Network Specific — PROFINET
13.8

LED Indications

Changes has been made regarding the specification of the LED indications. See tables below
for differences.
Fig. 6
13.8.1 Network Status LED (LED1[A..B])
LED State
Off
Green
Green, 1 flash
Green, 3 flashes
Green, cont. flash
Red
Red, 1 flash
Red, 2 flashes
Red, 3 flashes
®
Migrating from Anybus CompactCom
3
1
30-series 40-series
Offline Offline
Online (RUN) Online (RUN)
-
Online (STOP)
-
Identify
-
Online (STOP)
Fatal event Fatal event
-
Station Name error
-
IP address error
-
Configuration error
®
™ 30 to Anybus CompactCom
4
Comments
- No power- No connection with IO
controller
Connection with IO controller estab-
lished, IO controller in Run state
Connection with IO controller estab-
lished, IO controller in STOP state or
IO data bad, IRT synchronization not
finished
Flashing 3 times (1Hz) continuously
to identify slave (DCP_Identify).
Connection with IO controller estab-
lished, IO controller in STOP state
Major internal error (this indication is
combined with a red module status
LED)
Station name not set
IP address not set
Expected Identification differs from
Real Identification.
™ 40 Design Guide
32 (38)
2
SCM-1202-043 1.1
