- Page 1 User Manual WINIX AIR PURIFIER Model Please read and follow all safety rules and instructions Use & Care in this manual before operating. Guide The product warranty is printed on the back of this guide, so please keep it in a safe place for future use.
-
Page 2: Table Of Contents
WHERE TO USE INSTALLING THE FILTERS SAFETY AND CAUTIONS INITIAL OPERATION AUTO AND SLEEP MANUAL MODE, TIMER AND PLASMAWAVE CHILD LOCK, AIR QUALITY LED WINIX SMART FILTER CARE PARTICLE SENSOR CARE CLEANING CARE FREQUENTLY ASKED QUESTIONS UNIT SPECIFICATIONS PRODUCT WARRANTY... -
Page 3: 5-Stage Air Purification
5-STAGE AIR PURIFICATION PlasmaWave non-removable Cleancel™ (Anti-microbial coated) True HEPA lter replaceable (CD) Coated Deodorization Carbon lter replaceable Pre- lter washable User Manual Model • Please read and follow all safety rules and instructions Use & Care in this manual before operating. Guide •... -
Page 4: Controls
CONTROLS Air Outlet Vent Light Sensor Timer Indicator Reset Button Detects the amount of After replacing a lter, If timer has been set, ambient light within the LED light Indicates press the RESET button the environment, to the set time of operation. for at least 5 seconds. -
Page 5: Where To Use
WHERE TO USE Allow 30 ~ 46 cm. of space between TVs, radios, and other electronic products electromagnetic interference from certain electronics may cause product malfunction. Place indoors away from direct sun light direct exposure may cause product malfunction or failure. Only place on hard, flat surfaces flimsy or slanted surfaces may result in abnormal noise and vibrations. -
Page 6: Installing The Filters
INSTALLING THE FILTERS This product comes with all of the required filters. The protective plastic wrap must be removed from the filters before use. Operating the unit without removing the plastic wrap may result in product failure. Unplug and make sure the unit is turned off before installing filters. The unit will automatically power off when front panel is opened. - Page 7 INSTALLING THE FILTERS Install the filters until they fit securely in True HEPA place. lter with Filters must be installed in this order: Cleancel™ True HEPA filter with Cleancel™ (rear) CD Carbon CD Carbon filter (middle) lter Pre-filter (front) Pre- lter To install the pre-filter, insert bottom tabs into the slots on either side of the lower part of the unit, then rotate upward to insert the...
-
Page 8: Safety And Cautions
SAFETY AND CAUTIONS Before operating this equipment, carefully read and follow these safety cautions and instructions to avoid damage and ensure safe use. Ensure filters are inserted before running unit running unit without filters can shorten the units life and cause electric shock or injury. Be sure foreign objects are NOT inserted into the vents on the unit objects can include pins, rods, and coins. -
Page 9: Initial Operation
INITIAL OPERATION Insert the unit plug into an electrical outlet. The Control Panel lights will turn on and off. Press the ‘Power’ button. During the first 4 minutes of power up, the Air Quality light Note will flash as the Smart Sensors measure the air quality in the environment, after which normal operation will begin. -
Page 10: Auto And Sleep
AUTO AND SLEEP Every time the Mode button is pressed, the Mode LED light will cycle through the settings. (Auto, Sleep, Low, Medium, High, Turbo) 1. Auto Mode Enables Auto operation based on the unit's air quality Smart Sensors. Press the Mode button to select Auto mode. The mode LED light will indicate when ‘Auto’... -
Page 11: Manual Mode, Timer And Plasmawave
Every time the Timer button is pressed the Timer LED light will cycle through the settings. (1hr, 4hr, 8hr, [NO TIMER]). The WINIX SMART app will display how much time is Note remaining on the timer. 5. PlasmaWave By default, PlasmaWave is enabled whenever the unit is powered on. -
Page 12: Child Lock, Air Quality Led
CHILD LOCK, AIR QUALITY LED 6. Child Lock This feature prevents children from tampering with the control panel. Press and hold the Plasma/Child Lock button for 3 seconds to enable or disable the feature. 3 seconds When the Child Lock indicator is lit, the feature is enabled. -
Page 13: Winix Smart
Note iOS (6.0 or later recommended - iPhone 4S or later) Before connecting to Smart Home A Wi-Fi wireless router must be installed within range of the air purifier to use WINIX SMART. Ensure Wi-Fi router matches the following specifications;... - Page 14 WINIX SMART Setup Download the WINIX SMART app on your device. available via Google Play store or iTunes App store. Run the app and follow the setup guide to connect your device to the unit. Select "New Unit" and choose ZERO+ WiFi to connect to this model.
