- Page 1 User Manual WINIX AIR PURIFIER ZERO-N Model (AZNU230-HWE, AZNU230-HWB) ˍ Please read and follow all safety rules and instructions Use & Care in this manual before operating. Guide ˍ The product warranty is printed on the back of this guide, so please keep it in a safe place for future use.
-
Page 2: Table Of Contents
CONTENTS 3-STAGE AIR PURIFICATION · · ············································ 3 CONTROLS ····························································· 4 WHERE TO USE ························································· 5 INSTALLING FILTERS ···················································· 6 SAFETY AND CAUTIONS · · ·············································· 10 INITIAL OPERATION ···················································· 11 AUTO & SLEEP ························································· 12 MANUAL & AIR QUALITY INDICATOR ···································· 13 FILTER CARE ·... -
Page 3: 3-Stage Air Purification
(This product is suitable for 220V ~ 240V only.) True HEPA lter Carbon lter Fabric Pre- lter User Manual WINIX AIR PURIFIER Model ZERO-N (AZNU230-HWE, AZNU230-HWB) ㆍPlease read and follow all safety rules and instructions Use & Care in this manual before operating. -
Page 4: Controls
CONTROLS Outlet Vent Fan Speed Indicator ① Indicates the current fan speed. Change Filter Indicator ② LED light indicates when it is time to change the filter. Reset Button ③ After replacing a filter, press the RESET button for at least 5 seconds. Air Quality Indicator ④... -
Page 5: Where To Use
WHERE TO USE Allow 30 - 45 cm. of space between TVs, radios, and other electronic products electromagnetic interference from certain electronics may cause product malfunction. Place indoors away from direct sun light direct exposure may cause product malfunction or failure. Only place on hard, flat surfaces flimsy or slanted surfaces may result in abnormal noise and vibrations. -
Page 6: Installing Filters
INSTALLING FILTERS This product comes with all required filters. The protective plastic wrap must be removed from the filter before use. ※ Operating the unit without removing the plastic wrap may result in product failure. ※ Unplug and make sure the unit is turned off before installing filter. Remove the front panel by pressing down ①... - Page 7 INSTALLING FILTERS Remove filters from protective plastic wrap. ④ ˍ Operating the unit without removing filters from plastic wrap may cause abnormal noise, deformation, or fire as a result of overheating. After removing the packing vinyl of the ⑤ filter, insert the carbon filter into the filter case.
- Page 8 INSTALLING FILTERS Ture HEPA filter → Filter case in order, ⑧ pushing it in close to the back of the product. ⑨ After inserting both ends of the fabric pre filter, press both sides of the top to close it. English ZERO-N...
- Page 9 ※ Use a vacuum cleaner or soft brush to lightly remove dust from the fabric filter. If deeper cleaning is required, place the filter under running water or wash it with synthetic detergent. To purchase replacement FILTER Winix filters: this unit is compatible contact your local dealer with this filter...
-
Page 10: Safety And Cautions
SAFETY AND CAUTIONS Before operating this equipment, carefully read and follow these safety cautions Ensure filters are inserted before running unit running unit without filters can shorten the units life and cause electric shock or injury. Be sure foreign objects are NOT inserted into the vents on the unit objects can include pins, rods, and coins. -
Page 11: Initial Operation
INITIAL OPERATION Insert the power cord into an electrical ① outlet. Press the ‘Power’ button. ② ˍ During the first 30 seconds of power up, the Air Quality NOTE Indicator will cycle through Blue, Amber and Red colors. The Particle Sensors take approximately 30 seconds to gauge the air quality in the environment, after which normal operation will begin. -
Page 12: Auto & Sleep
AUTO & SLEEP 1. Auto Mode Enables auto operation based on the unit's air quality Particle Sensor. Press the Fan speed (UP/DOWN) button to ① select Auto mode. ˍ The LED ‘Auto’ light will indicate when Auto mode is activated, and operation will begin. -
Page 13: Manual & Air Quality Indicator
MANUAL & AIR QUALITY INDICATOR 3. Manual Mode (setting fan speed) Users can optative to manually set the fan speed to Low, Medium, High. Press the Fan Speed button to set the ① desired fan speed. ˍ When Manual Mode is selected, Auto Mode is automatically NOTE disabled. -
Page 14: Filter Care
※ Use a vacuum cleaner or soft brush to lightly remove dust from the fabric filter. If deeper cleaning is required, place the filter under running water or wash it with synthetic detergent. To purchase replacement FILTER Winix filters: this unit is compatible contact your local dealer with this filter... - Page 15 FILTER CARE 2. Resetting The Unit After replacing the filters, turn the power ① back on and then use a thin object, such as a paper clip, to press the RESET switch for 5 seconds. 3. Cleaning the Fabric Pre-filter Intervals between filter cleaning may vary depending on the air quality. Use a light brush to clean if the filter’s ①...
-
Page 16: Particle Sensor Care
PARTICLE SENSOR CARE Particle Sensors Care For optimal performance of the Particle Sensor, which detects airborne dust and ultrafine particles, clean it every two months. Clean it more frequently when the unit is running in a place with high dust levels. ①... -
Page 17: Cleaning Care
CLEANING CARE 1. Cleaning the Exterior & Interior Wipe with a soft damp cloth using room ① temperature water. Afterwards, wipe it down with a clean dry cloth. ˍ To keep unit in peak condition, clean every 1-2 months. Take off the fabric pre-filter that is fastened ②... -
Page 18: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is the plug securely attached to the outlet? - Make sure the outlet has power going to it, and ensure the plug is secured. It does not turn on at all. ˍ... - Page 19 FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take ˍ Is it being used in a place with a lot of smoke, dust, or odours? There is a strange - Clean the air intakes on either side and clean smell. the Fabric filter.
-
Page 20: Unit Specifications
UNIT SPECIFICATIONS Model Name ZERO-N (AZNU230-HWE, AZNU230-HWB) Power Voltage AC 220 - 240 V, 50 / 60 Hz Power Rate 30 W Max Room Capacity 45 m Dimensions 350 mm(W) x 207 mm(D) x 470 mm(H) Weight 6.2 kg Replacement Filter Filter R / item : 1712-0088-00 ※... -
Page 21: Product Warranty
PRODUCT WARRANTY The terms of the warranty are as follows. This product is manufactured under stringent quality control and inspections. Warranty void if product failure is a result of negligence or misuse by the consumer, shipping and service fees may be incurred even during the warranty period. The warranty must be presented upon bringing the product for service. - Page 22 2610-0174-00 Rev.00 Contact your local WWW.WINIX.COM/EU dealer for product related inquiries and customer service...
