SK 300
Instruction manual
Contents
Important safety instructions .................................................2
The SK 300 G3 bodypack transmitter....................................3
The frequency bank system............................................... 3
Areas of application............................................................. 4
Delivery includes.........................................................................5
Product overview........................................................................6
Overview of the displays .................................................... 7
Inserting the batteries/accupack...................................... 8
Charging the accupack ....................................................... 8
Using the bodypack transmitter.......................................... 11
RF signal.............................................................................. 14
Selecting a standard display........................................... 16
Using the operating menu..................................................... 17
The buttons ........................................................................ 17
Overview of the operating menu .................................. 18
Working with the operating menu ............................... 19
operating menu ....................................................................... 21
receiver....................................................................................... 29
receiver - individual operation....................................... 29
receivers - multi-channel operation ............................. 29
Cleaning the bodypack transmitter .................................... 30
Recommendations and tips .................................................. 31
If a problem occurs ... ............................................................. 32
Specifications............................................................................ 33
Connector assignment ..................................................... 34
the microphones................................................................ 35
An animated instruction manual can be
viewed on the SK 300 G3 product page on our
website at www.sennheiser.com.
Contents
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Sennheiser SK 300

Summary of Contents for Sennheiser SK 300

  • Page 1: Table Of Contents

    If a problem occurs ..............32 Specifications................33 Connector assignment ............. 34 Polar diagrams and frequency response curves of the microphones..............35 An animated instruction manual can be viewed on the SK 300 G3 product page on our Instruction manual website at www.sennheiser.com.

  • Page 2: Important Safety Instructions

    • Keep this instruction manual. Always include this This bodypack transmitter is part of the evolution wireless instruction manual when passing the product on to third series generation 3 (ew G3). With this series, Sennheiser parties. offers high-quality state-of-the-art RF transmission •...

  • Page 3: Areas Of Application

    The SK 300 G3 bodypack transmitter Delivery includes Delivery includes from the SK 300 G3 product page on our website at www.sennheiser.com. The frequency banks “U1” to “U6” allow you to freely select The packaging contains the following items: and store frequencies. It might be that these frequencies intermodulation-free.

  • Page 4: Product Overview

    Product overview Overview of the displays After switch-on, the bodypack transmitter displays the standard display “Frequency/Name”. For further illustra- Overview of the SK 300 G3 bodypack tions and examples of the different standard displays, refer transmitter to page 16. The display backlighting is automatically reduced after approx.

  • Page 5: Putting The Bodypack Transmitter Into Operation

    Inserting the batteries/accupack ³ For powering the bodypack transmitter, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack (optional accessory). Lock the 3.5 mm jack plug by screwing down the Open the battery compartment by pushing the two ¹...

  • Page 6: Attaching The Bodypack Transmitter To Clothing

    Putting the bodypack transmitter into operation Using the bodypack transmitter Using the bodypack transmitter ME 4 Use the microphone clip to attach the microphone to clothing (e.g. tie, lapel). To establish a transmission link, proceed as follows: 1. Switch the bodypack transmitter on (see next section) 2.

  • Page 7: Deactivating The Lock Mode Temporarily

    Using the bodypack transmitter Using the bodypack transmitter Press the button. Deactivating the lock mode temporarily The transmission frequency is displayed but the bodypack transmitter does not transmit an RF You can activate or deactivate the automatic lock mode via signal.

  • Page 8: Muting The Audio Signal Or Deactivating The Rf Signal

    Using the bodypack transmitter Using the bodypack transmitter Muting the audio signal or deactivating the 531.375 ew300 G3 RF signal MUTE · Audio signal is muted Transmitter’s display panel: “MUTE” is displayed Receiver’s display panel: “TX Mute” is displayed* only when activated on the receiver (see previous section) ·...

  • Page 9: Selecting A Standard Display

    Press the UP/DOWN button to select a standard display: A special feature of the Sennheiser ew G3 series is the consistent, intuitive menu structure of transmitters and receivers. As a result, adjustments to the settings can be Contents of the display Selectable standard display made quickly –...

  • Page 10: Overview Of The Operating Menu

    Using the operating menu Using the operating menu Overview of the operating menu Display Function of the menu item Software Revision Displays the current software revision (see page 28) Main menu “Menu” Exit Exits the extended menu “Advanced Sensitivity Menu” and returns to the main menu Extended menu Frequency Preset “Advanced Menu”...

  • Page 11: Adjusting Settings Via The Operating Menu

    Using the operating menu Adjusting settings via the operating menu Adjusting settings via the To subsequently return to the last edited menu item: Press the button repeatedly until the last operating menu edited menu item appears. Exiting a menu item Make use of the possibility to adjust settings via the operating menu of your receiver and to transfer Change to the “Exit”...

  • Page 12: The Extended Menu "Advanced Menu

    Adjusting settings via the operating menu Adjusting settings via the operating menu The following figures are a guide to the best settings: • numbers from 0 to 9, • special characters and spaces. Transmission situation Sensitivity setting −30 to −21 dB Loud music/vocals To enter a name, proceed as follows: −21 to 0 dB...
  • Page 13 Adjusting settings via the operating menu Adjusting settings via the operating menu Setting a transmission frequency for the current channel Setting the mode for the MUTE switch and the RMS 1 external mute switch – “Mute Mode” Press the UP/DOWN button until the “Tune”...
  • Page 14 Adjusting settings via the operating menu Adjusting settings via the operating menu Activating/deactivating the pilot tone transmission – If you connect the RMS 1 external mute switch, you “Pilot Tone” can only set the muting via the RMS 1. The function of the MUTE switch is deactivated Advanced Menu...

  • Page 15: Synchronizing The Bodypack Transmitter With A Receiver

    For information on software updates, visit the When synchronizing the bodypack transmitter with a SK 300 G3 product page at www.sennheiser.com. receiver, please observe the following: Only use a transmitter and a receiver from the same frequency range (see the type plate on the transmitter and the receiver).

  • Page 16: Cleaning The Bodypack Transmitter

    Cleaning the bodypack transmitter Recommendations and tips Cleaning the bodypack Recommendations and tips transmitter ... for the ME 2 and ME 4 clip-on microphones • To reduce level variations to a minimum when the user CAUTION! Liquids can damage the electronics of the turns his or her head away from the microphone, bodypack transmitter! attach the microphone as centrally as possible.

  • Page 17: If A Problem Occurs

    If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”.

  • Page 18: Connector Assignment

    Specifications Specifications Polar diagrams and frequency response Current consumption: curves of the microphones at nominal voltage typ. 180 mA (30 mW) with switched-off Polar diagram ME 3 Polar diagram ME 4 ≤ 25 μA transmitter 0° 0° 30° 30° 30° 30°...
  • Page 19 Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Publ. 12/16, 549126...
