User Manual
WISE-1530
M2.COM WIFI/BLE IoT Node
OEM/Integrators Installation
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WISE-1530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech WISE-1530

Summary of Contents for Advantech WISE-1530

  • Page 1 User Manual WISE-1530 M2.COM WIFI/BLE IoT Node OEM/Integrators Installation Manual...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such func- tion is available. FOR MOBILE DEVICE USAGE (>20cm/low power) Radiation Exposure Statement: WISE-1530 User Manual...
  • Page 4 (2) this device must accept any interference received, including interference that may cause undesired operation. 低功率電波輻射性電機管理辦法  第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性及功能。  第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指 依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學 及醫療用電波輻射性電機設備之干擾。 模組認證： 本模組於取得認證後將依規定於模組本體標示審驗合格標籤。 系統廠商應於平台上標示 「本產品內含射頻模組： 字樣。 WISE-1530 User Manual...
  • Page 5 Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately.  1 WISE-1530  1 Screw for WISE-1530  1 China RoHs Notice Optional Accessories Part No. Description 1750008001-01 Wi-Fi antenna Dipole L=141.5mm, 5dBi 2.4/5GHz...
  • Page 6 The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. WISE-1530 User Manual...

  • Page 7: Table Of Contents

    Programming................... 26 3.5.1 Debug Setting ................26 Chapter Example: WISE-1530 Demo(StartKit) Introduction ..................... 30 Detailed about WISE-1530 Demo ............30 Step by step usage guide................ 31 memory/flash usage................36 I/O Test (factory) ..................37 4.5.1 Introduction ................. 37 WISE-1530 User Manual...
  • Page 8 4.5.2 I/O Test Use WICED API............37 4.5.3 I/O Test Use SUSI API ............... 39 WISE-1530 User Manual viii...

  • Page 9: Chapter 1 Product Overview

    Chapter Product Overview...

  • Page 10: Introduction

    Introduction WISE-1530 is a wireless module integrated with ARM Cortex-M4 Processor and Wifi / BLE connectivity. This technology is the best solution for WIFI and BLE combo Applications. For example, we may use BLE to configure device and transfer mass data through wifi connectivity.

  • Page 11: Specifications

    -20 ~ 70° C Temperature Environment Operating 5% ~ 95% Relative Humidity, non-condensing Humidity Physical Dimensions 22 x 30 mm Characteristics (WxD) ThreadX v5.6, SDK 4.1.8 * Note: Frequency Band can be configurable for Japan or Korea by request. WISE-1530 User Manual...
  • Page 12 WISE-1530 User Manual...

  • Page 13: Chapter 2 H/W Installation

    Chapter H/W Installation...

  • Page 14: Board Connector

    Module input voltage: 3.3V DC-in  Connector mating force: 30N Maximum  Connector current rating: 0.5A / Power contact  Connector operation temperature range: -45 °C to +85 °C Figure 2.1 Card Edge Bevel Figure 2.2 Card Edge Outline-Topside WISE-1530 User Manual...

  • Page 15: Figure 2.3 Card Edge Outline-Backside

    Figure 2.3 Card Edge Outline-Backside Reference from PCI Express M.2 Specification Rev 1.0 (Nov 1, 2013) Section 2.3.5 Card PCB Details WISE-1530 User Manual...

  • Page 16: Module Outline

    Top Side Connector Physical Dimensions The top-side scheme has two connectors that share a common footprint but have dif- ferent stack-up requirements.  Length - 22 mm maximum including land pattern  Width - 9.1 mm maximum including land pattern WISE-1530 User Manual...

  • Page 17: Carrier Board Connection Length

    The additional increase in length is 7.05mm maximum for top-side connector to the module length.  The retention screw adds 2.75 mm maximum.  The maximum extension, including land pattern, beyond the module leading edge is 4.3 mm.  M2.COM module lengths are 30 mm and 42 mm. WISE-1530 User Manual...

  • Page 18: Carrier Board Connector Height

    The dimensions of M2.COM form factor follow the Type A 2230 -D3 M.2 module size. Hence, the carrier board connectors must choose H3.2-D3 or H4.2-D5 connector as in the following diagrams. Figure 2.7 H3.2-D3 Reference from PCI Express M.2 Specification, Revision 1.0, November 1, 2013 WISE-1530 User Manual...

