Machine description – quick overview
Description
0
Cover of the wire spool
Wire spool holder
Protective cap
Cover for the wire feed mechanism and other operating elements.
Depending on the machine series, additional stickers with information on the
replacement parts will be located on the inside.
Wire feed unit
Operating mode changeover switch
•
Position KORREKTUR
•
Position MANUELL
The setting determines the wire speed operating mode at the wire speed rotary dial.
Changeover switch, remote control on/off
ON
Set the welding performance via the remote control
OFF
Set the welding performance via the machine control
Figure 4-3
