IDROPULITRICE AD ALTA PRESSIONE PHDB 4 C3 IDROPULITRICE AD ALTA PRESSIONE PETROL PRESSURE WASHER Traduzione delle istruzioni d’uso originali Translation of the original instructions ATTENZIONE! PRIMA DI UTILIZZARE LA MACCHINA WARNING! READ THE OPERATING INSTRUCTIONS DEL MANUALE DI ISTRUZIONI LEGGI! BEFORE USING THE MACHINE/APPLIANCE.
Page 2
Prima di leggere aprire le due pagine con le immagini e prendere confidenza con le diverse funzioni dell’apparecchio. Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the device. Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
Page 4
IMPORTANTE PRIMA DI LAVORARE! 1. Sostituire i tappi dell‘olio di trasporto All’atto della consegna è avvitato un tappo dell’olio per il trasporto nero che deve essere sostituito con il tappo dell’olio rosso fornito. 2. Controllare il livello dell‘olio del motore Controllare il livello dell‘olio prima di ogni utilizzo.
IDROPULITRICE AD ALTA PRESSIONE 6,5...9,5 PHDB 4 C3 conducibilità elettrica * conducibilità acqua dolce +1200 μS/cm Introduzione sostanze sedimentabili ** < 0,5 mg/l Congratulazioni per l'acquisto del nuovo apparecchio. È stato scelto un pro- sostanze filtrabili *** < 50 mg/l dotto di alta qualità.
1 imbuto 1 ago per pulizia ugelli (si trova nel manuale di istruzioni) Tempo di av- 1 materiale di montaggio viamento del 1 Sostegno per tubo pompaggio 1 manuale di istruzioni automatico IT │ MT │ 3 ■ PHDB 4 C3...
Page 10
In caso di uso non conforme, i getti ad alta pressione po- trebbero essere pericolosi. Non dirigere il getto su persone, animali, attrezzature elettriche attive o l'apparecchio stesso. START CLOSE VALVOLA DELL'ARIA: APERTURA / CHIUSURA CHOKE BENZINA: OFF / ON FUEL │ IT │ MT ■ 4 PHDB 4 C3...
► ■ gionamento idrico. materia di prevenzione degli infortuni. I dispositivi per il getto di liquidi devono essere controllati co- stantemente e il risultato del controllo deve essere registrato per iscritto. IT │ MT │ 5 ■ PHDB 4 C3...
Page 12
Se si utilizzano detergenti, attenersi alla scheda ► tecnica di sicurezza del produttore del deter- gente, in particolare alle indicazioni relative ai dispositivi di protezione individuali. │ IT │ MT ■ 6 PHDB 4 C3...
Se si utilizza regolarmente l'apparecchio in modo ► prolungato e se si presentano ripetutamente i sin- tomi in questione (ad esempio formicolio alle dita, dita fredde), si consiglia di sottoporsi ad una visita medica. IT │ MT │ 7 ■ PHDB 4 C3...
L'inalazione di aerosol può comportare danni alla salute. Le maschere di protezione delle vie respiratorie di categoria FFP2 o superiore sono idonee alla protezione contro gli aerosol acquosi. │ IT │ MT ■ 8 PHDB 4 C3...
Non avvicinare mai le mani e i piedi a compo- ► nenti in movimento o rotanti. Pericolo di avvelenamento! Non utilizzare ► l'apparecchio in ambienti chiusi. Non utilizzare combustibili inadeguati, poiché ► potrebbero essere pericolosi. IT │ MT │ 9 ■ PHDB 4 C3...
Montare il portagomma ♦ Attaccare il supporto del tubo flessibile alla maniglia di prua ♦ Utilizzare due viti e due rondelle per fissare il portagomma alla maniglia di prua │ IT │ MT ■ 10 PHDB 4 C3...
Aprire la mandata dell'acqua. NOTA ► Il flessibile di mandata non è compreso nella fornitura. ♦ Per aggiungere olio usare l'imbuto fornito e versare lentamente l'olio nell'entrata dell'olio . Non riempire troppo! IT │ MT │ 11 ■ PHDB 4 C3...
All'avviamento con la cordicella di avviamento un improvviso contraccolpo potrebbe causare lesioni alla mano. ■ Per l'avviamento indossare guanti protettivi. ♦ Aprire il rubinetto della benzina portando il rubinetto della benzina in posizione "ON". │ IT │ MT ■ 12 PHDB 4 C3...
