NXP Semiconductors
User's Guide
WCT1012VLF/WCT1013VLH Consumer MP-
A11 (WCT-15W1CFFPD) V1.0 Wireless
Charging Application User's Guide

1. Key features

The WCT1012VLF/WCT1013VLH Consumer MP-
A11_Rev1.0 (MP-A11_Rev1_SCH-32212_B, MP-
A11_Rev1_LAY-32212_B) wireless charging TX demo
(WCT-15W1CFFPD) is used to wirelessly transfer power
to a charged device. The charged device can be any
electronic device equipped with a dedicated Qi wireless
charging receiver.
The main parameters of the Wireless Charging
Transmitter (WCT) are:
• Support for QC 3.0 and USB PD 2.0/3.0 input.
The input voltage ranges from 5 to 19 V DC.
• The input voltage can drop down to 5 V DC
during the start-stop function.
• The nominal power delivered to the receiver is
15 W, up to 22 W (at the output of the receiver)
and compatible with a 5 W receiver.
• Designed to meet the Qi 1.2.4 specification.
• Operation frequency: 120 kHz ~ 130 kHz (the
default is 127.772 kHz) for Qi devices.
© 2019 NXP B.V.
Document Number: WCT101XV10AUG
Contents
1.
Key features ....................................................................... 1
2.
Hardware setup .................................................................. 2
3.
Application operation ........................................................ 6
4.
Hardware description ......................................................... 6
5.
6.
Application monitoring using console ..............................20
7.
8.
Software description .........................................................46
9.
System bring up ................................................................52
10. Revision history ................................................................56
Rev. 1 ,, 05/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-A11 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NXP Semiconductors MP-A11 Series

Summary of Contents for NXP Semiconductors MP-A11 Series

  • Page 1: Table Of Contents

    NXP Semiconductors Document Number: WCT101XV10AUG User’s Guide Rev. 1 ,, 05/2019 WCT1012VLF/WCT1013VLH Consumer MP- A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide 1. Key features Contents The WCT1012VLF/WCT1013VLH Consumer MP- Key features ............... 1 Hardware setup ..............2 A11_Rev1.0 (MP-A11_Rev1_SCH-32212_B, MP- Application operation ............

  • Page 2: Hardware Setup

    2. Hardware setup 2.1. Package contents 1. WCT Consumer MP-A11 (WCT-15W1CFFPD) demo board. Figure 1. MP-A11 (WCT-15W1CFFPD) demo board WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 3: Board Description

    To power the board on, perform these steps: 1. Plug the USB PD or QC adaptor. 2. Connect the board with the USB PD or QC adaptor by an USB type-C cable. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 4 The virtual serial port on the computer should work well. 2. Plug the USB-UART converting board to the SCI connector according to the SCH signal pin position. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 5 Figure 4. UART and JTAG connectors WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 6: Application Operation

    MP-A11 (WCT-15W1CFFPD). Visit www.nxp.com to get the latest hardware design files. The whole design consists of several blocks, which are described in the following sections. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 7 Figure 5. Block diagram of the consumer wireless charger MP-A11 (WCT-15W1CFFPD) WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 8: Usb Power Supply

    Generally, the DCDC load current is low. It is preferable to select a DCDC with a high efficiency in the light-load condition. The MP-A11 design can also support other customized-propriety power protocols. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 9 EMI products. The Vrail discharge circuit (Q4 and R58) is switched ON while the system is terminated. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 10 Received Power �� , i.e. �� = �� − �� , provides the power absorption in foreign objects, as shown ���� �������� ���� ���� Figure WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 11 When the NXP MP-A11 transmitter charges the baseline profile RX, the power-loss baseline is applied. The TX continuously monitors �� , and if it exceeds the threshold several times, the TX terminates �������� the power transfer. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 12 Both effects lead to a decrease of the TX coil’s Q factor. The RX sends a packet including the reference Q factor for the TX to compare and determine if the FO exists, as shown Figure WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 13 Collect the ADC data of the tank voltage (or coil current), and get the decay rate of the signal. Q=��/(-ln(Rate)) Rate is the value of the decay rate of the resonance signal. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 14 Some ports of the ADC A-channel of the WCT1012VLF/WCT1013VLH are used to sense analog signals, such as the temperature, full-bridge input current, input voltage, and rail voltage. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 15: Application Monitoring And Control Using Freemaster

