Register Mapping

The SCADADroid is configured to map I/O Alarms, Modbus Alarms, Modbus Client and Modbus
Connection Loss Alarms, with the registers 1 to 1000. The first 8 registers are mapping with the
physical inputs, source of 1-8 for register 1-8 respectively. The SCADADroid assumes the role of
Modbus Slave in the network, using port 502.
Register:
Type:
The type of Alarm that you want mapped (I/O Alarm, Modbus Alarm, Modbus
Client).
I/O Alarm:
type the alarm ID. It is enable is you selected on type I/O Alarm.
Modbus Alarm:
type the alarm ID. It is enabled if you selected it under Type 'Modbus Alarm'.
IP Address:
enabled if you selected it under Type 'Modbus Client'. The SCADADroid must be on
the same subnet as a device in order to communicate with it.
Register Address:
mapped. It is enabled if you selected it under Type 'Modbus Client'.
28
Setting Up The R2
Register of the SCADADroid that you want to link or map.
Choose a digital input alarm that you want mapped to the register or
Choose a Modbus Alarm that you want mapped to the register or
Choose the IP address of Modbus Client that you want mapped. It is
Choose the register address of the Modbus Client that you want
