- Page 1 VAC-SIF-05 Training & Maintenance Manual Pneumatic Division CVX0260B Richland, Michigan 49083 ISSUED: July, 2013 Supersedes: November, 2012 Training & Maintenance Manual for CVX0260B Vacuum Generators...
-
Page 2: Description And Operation
Pressure A vacuum system consists the automation components connected to the vacuum port of the vacuum generator. Each CVX0260B unit consists of 2 independent vacuum generators labeled channel 1 and channel 2. Each vacuum Vacuum generator has a vacuum solenoid pilot valve, blow-off... - Page 3 Replacement Sensor MPS-V23C-NC is an NPN Sinking Sensor. When installed on the CVX0260B, the onboard electronics converts this sensor to a PNP circuit. Wiring circuit of the CVX0260B units is PNP, Sourcing. Each (P_4) vacuum generator sensor has 2 outputs. Output 1 and...
- Page 4 It is the Loss of Output Power or the Loss of Output Power state. and Input Power to the CVX0260B Vacuum Generator. The relevance to vacuum is the ability of the vacuum equipment to maintain the last output state of the control circuit.
-
Page 5: Basic Modes Of Operation
3-1/2 digit LED display Setting Button and pre-set desired value. Change setting mode and Display the measured pressure value, each set pre-set final desired value content and error code. Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... -
Page 6: Units Of Measure
VAC-SIF-05 Specifications CVX0260B Specifications Units of Measure CVX0260B Specifications The pressure sensor has an LED function that indicates the degree of pressure in the system. The units can be Media Non-lubricated Dry Air changed, but are factory set to inHg (inches of Mercury). -
Page 7: Ordering Information
M4 Spring Lock Contents Washers Mounting Screw M4x10 (4) The CVX0260B is supplied with four (4) M5 x 1 Socket Head (M5x1) Cover Mounting Screws Cap Screws to secure the unit to the optional mounting plate. (Cover Not Shown) Parker Hannifin Corporation... -
Page 8: Scheduled Maintenance
• Each CVX0260B incorporates a small filter housed on the Silencer – Periodic maintenance of the exhaust silencer may body to protect the internal components of the generator. -
Page 9: Technical Information
Part may not drop, but part present signal will change state. This may cause the PLC/PC program to command the system to drop the part. Check Sensor settings and adjust. Parker Hannifin Corporation Pneumatic Division Richland, Michigan... - Page 10 Note: If sensor LED indicates a pressure when unit is idle, reset the sensor to zero. This can be done by pressing the mode key for three seconds. This is the zero reset function of the pressure sensor. Press for 3 Seconds Zero Reset Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic...
- Page 11 LED illuminated. system pressure above P_3, the air economize function is overridden. This is the normal function of the CVX0260B Unit. Part off degree of vacuum should be less than n_1 and n_1 should be more than the Log Part On and maximum system initial part on pressure.
- Page 12 PSCVXDNB Emergency Stop Blow-off Vacuum Sensor Blow-off Vacuum Sensor Switches 1 2 3 4 5 6 7 8 Sensor Sensor VAC1 BL01 VAC2 BL02 Sensor 2 Sensor 1 BL02 VAC1 VAC1 BL01 Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic...
-
Page 13: Devicenet Connections
Not Used Not Used Not Used Not Used Not Used Part Presence Part Presence Output Data Table Output Byte 1 Not Used Not Used Not Used Not Used Vacuum Blow-Off Vacuum Blow-Off Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... -
Page 14: General Description
125k default value is 16ms. 250k A Slave can be allocated for Cyclic or Change of State but not both. Change of State can function with Bit-Strobed and 500k Polled messaging. Invalid Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... -
Page 15: Factory Dip Switch Settings
8 bytes of input data and / or status information. The format of the Bit-Strobe response for the Convum / Parker DeviceNet™ is the same as the Poll response. Factory DIP Switch Settings 1 2 3 4 5 6 7 8... -
Page 16: Optional Mounting Plate
Typ. 4 Places (12.7) 4 Places Discrete Kits Emergency Stop Blow-off PSCVXD3B - M12, 24VDC Vacuum Sensor PSCVXN3B - M18, 24VDC Blow-off Vacuum Sensor Output Output Channel 1 Channel 2 Input Aux. Power Sensors Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... -
Page 17: Pin Connector
Either pin can connect power to both sensors. Pin P & J are jumpered inside unit. This is for monitoring power only. Pin P is not necessary for operation of the unit. Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... - Page 18 • After installation, servicing, or conversion, air and electrical to change by Parker Hannifin Corporation and its subsidiaries at any supplies (when necessary) should be connected and the product time without notice.
- Page 19 (Revised 07-23-13) VAC-SIF-05 CVX0260B Pocket Troubleshooting Card Troubleshooting Parker Convum CVX0260B Sensor Verify ou1 is set NC. Factory Pre-set Air Economizing / Part Present Signal LED 1 will be ON if <NC> No Vacuum Signal Air Economizing (ON) n_1 = -18.0 inHg...
- Page 20 (Revised 07-23-13) VAC-SIF-05 CVX0260B Pocket Troubleshooting Card Troubleshooting Parker Convum CVX0260B Sensor Verify ou1 is set NC. Factory Pre-set Air Economizing / Part Present Signal LED 1 will be ON if <NC> No Vacuum Signal Air Economizing (ON) n_1 = -18.0 inHg...
- Page 21 Press button 2 seconds to enter the min. value mode, pressure sensor will detect the min. value and keep min. value displayed. Press button 2 seconds to return to measure mode display. Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic...
-
Page 22: Output Type
– – – – limit of pressure setting Internal data error Turn power off and then restart. If error condition System Error Internal system error remains, please return to factory for inspection Internal data error Parker Hannifin Corporation Pneumatic Division Richland, Michigan www.parker.com/pneumatic... -
Page 23: Offer Of Sale
Products, to or from Buyer is subject to these Terms and Conditions or any newer or any other person, arising out of: (a) improper selection, improper application or other version of the terms and conditions found on-line at www.parker.com/saleterms/. Seller misuse of Products purchased by Buyer from Seller; (b) any act or omission, negligent objects to any contrary or additional terms or conditions of Buyer’s order or any other... - Page 24 Parker Hannifin Corporation Applications Engineering Pneumatic Division Phone: 877 321 4PDN Option #2 E-mail: pdnapps@parker.com 8676 E. M89 Customer Support P.O. Box 901 Richland, MI 49083 USA Phone: 877 321 4PDN Option #1 Tel: 269 629 5000 E-mail: pdncustsvc@parker.com Fax: 269 629 5385 Web site: www.parker.com/pneumatics...