Dopo il funzionamento con detergente ♦ Risciacquare a fondo l'apparecchio con il motore acceso e il grilletto aperto per almeno 1 minuto. IT │ MT │ 13 ■ PHDB 4 C3...
Controllare il livello dell'olio con l'astina di livello dell'olio Se l'olio è torbido (acqua nell'olio), rivolgersi subito al servizio clienti. ♦ Pulire il filtro nell’adattatore di connessione del tubo flessibile ♦ Pulire il filtro di aspirazione │ IT │ MT ■ 14 PHDB 4 C3...
♦ Sfilare la spina della candela di accensione con un movimento rotatorio. ♦ Rimuovere la candela di accensione con la chiave per candele in dotazione. ♦ L'assemblaggio avviene in sequenza inversa. IT │ MT │ 15 ■ PHDB 4 C3...
Controllare/pulire il flessibile del deter- Flessibile del detergente non a tenuta o ostruito. gente . NOTA Qualora non fosse possibile risolvere l'anomalia, è necessario far controllare l'apparecchio dal servizio ► di assistenza clienti. │ IT │ MT ■ 16 PHDB 4 C3...
NOTA Questa prestazione di garanzia ha come presupposto che l’apparecchio ► In caso di utensili Parkside e Florabest, inviare esclusivamente l'articolo guasto senza accessori (es. batteria, valigetta, attrezzi di difettoso e la prova di acquisto (scontrino di cassa) vengano presentati montaggio, ecc.).
EN ISO 14982:2009 Pezzi di ricambio Tipo / denominazione dell'apparecchio: Ordinazione dei pezzi di ricambio Idropulitrice ad alta pressione PHDB 4 C3 Per l'ordinazione dei pezzi di ricambio è necessario fornire i seguenti dati: Anno di produzione: 08 - 2018 ■...
PETROL PRESSURE WASHER PHDB 4 C3 pH value 6.5...9.5 Electrical conductivity* Conductivity Introduction Fresh water +1200 μS/cm Congratulations on the purchase of your new appliance. You have chosen Settleable solids** < 0.5 mg/l a high-quality product. The operating instructions are a part of this product.
2 x spray gun holder weight 1 x funnel 1 x nozzle cleaner needle (can be found in the operating instructions) 1 x assembly material 1 x hose holder 1 operating manual GB │ MT │ 21 ■ PHDB 4 C3...
Page 28
Fire, naked flames and smoking are prohibited! High-pressure jets can be dangerous if misused. Do not aim at people, animals, active electrical equipment or at the appliance itself. START CLOSE CHOKE: OPEN/CLOSE CHOKE PETROL: ON/OFF FUEL │ GB │ MT ■ 22 PHDB 4 C3...
Liquid jet sprayers must be inspected regularly and the result of the inspection noted in writing. WARNING! Observe the regulations of your water supply ► company. GB │ MT │ 23 ■ PHDB 4 C3...
Page 30
Damaged vehicle tyres are a source of danger. When using cleaning agents, comply with the ► safety data sheet of the cleaning agent manu- facturer, especially the information on personal safety equipment. │ GB │ MT ■ 24 PHDB 4 C3...
In the event of regular, prolonged use of the ap- ► pliance coupled with the repeated occurrence of certain symptoms (e.g. tingling in the fingers, cold fingers), we recommend consulting a doctor. GB │ MT │ 25 ■ PHDB 4 C3...
The use of high-pressure cleaners can lead to ► the formation of aerosols. Inhalation of aerosols can be hazardous to health. Grade FFP2 filter masks (or higher) are suitable for protection from water-based aerosols. │ GB │ MT ■ 26 PHDB 4 C3...
Keep your hands and feet away from all moving ► or rotating parts. Risk of poisoning! Do not operate the appliance ► in confined spaces. Do not use any unsuitable fuels as these can be ► dangerous. GB │ MT │ 27 ■ PHDB 4 C3...
Mount the hose holder ♦ Attach hose holder to bow handle ♦ Use two screws and two washers to attach the hose holder the bow handle │ GB │ MT ■ 28 PHDB 4 C3...
♦ Connect the suction hose (diameter at least 3/4") with the filter ♦ Screw the dipstick back into the oil inlet. (accessories) to the water connection GB │ MT │ 29 ■ PHDB 4 C3...
; to do this, move the fuel tap to the "ON" position. ♦ Move the On/Off switch to the "ON" position. to position I \ I (in the left position). ♦ Set the choke │ GB │ MT ■ 30 PHDB 4 C3...
