SMART Coin System Quick Start and Configuration Guide
2.1 Detaching SMART Coin Feeder
The below pictures highlight the button location to detaching the different parts.
1. The Feeder can be detached from the Hopper pulling up the button.
2. Then remove the Feeder by reversing the process of attaching.
3. Push the Feeder back until it stops and lift the Feed from the Hopper.
1
2
Copyright © Innovative Technology Ltd 2014
3
GAXXXX-01
6