    Figure 13. Device Manager 4. Unpack the embedded source code to your local disk. 5. Start the FreeMASTER application by opening: • MWCT1013 <unpacked_files_location>/15W_MP/example/wct1013PD/ wct1013pd.pmp WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 16 7. Ensure that the correct virtual port (according to Step 3) and speed are selected. Figure 15. Setting port and speed 8. Ensure that the MAP file is correct. The default directories are: • MWCT1013 <unpacked_files_location>/15W_MP/build/demo/wct1013PDdemo/demo_ldm_debug/wct1013P Ddemo_debug.elf WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 17 Figure 16. Setting the MAP file 9. Connect FreeMASTER. Power the MP-A11 on and start the communication by clicking the “STOP” button in the FreeMASTER GUI. Figure 17. “STOP” button WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 18 This block lists all the parameters used for the WCT library. • Command The command variable is used to stop the WCT, start the WCT, and perform automatic calibration. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 19 Figure 19. Application variables The application variables are divided into these tabs: • “Op Params”—enables access to variables related to the operation control. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 20: Application Monitoring Using Console

    The macros are defined in example->wct101xa->driver->qsci.h. c) #define FMSTR_USE_SCI 0 /* To select SCI communication interface */ #define FMSTR_USE_JTAG 1 /* 56F8xxx: use JTAG interface */ WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 21 Data Bits Stop Bits Parity None Hardware Flow Control None Display As ASCII 5. Open the port or start the communication, depending on the terminal used. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 22: Programming New Software And Calibration

    Click the “Download” button for the CodeWarrior Special Edition (offline or online). Figure 21. Clicking “Download” for CodeWarrior Special Edition Download the CodeWarrior for Microcontrollers 10.7 service pack at this link: www.nxp.com/products/power-management/wireless-charging-ics/15-watt-wireless-charging- transmitter-ics-for-automotive-applications:MWCT1x1xA?tab=Design_Tools_Tab WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 23 Figure 22. Downloading CodeWarrior for MCU v10.7 service pack 2. Double-click the CW_MCU_v10.7_b160721_SE.exe file after downloading. Figure 23. Setup file 3. Make sure that the “DSC” option is selected. Figure 24. DSC installed WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 24 4. Launch CodeWarrior, create a folder workspace, and select it as the default workspace. Figure 25. Workspace Launcher dialog box 5. Select “Help” –> “Install New Software”. Figure 26. Install New Software WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 25 8. Review the license terms. If you agree with the license terms, select “I accept the terms of the license agreement” and then click “Finish”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 26 Figure 29. Installation finished 7.2. Board and programmer connection Connect the 14-pin debug cable to J3 on the board (notice the pin-1 position of the cable). WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 27 1. Import a project. 2. Select the “File” tab and then click the “Import” button to import an existing project, as shown in the following figures. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 28 Figure 31. Importing a project (1) Figure 32. Importing a project (2) WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 29 3. Select the project directory, as shown in the following figure. Figure 33. Importing a project (3) 4. Select the WCT1013 project. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 30 The “demo_ldm_debug” build contains debug information. The “demo_ldm_release” is the same as the “demo_ldm_debug”, except for debug information. Figure 35. Building a project (1) WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 31 “Download Configurations”, select a download configuration according to your build configurations and debugger type: USB TAP, PnE Multilink, or OSJTAG. Figure 37. Downloading the project WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 32 MCU. Due to the automatic calibration of the rail voltage, the Q-factor and quick removal is done the first time the TX runs after flashing a new image. Figure 38. Project downloaded WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 33 1. Select “Flash Programmer” –> “Flash File to Target”. Figure 39. Choosing Flash File to Target 2. Click the “New” button to create a new connection. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 34 Figure 40. Creating a new connection 3. In the “New Connection” text box, select “Hardware or Simulator Connection” and click “Next”. Figure 41. Entering a connection name WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 35 5. In the “Name” text box, enter a target name (any name is OK, but it cannot be the same as the connection name) and choose “dsc.MWCT101x” -> “MWCT1013A” from the “Target Type” drop-down menu. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 36 Figure 43. Choosing MWCT1013A 6. Select “Execute reset” and “Initialize target”, set the initialization target file path to the CodeWarrior IDE installation folder, and then select MWCT1013A.tcl. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 37 7. Click the “Memory” tab. 8. Select “Memory configuration”, set the memory configuration file path to the CodeWarrior IDE installation folder, and then select “MWCT1013A.mem”. 9. Click “Finish”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 38 Figure 45. Memory configuration 10. Select “USB TAP” for the “Connection type”, and then click “Finish”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 39 11. Set the binary file path to “File to Flash”. Select “Save the Target Task” for future programming. Power the MP-A11 on and click “Erase and Program”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 40 12. Specify the task path and click “OK” to save the task. Figure 48. Selecting the task path 13. When program is finished, the “Console” window displays the following log. Figure 49. Programming finished log WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 41 See the figure below to configure the application project settings. Select the “Sort by Address” option. Set “Max S-Record Length” to a value that does not exceed 255. Select “DOS (\\r\\n)” for the “S-Record EOL Character”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 42 Most serial terminal programs can be used to send the S-Record file from the host to the WCT1013 board using the bootloader. For example, Tera Term can be used in the Windows OS platform. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 43 Figure 52. Tera Term connection 4. Choose “Setup” -> “Serial port” to configure the COM properties, as shown in the following figure. Figure 53. Serial port WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 44 Figure 54. Serial port setup 5. Choose “File” -> “Send file”. Figure 55. Send file 6. Select the application S-Record file and click “Open”. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 45 Figure 56. Send application S-Record file The download progress is displayed in the Tera Term window. After the download completes, the application code starts. Figure 57. S-Record file download complete WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 46: Software Description

