CombiMaster 230V Series – User and Installation Manual

4 INSTALLATION

4.1

Unpacking

The delivery includes:
•
CombiMaster
•
1× Temperature sensor
•
1× MasterBus terminator
•
1× Drop cable CZone/MB (1m)
•
Mounting bracket
•
User and installation manual
After unpacking, check the contents for possible damage. Do not use the product if it is damaged. If in doubt, contact your
supplier.
Check from the identification label (see section 2.4) whether the battery voltage is the same as the nominal output voltage of
the CombiMaster (e.g. 24V battery set for a 24V battery charger).
Also check that the AC output voltage and output power of the CombiMaster complies with your system and loads.
4.2

Location

•
The CombiMaster is designed for indoor use only.
•
Ambient temperature: -25°C to 60°C, power derating above 40°C.
•
Humidity: 5-95% non-condensing
•
Surface wall mount (vertically, IP 23) or tabletop (horizontally, IP 21)
•
Do not expose the CombiMaster to excessive dust, aggressive environments, ammonia or salt.
•
Do not operate the CombiMaster in a closed-in area or restrict ventilation in any way.
•
The CombiMaster requires a minimum of 100mm/4" of clearance on every side to ensure safety and proper ventilation.
•
If the CombiMaster is installed in the immediate vicinity of living areas, take into account that the fan of the CombiMaster
can produce noise when operating.
•
If the CombiMaster is installed in a CZone or MasterBus network, take the network powering into consideration.
•
Although the CombiMaster fully complies with all applicable EMC limits, it may still cause harmful interference to radio
communication equipment. If such interference appears, it is recommended to increase the separation between the
CombiMaster and the equipment, to relocate the receiving antenna or to connect the equipment to a circuit different from
that to which the CombiMaster is connected.
•
Never place the CombiMaster directly above the battery being charged, as gases from battery will corrode and damage the
CombiMaster.
4.3

Batteries

Model
12V/2000VA-60A
24V/2000VA-40A
12V/3000VA-100A
24V/3000VA-60A
Recommended battery capacity
120 − 600 Ah
80 − 400 Ah
200 − 1000 Ah
120 − 600 Ah
Minimum based on Mastervolt Gel batteries. If
connecting batteries of a different manufacturer
make sure the manufacturer's
recommendations are met.
