Unit Specifications; Scadadroid Models; Physical Characteristics - Reonix Automation SCADADroid R2 Technical User's Manual

SCADADroid Models

Catalog
SCADAdroid R2
SCADAdroid R2-NM

Physical Characteristics

Inputs:
8 digital inputs
Input Power: USB (5 VDC), 1 amp
12-24 VDC, 1 amp
With the default hardware configuration, the inputs are activated in the following
conditions:
1. Grounding of the pin.
2. Applying 20-24V.
In terms of thresholds:
0 - 1V: activated
1V - 6V : deactivated
6V-20V: undefined
20V-24V: activated
The inputs can be used with:
Open collector outputs to ground (no external supply)
Relays to ground (no external supply)
Switches to ground (no external supply)
Relay to 24V
Switch to 24V
5V TTL logic
Note: It cannot be used with 24V 'logic' outputs
Enclosure:
SCADADroid is designed to be mounted in an enclosure. For Hazardous areas,
the SCADADroid is required to be mounted in a Type 1, Type 4, or Type 4X enclosure
depending on end application environment.
6
The Device
Description
Standard model with cell modem, 8 digital inputs, 1 relay
output, Ethernet connection with VPN remote capability.
Ethernet connection only, no cell modem installed, 8 digital inputs,
1 relay output, Ethernet connection with VPN remote capability.
Mounting:
Dimensions: 6.5 cm x 7 cm x 12 cm

Unit Specifications

DIN rail mounted
Note:
The DIN rail used for mounting the
module shall be bonded to ground
