- Page 1 WINIX ZERO 4 AIR PURIFIER USER MANUAL SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
USER MANUAL WINIX ZERO 4 AIR PURIFIER CONTENTS CONTENTS ......................2 4-STAGE AIR PURIFICATION ................3 CONTROLS ......................4 WHERE TO USE .....................5 INSTALLING FILTERS ....................6 SAFETY AND CAUTIONS ..................8 INITIAL OPERATION ....................9 AUTO & SLEEP .....................10 MANUAL & TIMER ....................11 PLASMAWAVE &... -
Page 3: 4-Stage Air Purification
USER MANUAL WINIX ZERO 4 AIR PURIFIER 4-STAGE AIR PURIFICATION Particle sensor PlasmaWave Light sensor Control Panel / Display Panel Power cord with plug (This product is suitable Front panel for 220-240V only.) Unit User Manual True HEPA Page 3... -
Page 4: Controls
USER MANUAL WINIX ZERO 4 AIR PURIFIER CONTROLS Air Outlet Vent Timer Indicator PlasmaWave Indicator Indicates whether If timer has been set, the PlasmaWave is enabled or LED light indicates the set time of operation. disabled. Mode Button Fan Speed Indicator... -
Page 5: Where To Use
USER MANUAL WINIX ZERO 4 AIR PURIFIER WHERE TO USE Allow 30 - 45cm of space between TVs, radios, and other electronic products electromagnetic interference from certain electronics may cause product malfunction. Place indoors away from direct sun light direct exposure may cause product malfunction or failure. -
Page 6: Installing Filters
USER MANUAL WINIX ZERO 4 AIR PURIFIER INSTALLING FILTERS This product comes with all required filters. The protective plastic wrap must be removed from the filter before use. • Operating the unit without removing the plastic wrap may result in product failure. - Page 7 USER MANUAL WINIX ZERO 4 AIR PURIFIER Install the filters until they fit securely in place. Filters must be installed in this order: 3 True HEPA Filter (rear) 2 Deodorization filter (middle) 1 Pre-filter (front) • To install the Pre-filter, insert bottom tabs into the...
-
Page 8: Safety And Cautions
USER MANUAL WINIX ZERO 4 AIR PURIFIER SAFETY AND CAUTIONS Before operating this equipment, carefully read and follow these safety cautions Ensure filters are inserted before running unit running unit without filters can shorten the units life and cause electric shock or injury. -
Page 9: Initial Operation
USER MANUAL WINIX ZERO 4 AIR PURIFIER INITIAL OPERATION Insert the power cord into an electrical outlet. Press the ‘Power’ button. NOTE : During the first 30 seconds of power up, the Air Quality Indicator will cycle through Blue, Amber and Red colors. -
Page 10: Auto & Sleep
USER MANUAL WINIX ZERO 4 AIR PURIFIER AUTO & SLEEP Auto Mode Enables auto operation based on the unit’s air quality Particle Sensor. Press the Mode button to select Auto mode. • The LED ‘Auto’ light will indicate when Auto mode is activated, and operation will begin. -
Page 11: Manual & Timer
USER MANUAL WINIX ZERO 4 AIR PURIFIER MANUAL & TIMER Manual Mode (setting fan speed) Users can opt to manually set the fan speed to Low, Medium, High, or Turbo. Press the Fan Speed button to set the desired fan speed. -
Page 12: Plasmawave ® & Air Quality Indicator
USER MANUAL WINIX ZERO 4 AIR PURIFIER PLASMAWAVE & AIR QUALITY INDICATOR ® PlasmaWave ® By default, PlasmaWave is enabled whenever the unit is powered on. ® Press the Plasmawave button, when the unit is on, to enable or disable this feature. -
Page 13: Filter Care
USER MANUAL WINIX ZERO 4 AIR PURIFIER FILTER CARE Know The Filters When the Check Filter indicator LED is on, it is time to replace both the True HEPA and Deodorization filters. Filter Indicator Light When to service When to replace... - Page 14 • Operating the unit without removing filters from plastic wrap may cause abnormal noise, deforma- tion, or fire as a result of overheating. NOTICE : • For optimal performance, only Winix filters should be used with this unit. Page 14...
- Page 15 USER MANUAL WINIX ZERO 4 AIR PURIFIER Replacing Filters Insert the True HEPA Filter first, then the Deodor- ization filter. Insert the Pre-filter. • Insert bottom tabs of the Pre-filter into the slots on either side of the lower part of the unit, then rotate...
- Page 16 USER MANUAL WINIX ZERO 4 AIR PURIFIER Cleaning the filter Intervals between filter cleaning may vary depending on the air quality. Use a vacuum cleaner or soft brush to clean the Pre-filter. If it is excessively soiled, rinse in room temperature water.
-
Page 17: Particle Sensor Care
USER MANUAL WINIX ZERO 4 AIR PURIFIER PARTICLE SENSOR CARE Particle Sensors Care For optimal performance of the Particle Sensor, which detects airborne dust and ultrafine particles, clean it every two months. Clean it more frequently when the unit is running in a place with high dust levels. -
Page 18: Cleaning Care
USER MANUAL WINIX ZERO 4 AIR PURIFIER CLEANING CARE Cleaning the Exterior & Interior Wipe with a soft damp cloth using room tempera- ture water. Afterwards, wipe it down with a clean dry cloth. • To keep unit in peak condition, clean every 1-2 months. -
Page 19: Frequently Asked Questions
USER MANUAL WINIX ZERO 4 AIR PURIFIER FREQUENTLY ASKED QUESTIONS Problem Check / Actions to take It does not turn on at all. • Is the plug securely attached to the outlet? • Make sure the outlet has power going to it, and ensure the plug is secured. -
Page 20: Safety Instructions
WINIX ZERO 4 AIR PURIFIER SAFETY INSTRUCTIONS Thank you for purchasing a Winix air purifier. This product is for household use only. IMPORTANT CAUTIONS FOR USING YOUR AIR PURIFIER WARNING : Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or fire. -
Page 21: Product Warranty
USER MANUAL WINIX ZERO 4 AIR PURIFIER PRODUCT WARRANTY Product Name Air Purifier Model Name AUS-1050AZBU Purchase Date Warranty period Two (2) years Place of purchase Place of purchase Tel. Address Customer Name Tel. • After purchase, be sure to complete all of the above information.
