Supply Shelf is mounted in its location and powered on, you should first verify it is working properly by checking the unit’s LEDs. Check the LEDs on the unit as described below. Power and Fault LEDs ProCurve Switch zl Power Supply Shelf J8714A Power Power... -
Page 26: Recommended Connection Topologies
This section shows some recommended connection topologies using the Power Supply Shelf. The Power Supply Shelf provides only EPS (PoE) power for up to two ProCurve switches. In the illustration below, one Power Supply Shelf with two power supplies is connected to a ProCurve Series zl Switch, also with two power supplies. -
Page 27: Limitations
Installing and Connecting the External Power Supply Shelf Recommended Connection Topologies To Power To Power Source Source Power Supply Shelf ProCurve Switch ProCurve Switch 5406zl 5406zl EPS cables Figure 2-9. Connecting one EPS to two 5406zl switches Limitations In the illustration above, the maximum power that can be provided to each switch is dependant upon which power supply is installed in the Power Supply Shelf. -
Page 29: Troubleshooting
Connection topologies. It is important to make sure you have a valid ■ connection topology. The Power Supply Shelf can support two ProCurve PoE devices. Sample topologies are shown at the end of chapter two page 2-12 in this book. -
Page 30: Diagnosing With The Leds
Troubleshooting Diagnosing with the LEDs Diagnosing with the LEDs Table 3-1 shows LED patterns on the Power Supply Shelf that indicate problem conditions. Check in the table for the LED pattern that you see on your unit. Refer to the corresponding diagnostic tip on the next few pages. Table 3-1. - Page 31 Troubleshooting Diagnosing with the LEDs Diagnostic Tips: Problem Solution ➊ The unit is not 1. Verify the power cord is plugged into an active power source and to the unit. Make sure these connections are snug. plugged into an active AC power 2.
-
Page 32: Diagnostic Tests
See the Customer Support/Warranty booklet that came with your Power Supply Shelf for information on how to use these services to get technical support. The ProCurve Web site, www.procurve.com also provides up-to-date support information under “product support”. -
Page 33: Physical
Specifications Physical Power Supply Shelf Width: 44.3 cm (17.4 in) Depth: 22.76 cm (8.96 in) Height: 13.22 cm (5.2 in) Weight: 4.2 kg (9.2 lbs) Electrical The Power Supply Shelf automatically adjusts to any voltage between 100-127 and 200-240 volts when using the J8712A power supply, and 200-240 volts only when using the J8713A power supply, and either 50 or 60 Hz. -
Page 34: Acoustic
Specifications Non-Operating Relative 90% maximum at 65°C (149°F) humidity: (non-condensing) Maximum altitude: 3.5 Km (10,000 ft) Acoustic Power Supply Shelf Geraeuschemission LwA=52.9 dB am fiktiven Arbeitsplatz nach DIN 45635 T.19 Noise Emission LwA=52.9 dB at virtual workspace according to DIN 45635 T.19 Cable Length EPS cables are 2.0 meters (6.56 feet) in length... -
Page 35: B Safety And Regulatory Statements
Safety and Regulatory Statements Safety Information Documentation reference symbol. If the product is marked with this symbol, refer to the product documentation to get more information about the product. WARNING A WARNING in the manual denotes a hazard that can cause injury or death. -
Page 36: Informations Concernant La Sécurité
Safety and Regulatory Statements Informations concernant la sécurité Informations concernant la sécurité Symbole de référence à la documentation. Si le produit est marqué de ce symbole, reportez-vous à la documentation du produit afin d'obtenir des informations plus détaillées. WARNING Dans la documentation, un WARNING indique un danger susceptible d'entraîner des dommages corporels ou la mort. -
Page 37: Hinweise Zur Sicherheit
Safety and Regulatory Statements Hinweise zur Sicherheit Hinweise zur Sicherheit Symbol für Dokumentationsverweis. Wenn das Produkt mit diesem Symbol markiert ist, schlagen Sie bitte in der Produktdokumentation nach, um mehr Informationen über das Produkt zu erhalten. WARNING Eine WARNING in der Dokumentation symbolisiert eine Gefahr, die Verletzungen oder sogar Todesfälle verursachen kann. -