Rinse off the dissolved dirt using a high-pressure jet. After using with a cleaning agent ♦ Leave the appliance engine running and pull the trigger for at least 1 minute to rinse itself. GB │ MT │ 31 ■ PHDB 4 C3...
Clean the strainer in the hose connection adapter ♦ Clean the intake filter ♦ Check the fastenings between the engine and the frame for cracks and have any cracked fastenings replaced by customer service. │ GB │ MT ■ 32 PHDB 4 C3...
♦ Pull of the spark plug connector with a twisting motion. ♦ Remove the spark plug with the supplied spark plug spanner. ♦ Assembly is done in the reverse order. GB │ MT │ 33 ■ PHDB 4 C3...
Fit low-pressure nozzle ( ). Cleaning agent hose leaking or blocked. Inspect/clean cleaning agent hose . NOTE If the fault cannot be remedied, the appliance must be checked by customer service. ► │ GB │ MT ■ 34 PHDB 4 C3...
(receipt) and a short ► For Parkside and Florabest tools, please send us only the defective written description of the fault and its time of occurrence. item without the accessories (e.g. battery, storage case, assembly tools, etc.).
Replacement parts EN ISO 14982:2009 Ordering replacement parts Type/appliance designation: The following information should be provided when ordering spare parts: Petrol pressure washer PHDB 4 C3 ■ Type of appliance Year of manufacture: 08 - 2018 ■ Item number of the appliance ■...
Page 43
Gerät entlüften........48 DE │ AT │ CH │ 37 ■ PHDB 4 C3...
BENZIN-HOCHDRUCKREINIGER pH-Wert 6,5...9,5 PHDB 4 C3 elektrische Leitfähigkeit * Leitfähigkeit Frischwasser +1200 μS/cm Einleitung absetzbare Stoffe ** < 0,5 mg/l Wir beglückwünschen Sie zum Kauf Ihres neuen Gerätes. Sie haben sich abfiltrierbare Stoffe *** < 50 mg/l damit für ein hochwertiges Produkt entschieden. Die Betriebsanleitung ist Kohlenwasserstoffe...
1 x Schraubenschlüssel (SW 10/12) Betriebsgewicht 2 x Sechskantschlüssel (M5/M6) 2 x Spritzpistolenhalterung 1 x Trichter 1 x Düsenreinigungsnadel (befindet sich in der Betriebsanleitung) 1 x Montagematerial 1 x Schlauchhalterung 1 Betriebsanleitung DE │ AT │ CH │ 39 ■ PHDB 4 C3...
Page 46
Der Strahl darf nicht auf Personen, Tiere, aktive elektrische Ausrüstung oder auf das Gerät selbst gerichtet werden. START CLOSE CHOKE: ÖFFNEN / SCHLIESSEN CHOKE BENZIN: AUS / AN FUEL │ DE │ AT │ CH ■ 40 PHDB 4 C3...
Gesetzgebers zur Unfallverhütung beachten. Flüssigkeitsstrahler müssen regelmäßig geprüft WARNUNG! und das Ergebnis der Prüfung schriftlich festgehal- Beachten Sie die Vorschriften Ihres Wasserver- ► ten werden. sorgungsunternehmens. DE │ AT │ CH │ 41 ■ PHDB 4 C3...
Page 48
Beschädigung ist die Verfärbung des Reifens. Beschädigte Fahrzeugreifen sind eine Gefah- renquelle. Bei Verwendung von Reinigungsmitteln ist das ► Sicherheitsdatenblatt des Reinigungsmittel-Herstel- lers zu beachten, insbesondere die Hinweise zur persönlichen Schutzausrüstung. │ DE │ AT │ CH ■ 42 PHDB 4 C3...
Ununterbrochener Betrieb ist schlechter als durch – Pausen unterbrochener Betrieb. Bei regelmäßiger, langandauernder Benutzung des ► Gerätes und bei wiederholtem Auftreten entspre- chender Anzeichen (zum Beispiel Fingerkribbeln, kalte Finger) empfehlen wir eine ärztliche Untersuchung. DE │ AT │ CH │ 43 ■ PHDB 4 C3...
Während des Gebrauchs von Hochdruckreini- ► gern können Aerosole entstehen. Das Einatmen von Aerosolen kann gesundheitliche Schäden zur Folge haben. Atemschutzmasken der Klasse FFP2 oder höher sind zum Schutz vor wässrigen Aerosolen geeignet. │ DE │ AT │ CH ■ 44 PHDB 4 C3...