    Directory structure The following figure shows an example of the directory structure of the whole WCT1013_MP-A11 distribution. Figure 58. Directory structure of the whole WCT1013_MP-A11 distribution WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 47 For WCT1013, there are two build configurations: • “demo_ldm_debug”: larger program model, including the code for debugging. • “demo_ldm_release”: larger program model, excluding the debugging code to save memory size. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 48: Functional Description

    • The FreeMASTER SCI port is SCI0 by default. #define FMSTR_SCI_BASE 0xE080 /* base address of SCI_0 The macro is in freemaster_cfg.h. #define QSCI_FREEMASTER_INDEX 0 //QSCI0 The macro is in qsci.h. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 49 Default value Location Description DIGITAL_BUCKBOOST FALSE appcfg.h Switch the DCDC control type. Set TRUE to enable the digital buck-boost. Set FALSE to enable the analog buck-boost. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 50 TX is ryLowPowerEnable enable or disable recharge retry under the recharge retry under recharge retry state state state. 1: enable, 0: disable WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 51 5000 mA gPROT_Params.wMaxInputCurrent Application implemented. If the input current exceeds the limit, charging is turned off. The limit value can be changed by the FreeMASTER GUI. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 52: System Bring Up

    The digital ping appears about every 5 seconds and the analog ping appears about every 400 ms. There are 12 to 13 analog pings between two digital pings. The following figures show the PWM waveforms of the ping sequence and ping patterns. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 53 Figure 61. Digital ping interval Figure 62. Analog ping interval WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 54: Led Indication

    Figure 63. Digital ping pattern Figure 64. Analog ping pattern 9.2. LED indication The default LED display modes for different TX working states are shown in the following table. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 55 Prints information when the RX power is beyond capability. Message: CFG, Rcvd 0xXX Prints the packet type that should not be received in the configuration phase. WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...

  • Page 56: Revision History

    Table 10. Revision history Revision number Date Substantive changes 04/2019 Initial release. Section 1, “Key features” Updated Section 4.5, “Full-bridge and resonant 05/2019 circuits”. Updated Table WCT1012VLF/WCT1013VLH Consumer MP-A11 (WCT-15W1CFFPD) V1.0 Wireless Charging Application User’s Guide, Rev. 1, 05/2019 NXP Semiconductors...
  • Page 57 Information in this document is provided solely to enable system and software How to Reach Us: implementers to use NXP products. There are no express or implied copyright licenses Home Page: granted hereunder to design or fabricate any integrated circuits based on the www.nxp.com information in this document.