  • Page 19: Wise-1530 Pin-Out Map

    WISE-1530 Pin-Out Map M2.COM STM32L443RCI6 M2.COM Signal name MCU Pin Name Signal name 3.3V MICRO_USB_HS_DP PA12 3.3V MICRO_USB_HS_D PA11 PB12 I2S_CK_MICRO I2S_WS_MICRO PC12 I2S_SD_MICRO PB14 CB_RESET_OUT# CB_PWR_ON UART3_TX (O)(0/3.3V) Connector Key Connector Key Connector Key Connector Key Connector Key Connector Key...

  • Page 20: Quick Starter Of Wise-1530

    Figure 2.8 M.2 Connector Quick Starter of WISE-1530 2.5.1 Preparing for Hardware The user needs to prepare for hardware as following:  WISE-1530, WISE-1500 and WISE-ED22.  802.11b/g/n (2.4 GHz) Wireless Access Point (AP).  PC Runs on Windows®, Mac® OS X®, and Linux®...
  • Page 21  6.SW3 on WISE-1500 Switch pin2 to decide whether running "backup to default" while device booting. "ON": enabled, "OFF": disable 7.WISE-1530 reset button, one button on WISE-1500 and the other on WISE- ED22  Drag-n-drop programming  8.Micro USB connector Serial port and debugging ...
  • Page 22 WISE-1530 User Manual...

  • Page 23: Chapter 3 Development Environment Setup

    Chapter Development Environment Setup...

  • Page 24: Overview

    Overview WISE-1530 is used Cypress's WICED® SDKs to develop Wi-Fi and BLE application. WISE-1530 SDK use C/C++ language Runs on Windows® through Eclipse®-based integrated development environment (IDE). Single installer package with support for:  Wi-Fi + Bluetooth combo solution –...

  • Page 25: Installation Of Wiced Studio

    Installation of WICED Studio The user can refer to the following steps to setup WICED Studio with WISE-1530 SDK. 3.2.1 Windows Install Download WICED-Studio-5.2.0.22-IDE-Installer.zip(https://commu- nity.cypress.com/servlet/JiveServlet/downloadBody/13651-102-1-14558/ WICED-Studio-5.2.0.22-IDE-Installer.zip) Extract the installer exe from the zip file to temp folder on your computer; do not...
  • Page 26 WISE-1530 User Manual...

  • Page 27: Copy Patch File

    When you see the Select WICED Platform page, choose the 43xxx_Wi-Fi item. You can change in "WICED Platform" in SDK toolbar as well. 3.2.2 Copy patch file Download and unzip WM-BN-BM-22_SDK_5.1.x_platform_patch.zip(http://ess- wiki.advantech.com.tw/wiki/images/c/c1/WM-BN-BM- 22_SDK_5.1.x_platform_patch_v1.2.zip) Replace the folders under WICED directory <SDK folder>\43xxx_Wi-Fi\ with patch folders. WISE-1530 User Manual...

  • Page 28: Build Source File

    Make a "Make Target" file Step1: In Make Target window click mouse right button Step2: Select New... Step3: Type "snip.gpio-WISE_1530" Field explanation: snip.gpio-WISE_1530  snip.gpio: application project name  WISE_1530: platform name, for WISE-1530 platform don't change this field WISE-1530 User Manual...

  • Page 29: Build Project

    3.3.2 Build Project Double click "Make Target" file to build project. You see below message when image is built successfully. WISE-1530 User Manual...
  • Page 30 WISE-1530 User Manual...

  • Page 31: Generate A Programming File

    Generate a Programming File It will generate three bin files in <SDK folder>\43xxx_Wi-Fi\build folder when build complete. Bootloader: waf.bootloader-NoOS-WISE_1530.bin DCT(Device Configuration Table): DCT.bin: Application: snip.gpio-WISE_1530.bin Download install J-Link(https://www.segger.com/downloads/jlink/ JLink_Windows_V616j.exe)software, we need J-Flash tool to combine three bin files for programming. WISE-1530 User Manual...

