- Page 1 SMART HOPPER OPERATIONS MANUAL INTELLIGENCE IN VALIDATION FENG CHEN TECHNOLOGY CO.,LTD 豐乾科技有限公司 ITL 台灣總代理 Tel：+886-4-2232-9236 Fax： +886-4-2235-4234 Web：http://www.itltw.com.tw/ E-mail： itl.tw@msa.hinet.net...
- Page 2 SMART HOPPER OPERATIONS MANUAL Copyright Innovative Technology Ltd 2012 GA401-5...
-
Page 3: Table Of Contents
Table 9 - CCT Coin Acceptor Connections Table 10 - SMART Hopper eSSP Commands Table 11 - eSSP example for the SMART hopper with coin mech connected via the hopper 22 Table 12 – eSSP example for the SMART hopper with coin mech connected separately... -
Page 4: Introduction
In this way we may continue to improve our product. Innovative Technology Ltd has a policy of continual product improvement. As a result the products supplied may vary from the specification described here. Copyright Innovative Technology Ltd 2012... -
Page 5: Technical Specification
Table 4 - Maximum and Minimum Coin Dimensions CAPACITY The capacity of the SMART Hopper depends on the size of coins. The table below shows approximate capacity for various coins and assumes all the coins within the hopper are the... -
Page 6: General Description
3 GENERAL DESCRIPTION The Innovative Technology SMART Hopper sets new standards for coin handling technology. The SMART Hopper is a multi-coin hopper with the ability to payout coins of 11 different denominations at speeds up to 12 coins per second. - Page 7 (eSSP); locking option. The SMART Hopper can be used to control a coin acceptor making machine wiring and software implementation simpler. There is no need to have a separate ccTalk bus to control the coin acceptor. Only 1 SSP bus is required, the hopper then communicates with the coin acceptor using a ccTalk connection.
-
Page 8: Installation
SMART HOPPER OPERATIONS MANUAL 4 INSTALLATION 4.1 HOPPER INSTALLATION 1. Secure the mounting plate using the 6 fixing holes shown in Appendix B – Dimension Drawing. 2. Connect the cable from the host machine to the connector on the rear of the mounting plate. -
Page 9: Lock Installation
4.2 LOCK INSTALLATION The SMART Hopper has the option to add a lock that prevents the hopper being removed from the mounting plate. The hopper uses a standard lock PA650 which includes all the parts shown with an asterisk *. The lock cam can be ordered from Innovative Technology, part MC211. -
Page 10: Machine Interfaces
5 MACHINE INTERFACES 5.1 STATUS LEDS The SMART Hopper has 2 status LED’s located on the front panel, one Green, one Red. The green status LED indicates system health, while the red status LED is used to indicate system problems; these are described below in Table 7 - LED Status Codes. The red LED will flash a number of times according to the status, pause and then flash the code again. -
Page 11: Hardware
SMART HOPPER OPERATIONS MANUAL 5.2 HARDWARE Coin Entry Lid Catch Status LEDs Host Machine Connections Coin Payout Lock Unit Removal Handle Cash Box Exit Copyright Innovative Technology Ltd 2009 GA401-2... -
Page 12: Connection Diagram
Supply WARNING Always ensure that the bottom cash box exit is clear to allow coins to exit the hopper Figure 1 - SMART Hopper Connection Diagram 5.2.2 INTERFACE CONNECTOR Figure 2 - Interface Connections location eSSP Connections (Host Machine) Function... -
Page 13: Communication Protocols
The integrity of data transfers is ensured through the use of 16 bit CRC checksums on all packets. A Diffie-Hellman key exchange is used to allow the host machine and SMART hopper to jointly establish a shared secret key over an insecure communications channel. The encryption algorithm used is AES with a 128-bit key;... -
Page 14: Programming The Smart Hopper
To program the SMART hopper a PC must be used running the ITL SMART PIPS software version 1.4.5 or later. - Page 15 SMART HOPPER OPERATIONS MANUAL After connection has been established, move the mouse pointer over the Smart Hopper to be updated, and click the right mouse button, Select Download Update File Copyright Innovative Technology Ltd 2009 GA401-2...
- Page 16 SMART HOPPER OPERATIONS MANUAL Locate and open the required file. Once the file is open, you will need to confirm the download. Click ‘Yes’ if the information is correct. NOTE: Do not remove power during the update procedure; this could result in rendering the Smart Hopper inoperable.
-
Page 17: Clearing A Jam
Much of this is achieved by careful hardware and software design. 6.1 CLEARING A JAM On the unlikely event of a coin jamming within the SMART Hopper, follow the steps below 1. Power off the hopper 2. Remove the hopper from the mounting plate 3. -
Page 18: Appendix B - Dimension Drawing
SMART HOPPER OPERATIONS MANUAL APPENDIX B – DIMENSION DRAWING Copyright Innovative Technology Ltd 2009 GA401-2... -
Page 19: Appendix C - Essp Commands
SMART HOPPER OPERATIONS MANUAL APPENDIX C – eSSP COMMANDS Table 10 - SMART Hopper eSSP Commands shows the eSSP commands for the SMART Hopper. These commands are in addition to the Generic commands. See document number GA138 for the full eSSP specification. Commands marked with an asterisk (*) -
Page 20: Appendix D - Example Essp Communications
> POLL < OK < DISPENSED, 28 00 00 00 Dispense value of 0040 completed > POLL < OK Table 11 - eSSP example for the SMART hopper with coin mech connected via the hopper Copyright Innovative Technology Ltd 2012 GA401-5... -
Page 21: Table 12 - Essp Example For The Smart Hopper With Coin Mech Connected Separately
Currently dispensed 0020 > POLL < OK < DISPENSED, 28 00 00 00 Dispense value of 0040 completed > POLL < OK Table 12 – eSSP example for the SMART hopper with coin mech connected separately Copyright Innovative Technology Ltd 2012 GA401-5... -
Page 22: Appendix E - Parts List
The following parts are available as spares PA417 – SMART Hopper Base plate PA415 – SMART Hopper Lid Assembly CN384 – SMART Hopper CCT interface cable CN385 – SMART Hopper eSSP interface cable CN389 – SMART Hopper Power cable PA650 – Lock MC211 –... -
Page 23: Revision History
Pending protecting this product. If you require further details please contact the factory. Innovative Technology is not responsible for any loss, harm, or damage caused by the installation and use of this product. This does not affect your local statutory rights. If in doubt please contact Innovative Technology for details of any changes.