-
Page 15: Filter Care
FILTER CARE 1. Changing Filters When the Check Filter indicator LED is on, it is time to replace both the True HEPA filter with Cleancel™ and CD Carbon filters. When to When to Filter Indicator Light service replace Clean once every Pre-filter none Permanent... - Page 16 CD Carbon filter and then the True HEPA filter with Cleancel™ by pulling on the numbered tags at the top of each filter. For optimal performance, only genuine Winix filters should NOTICE be used with this unit. English ZERO+ WiFi...
- Page 17 FILTER CARE 3. Filter Assembly and Replacement Filters should be re-installed in the reverse order of their removal. Insert the replacement True HEPA filter with Cleancel™ (rear) True HEPA CD Carbon filter (middle) lter with Cleancel™ Remove the protective plastic wrap from new filters.
- Page 18 FILTER CARE 4. Cleaning the Pre-filter Intervals between filter cleanings may vary depending on the air quality. Use a vacuum cleaner or soft brush to clean the Pre-filter. If it is excessively dirty, wash with room temperature water. Use only water, do not use volatile substances such as alcohol or acetone.
-
Page 19: Particle Sensor Care
PARTICLE SENSOR CARE Particle Sensors Care For optimal performance of the Particle Sensor, which detects airborne dust and ultrafine particles, clean it every two months. Clean it more frequently when the unit is running in a place with high dust levels. Open the Particle Sensor cover. -
Page 20: Cleaning Care
CLEANING CARE Cleaning the exterior and interior Cleaning the exterior Wipe with a soft damp cloth using room temperature water. Afterwards, wipe it down with a clean dry cloth. For optimal performance, clean the front panel 1-2 times a month. Cleaning the interior Open the front panel and clean the interior with a vacuum cleaner. -
Page 21: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take It does not turn on at all. Is there a power outage? Check to see if other lights and electrical equipment are working and try again. It doesn’t work in Auto mode. Has Auto mode been selected? Press the Mode button until Auto mode is selected. - Page 22 FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take The power plug and outlet feel hot. Is the plug securely plugged in? Make sure the plug is properly plugged into the outlet. There is a strange smell. Is it being used in a place with a lot of smoke, dust, or odors? Clean the air intakes on the front sides of the unit and clean the pre-filter.
-
Page 23: Unit Specifications
UNIT SPECIFICATIONS Model Name ZERO+ WiFi (AZPU373-HWE) Power Voltage AC220 - 240V, 50 / 60Hz Power Rate 90 W Max Room Capacity 120 m Dimensions 415 mm(W) x 245 mm(D) x 600 mm(H) Weight 8.5 kg Replacement Filter Pre-Filter The exterior, design, and product specifications may be changed to improve product performance without prior notice. -
Page 24: Product Warranty
PRODUCT WARRANTY This product is manufactured under stringent quality control and inspections. Warranty void if product failure is a result of negligence or misuse by the consumer, shipping and service fees may be incurred even during the warranty period. The warranty must be presented upon bringing the product for service. Store the warranty in a safe place, as it cannot be reissued. - Page 25 2610-0169-00 Rev.00 Contact your local dealer for product WWW.WINIX.COM/EU related inquiries and customer service...