  • Page 32: Launch J-Flash

    3.4.1 Launch J-Flash 3.4.2 Open bootloader bin file WISE-1530 User Manual...

  • Page 33: Merge Dct Bin File

    3.4.3 Merge DCT bin file 3.4.4 Merge application bin file WISE-1530 User Manual...

  • Page 34: Save As A Final Bin File

    3.4.5 Save as a final bin file Programming Generate a programming file then use WISE-ED22(http://ess-wiki.advantech.com.tw/ view/WISE-ED22_User_Manual)to program WISE-1530. User can refer WISE-ED22 Drag-n-drop Programming(http://ess-wiki.advantech.com.tw/view/WISE- ED22_User_Manual#Drag-n-drop_Programming)section 3.5.1 Debug Setting Launch a serial port tool (Take Tera Term for example), then setting is as below.
  • Page 35 Press WISE-1530 reset button, the screen will show as below. WISE-1530 User Manual...
  • Page 36 WISE-1530 User Manual...

  • Page 37: Chapter 4 Example: Wise-1530 Demo(Startkit)

    Chapter Example: WISE-1530 Demo(StartKit)

  • Page 38: Introduction

     BLE and WiFi introducer WISE-1530 will try to connect to WiFi AP with default SSID and password at first. If success, WISE-1530 will Loop in WISESnail. Otherwise, BLE will be used for setting SSID and password. User can scan WISE-1530 as BLE device via mobile app.

  • Page 39: Step By Step Usage Guide

    WISE_1530 folder to <SDK folder>\43xxx_Wi-Fi\apps. Project Explorer window will appear WISE_1530 folder. You can press 'F5' to refresh if you do not see. Step 2: Create a "WISE_1530.StartKit-WISE_1530" target file and build the applica- tion. WISE-1530 User Manual...
  • Page 40 Step 3: Follow "Generate a Programming File(http://ess-wiki.advantech.com.tw/view/ WISE-1530_SDK#Generate_a_Programming_File)" to generate a bin file, then download bin file to WISE-1530. You will see below message in console screen if success. Step 4 to step 8 Please install BLE scanner app in your mobile phone.
  • Page 41 Step 6: If the connection between mobile phone and WISE-1530 is successful, you will access configuration page and select "CUSTOM SERVICE" to modify SSID and PASSWORD of WiFi AP. Step 7: Find the UUID: ACA0EF7C-EEAA-48AD-9508-19A6F6B356 for SSID char- acteristic. Press the "W" button to enter input window. Input new SSID name then press the OK button.
  • Page 42 Step 8: Find the UUID: 40B7DE33-93E4-4C8B-A876-D833B415A6CE for Pass- word characteristic then procedure as Step5. Step 9: If it succeed to access WiFi AP, WISE-1530 will get network IP. The console message is as below. WISE-1530 User Manual...
  • Page 43 Step 10: If it connect to broker and WISESnail successfully, user can see tempera- ture, humidity, GPIO1 and GPIO2 on cloud server. WISE-1530 User Manual...

  • Page 44: Memory/Flash Usage

    The WISE-1530 has 1 MBytes flash and 256 KBytes RAM. The Start kit flash and memory usage is as below. Module Flash Static RAM Adv_WiseSnail 18284 27096 Bluetooth_Embedded_Low_Energy_Stack bluetooth_low_energy 78493 9348 button_manager command_console 3688 command_console_wifi 11146 1060 DHCP_Server...

  • Page 45: I/O Test (Factory)

    I/O Test (factory) 4.5.1 Introduction The I/O Test application is a WISE-1530 I/O testing example. It's need extra I/O board(WISE-ED30) to plug in to WISE-1500. The hardware setup as below. This instance could test m2.com I/O that WISE-1530 supported(M2.COM Pinout(http:// ess-wiki.advantech.com.tw/view/MCU/WISE-1530)), include GPIO, ADC, I2C.
  • Page 46 Step 3: Create a "WISE_1530.factory-WISE_1530" target file and build the applica- tion. Download firmware to WISE-1530 then press reset button. Step 4: You will see below message in console screen if success. Input '1' to select I/ O Function Test, the screen will show I/O test items.Input 1~7 to test I/0 and 0 to return previous page.
  • Page 47 GPIO, I2C, SPI, ADC and PWM APIs. You can simple revise setting to accomplish SUSI API I/O Test. Step 1: The SUSI API I/O test source code are as below files. Step 2: Open SimpleCli.mk and change USE_SUSI_API to 1. WISE-1530 User Manual...
  • Page 48 Step 3: Double click "WISE_1530.factory-WISE_1530" target file and build the appli- cation. Then download the firmware to WISE-1530, you can see the screen that same as I/O Function Test. WISE-1530 User Manual...
  • Page 49 WISE-1530 User Manual...
