SMART Coin System Quick Start and Configuration Guide

2.4 Opening the SMART Coin System

Copyright © Innovative Technology Ltd 2014
The SMART Coin
System and be
opened via the front
latch.
Take care during opening any
loose coins not captured by the
disk will be free to fall once the
SMART Coin System is separated.
Coin Disk
Sensor Coils
& Acoustic
flap
Coin
Transport
Path
Sensors
Acceptance
Flap
9
GAXXXX-01
