- Page 1 SMART Coin System QUICK START CONFIGURATION GUIDE...
-
Page 2: Table Of Contents
SMART Coin System Quick Start and Configuration Guide SMART Coin System Quick Start and Configuration Guide INTRODUCTION ASSEMBLY Detaching SMART Coin Feeder Baseplate Mounting Requirements Fit the payout nozzle to the SMART Coin System Opening the SMART Coin System CONNECTORS AND PINOUTS Connections Operational Connection CONFIGURATION... - Page 3 SMART Coin System Quick Start and Configuration Guide Flash Fault Codes MAINTENANCE Cleaning Disk Removal Clearing a Jam FREQUENTLY ASKED QUESTIONS DIARY OF CHANGES Copyright © Innovative Technology Ltd 2014 GAXXXX-01...
-
Page 4: Introduction
This manual is intended to help with first setup and installation of the SMART Coin System. This section contains the essential information that a user needs to quickly assemble and configure the SMART Coin System ready for installation into the host machine or for testing on the bench. Copyright © Innovative Technology Ltd 2014... -
Page 5: Assembly
2. Slide the Feeder forward until it locks securely in place. 3. Slide the now assembled SMART Coin System on to the base plate the latch will lock the SMART Coin System in to place. Copyright © Innovative Technology Ltd 2014... -
Page 6: Detaching Smart Coin Feeder
SMART Coin System Quick Start and Configuration Guide 2.1 Detaching SMART Coin Feeder The below pictures highlight the button location to detaching the different parts. 1. The Feeder can be detached from the Hopper pulling up the button. 2. Then remove the Feeder by reversing the process of attaching. -
Page 7: Baseplate Mounting Requirements
SMART Coin System Quick Start and Configuration Guide 2.2 Baseplate Mounting Requirements Ensure that the mounting position and note exit hole meets the dimensional requirements as shown below (all dimensions are in millimetres mm): The coins fall from the cashbox exit chute and are intended to be caught in the host machine cashbox. -
Page 8: Fit The Payout Nozzle To The Smart Coin System
2.3 Fit the payout nozzle to the SMART Coin System Place nozzle hooks in to the Hopper with Feeder removed. Then push down on the Nozzle it clip in to place. -
Page 9: Opening The Smart Coin System
SMART Coin System Quick Start and Configuration Guide 2.4 Opening the SMART Coin System The SMART Coin System and be opened via the front latch. Take care during opening any loose coins not captured by the disk will be free to fall once the SMART Coin System is separated. -
Page 10: Connectors And Pinouts
3 Connectors and Pinouts 3.1 Connections There is only one connecting plug on the SMART Coin System for use by the host. It is located on the rear of the baseplate please use the connector labelled SSP. The CCT is legacy connection for use when the hopper is used in the SMART Hopper configuration for attaching external ccTalk coin accepter. - Page 11 SMART Coin System Quick Start and Configuration Guide When in operational mode (in a machine) the only connector available is the 8 way connector on the baseplate. Information Power (+V & Ground) is always required on pins 1 Only use the 8 way and 2 of the 4 way connector highlighted 24volts.
-
Page 12: Configuration
SMART Coin System Quick Start and Configuration Guide 4 Configuration The SMART Coin System does not use DIP switches to configure the unit – configuration and setting is carried out by use of a Configuration Button on the front of the SMART Coin System body (below/left of the Led cluster):... -
Page 13: Flash Counts (Interface Type)
Trusted Mode The SMART Coin System leaves the factory pre-set to at least one currency and one interface so that it is ready for immediate installation. The dataset and interface used are shown on the label fixed to the back of the SMART Coin System. -
Page 14: Programming And Dataset Loading
For programming and loading a new dataset in some cases it may be possible to connect to the unit using the USB connectors on the SMART Coin System. These connections are NOT for operational use. The 8 way connector should be used at all times. -
Page 15: Technical Specifications
Inputs are pulled up internally to 5V. They should be driven by an open collector in the host machine, which will pull the SMART Coin System input low when required. Outputs are open collector which will pull the host input low when required. -
Page 16: Dimensions
SMART Coin System Quick Start and Configuration Guide 6.3 Dimensions 6.4 Outline Dimensions 6.5 Mounting Face Dimensions Copyright © Innovative Technology Ltd 2014 GAXXXX-01... -
Page 17: Mounting Screws
The SMART Coin System has inbuilt fault detection facilities. If there is a configuration or other error, the SMART Coin System will flash in a particular sequence; a summary of the Flash Codes for the SMART Coin System is shown below. -
Page 18: Maintenance
SMART Coin System Quick Start and Configuration Guide 8 Maintenance 8.1 Cleaning Do not use solvent based cleaners such as alcohol, petrol, methylated spirits, white spirit or PCB cleaner. Using these solvents can cause permanent damage to the unit; Only use a mild detergent. -
Page 19: Disk Removal
A T30 Screwdriver will be required. Once removed the screw will be held captive inside the hole. Open the SMART Coin System using the catch on the front of the Feeder. With the screw detached the can be removed. -
Page 20: Clearing A Jam
The SMART Coin System has been designed to minimise any performance variation over time. Much of this is achieved by careful hardware and software design. CLEARING A JAM On the unlikely event of a coin jamming within the SMART Coin System, follow the steps below 1. Power off 2. -
Page 21: Frequently Asked Questions
Smart Coin System (Please see Section 5.1). f. How do I put my Smart Coin System in to DES Trusted mode? The SMART Coin System can be put in to DES trusted mode by following Section 3.3 Copyright ©... -
Page 22: Diary Of Changes
SMART Coin System Quick Start and Configuration Guide MAIN HEADQUARTERS Innovative Technology Ltd Derker Street – Oldham – England - OL1 4EQ Tel: +44 161 626 9999 Fax: +44 161 620 2090 E-mail: support@innovative-technology.co.uk Web site: www.innovative-technology.co.uk AUSTRALIA support@innovative-technology.com.au BRAZIL suporte@bellis-technology.com.br...
