2.2 Installation for Motor & Wheel
M3*30 Screw
Installation Instruction: The motor fixing support passes through the car chassis, and fixed with
screw and nut, then the wheels are mounted on the motors
2.3 Installation for Battery Box
M3*8mm
Screw
Installation Instruction: Install the battery box on the bottom of car chassis, fixed with the
M3*8mm screw and nut.
2.4 Installation for Copper Pillars
M3*45mm Copper
pillar
M3*40mm
Copper pillar
Design Sketch (After Installation)
Design Sketch (After Installation)
M3*8mm
Copper pillar
M3*6mm
Screw
Design Sketch (After Installation)
3