Page 38: Considerazioni Sulla Sicurezza
Safety and Regulatory Statements Considerazioni sulla sicurezza Considerazioni sulla sicurezza Simbolo di riferimento alla documentazione. Se il prodotto è contras- segnato da questo simbolo, fare riferimento alla documentazione sul prodotto per ulteriori informazioni su di esso. WARNING La dicitura WARNING denota un pericolo che può causare lesioni o morte. -
Page 39: Consideraciones Sobre Seguridad
Safety and Regulatory Statements Consideraciones sobre seguridad Consideraciones sobre seguridad Símbolo de referencia a la documentación. Si el producto va marcado con este símbolo, consultar la documentación del producto a fin de obtener mayor información sobre el producto. WARNING Una WARNING en la documentación señala un riesgo que podría resultar en lesiones o la muerte. -
Page 40: Safety Information (Japan
Safety and Regulatory Statements Safety Information (Japan) Safety Information (Japan) J a p a n P o w e r C o r d W a r n i n g... -
Page 41: Safety Information (China
Safety and Regulatory Statements Safety Information (China) Safety Information (China) -
Page 42: Emc Regulatory Statements
Safety and Regulatory Statements EMC Regulatory Statements EMC Regulatory Statements U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment. -
Page 43: Korea
Safety and Regulatory Statements EMC Regulatory Statements Korea Taiwan... -
Page 44: Declaration Of Conformity
Hewlett-Packard Company 8000 Foothills Blvd., Roseville, CA 95747 U.S.A Supplier's Address: declares, that the product Product Name and Model: J8714A - Switch zl Series Power Supply Shelf Regulatory Model Number: RSVLC-0607 Product Options: conforms to the following Product Specifications and Regulations:... -
Page 45: C Recycle Statements
Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. - Page 46 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Laitteiden hävittäminen kotitalouksissa Euroopan unionin alueella Jos tuotteessa tai sen pakkauksessa on tämä merkki, tuotetta ei saa hävittää kotitalousjätteiden mukana. Tällöin hävitettävä laite on toimitettava sähkölaitteiden ja elektronisten laitteiden kierrätyspisteeseen. Hävitettävien laitteiden erillinen käsittely ja kierrätys auttavat säästämään luonnonvaroja ja varmistamaan, että...
- Page 47 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Smaltimento delle apparecchiature da parte di privati nel territorio dell'Unione Europea Questo simbolo presente sul prodotto o sulla sua confezione indica che il prodotto non può essere smaltito insieme ai rifiuti domestici. È responsabilità dell'utente smaltire le apparecchiature consegnan- dole presso un punto di raccolta designato al riciclo e allo smaltimento di apparecchiature elettriche ed elettroniche.
- Page 48 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Descarte de Lixo Elétrico na Comunidade Européia Este símbolo encontrado no produto ou na embalagem indica que o produto não deve ser descartado no lixo doméstico comum. É responsabilidade do cliente descartar o material usado (lixo elétrico), encaminhando-o para um ponto de coleta para reciclagem.
- Page 49 Index back of unit … 1-4 Fault LED … 1-3 EPS ports … 1-4 behaviors … 1-3 power connector … 1-4 blinking definition … 1-3 basic troubleshooting tips … 3-1 showing error conditions … 3-2 flashing LEDs error indications … 3-2 front of unit cabinet LEDs …...
- Page 50 safety specifications … A-2 specifications mounting the unit cable length … A-2 in a rack or cabinet … 2-4 emmissions … A-2 on a horizontal surface … 2-7 environmental … A-1 physical … A-1 safety … A-2 summary network devices of unit installation …...
- Page 52 Technical information in this document is subject to change without notice. © Copyright 2007, Hewlett-Packard Development Company, L.P. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. Printed in Singapore February 2007 Manual Part Number 5991-4739 *5991-4739*...
