Reonix Automation R2A+ Quick Start Manual

04
Configure Ethernet Settings
The LAN settings are for the physical Ethernet port.
If you are not using this function, it can be skipped. If
a gateway is configured in the LAN Settings. The unit
will use this path to connect with the Internet.
05
Configure Cellular Settings
The cellular settings are for the SIM card and cell
modem in the unit. If the cellular network is not being
used or If your SIM card is text and voice only, skip this
step. The only parameter that needs to be configured
is the APN name. This setting will be dependent on
your SIM card's cellular provider. Contact the cellular
provider for your SIM card's APN.
At a minimum, if you are using a cell modem, the cell
modem type must appear, and the service provider
field should appear if you have a SIM card. A reading
of -113dbm means the SCADADroid® can detect no
cellular coverage, despite a functioning SIM.
06
Configure Email Settings
You must configure the email information service to
send and receive email notifications. If you are not
using this function, it can be skipped. Contact your
email provider, if needed.
username@gmail.com
Email address:
IMAP or POP3
Incoming mail server type:
imap.gmail.com or pop.gmail.com
Incoming mail server (POP3/IMAP):
993 or 995
Incoming mail server port (IMAP/POP3):
If delete is selected all retrieved mail will
Keep mail on server:
be deleted. Use only if email account
is dedicated to SCADADroid®.
smtp.gmail.com
Outgoing mail server (SMTP):
587
Outgoing mail server port (SMTP):
username@gmail.com
User:
Your password
Password:
It shows the last incoming mail time.
Last incoming check:
Show the status of the last email checked.
Last incoming status:
07
Confirm Connectivity
Navigate to the system page by clicking on the Tools
page on drop-down from the System tab located
right below the upper SCADADroid® banner. Send
yourself an email, SMS, and voice call to confirm
connectivity.
The SCADADroid® has an input simulation feature.
On the "STATUS" tab, ensure you turn off simulation
by toggling the Disable Input Simulation button.
Disable Input Simulation
Otherwise, the unit will not detect physical inputs
changes.
Tel: (587) 351-5554
Toll Free: (855) 886-8506
E-mail: info@reonix.com
For further instructions, including instructions
on how to set up shifts, add contacts, and
add alarms, please refer to the user manual
and the set-up manual. There are also
detailed instructions on the use of Modbus,
MQTT, and reporting functions in these
manuals. The manual can be found at:
www.reonix.com/downloads
There are also support videos available at:
www.reonix.com/product-support-videos
R2A+ Alarm Dialer
QUICKSTART
GUIDE
www.reonix.com
Tools Required:
Philips screwdriver (small)
PPE (Recommended):
Safety gloves while removing
and replacing the top plate
Form: RAI-SD-013
Issue Date: May 12, 2019
Revision Date: Apr 26, 2020
Revision Number: 4