Hände und Füße nie in die Nähe bewegter ► oder umlaufender Teile bringen. Vergiftungsgefahr! Gerät darf nicht in geschlos- ► senen Räumen betrieben werden. Keine ungeeigneten Brennstoffe verwenden, da ► sie gefährlich sein können. DE │ AT │ CH │ 45 ■ PHDB 4 C3...
Nehmen Sie hierzu den mitgelieferten Schraubenschlüssel und den Sechskantschlüssel zur Hilfe. Schlauchhalterung montieren ♦ Befestigen Sie Schlauchhalterung am Bügelgriff ♦ Benutzen Sie zwei Schrauben und zwei Unterlegscheiben die Schlauchhalterung am Bügelgriff zu befestigen. │ DE │ AT │ CH ■ 46 PHDB 4 C3...
♦ Warten Sie eine Minute bis sich das Öl gesetzt hat bevor Sie den Ölstand erneut wie oben beschrieben prüfen. ♦ Schrauben Sie den Ölmessstab wieder in den Öleinlass. DE │ AT │ CH │ 47 ■ PHDB 4 C3...
Tragen Sie zum Starten Schutzhandschuhe. ♦ Benzinhahn öffnen; hierfür den Benzinhahn auf Stellung „ON“ bringen. ♦ Ein-/Ausschalter auf Stellung „ON“ bringen. auf Stellung I \ I (in die linke Position) bringen. ♦ Choke │ DE │ AT │ CH ■ 48 PHDB 4 C3...
– Schmutz entfernen: Gelösten Schmutz mit Hochdruckstrahl abspülen. Nach Betrieb mit Reinigungsmittel ♦ Lassen Sie das Gerät bei laufendem Motor und geöffnetem Abzug mindestens 1 Minute klarspülen. DE │ AT │ CH │ 49 ■ PHDB 4 C3...
Reinigen Sie das Sieb im Schlauchanschlussadapter ♦ Reinigen Sie den Ansaugfilter ♦ Prüfen Sie die Befestigungselemente zwischen Motor und Rahmen auf Risse und lassen Sie rissige Befestigungselemente durch den Kunden- dienst ersetzen. │ DE │ AT │ CH ■ 50 PHDB 4 C3...
Kupferdrahtbürste. Danach die Zündkerze alle 50 Betriebsstun- den warten. ♦ Ziehen Sie den Zündkerzenstecker mit einer Drehbewegung ab. ♦ Entfernen Sie die Zündkerze mit dem beiliegenden Zündkerzenschlüssel. ♦ Der Zusammenbau erfolgt in umgekehrter Reihenfolge. DE │ AT │ CH │ 51 ■ PHDB 4 C3...
Hochdruckdüse ( ) ist montiert. Niederdruckdüse ( ) montieren. Reinigungsmittelschlauch undicht oder verstopft. Reinigungsmittelschlauch prüfen/reinigen. HINWEIS Kann die Störung nicht behoben werden, muss das Gerät vom Kundendienst überprüft werden. ► │ DE │ AT │ CH ■ 52 PHDB 4 C3...
Wahl – für Sie kostenlos repariert oder ersetzt. Diese Garantieleistung ► Bei Parkside und Florabest Werkzeugen senden Sie bitte ausschließ- setzt voraus, dass innerhalb der Drei-Jahres-Frist das defekte Gerät und der lich den defekten Artikel ohne Zubehör (z. B. Akku, Aufbewahrungs- Kaufbeleg (Kassenbon) vorgelegt und schriftlich kurz beschrieben wird, koffer, Montagewerkzeuge, etc) ein.
Geben Sie verschmutztes Wartungsmaterial und Betriebsstoffe in einer dafür vorgesehenen Sammelstelle ab. EN ISO 14982:2009 Ersatzteile Typ / Gerätebezeichnung: Benzin-Hochdruckreiniger PHDB 4 C3 Ersatzteile bestellen Herstellungsjahr: 08 - 2018 Bei der Ersatzteilbestellung sollten folgende Angaben gemacht werden: Seriennummer: IAN 305750 ■...
Page 61
KOMPERNASS HANDELS GMBH BURGSTRASSE 21 DE - 44867 BOCHUM DEUTSCHLAND / GERMANY www.kompernass.com Versione delle informazioni · Last Information Update Stand der Informationen: 07 / 2018 · Ident.-No.: PHDB4C3-072018-1 IAN 305750...
