Freescale Semiconductor
User's Guide
MPC8349E-mITX-GP Reference
Design Platform User's Guide
The MPC8349E-mITX-GP reference design platform is a
system featuring the powerful PowerQUICC™ II Pro
processor, which includes a built-in security accelerator.
This low-cost, high-performance system solution consists of
a printed circuit board (PCB) assembly known as the
MPC8349E-mITX-GP Board, plus a board support package
(BSP), distributed in a CD image. This BSP enables fastest
possible time-to-market for development or integration of
applications including media servers, network attached
storage devices, and next-generation small office home
office/small medium business gateways.
Section 1, "MPC8349E-mITX-GP Board,"
board in terms of its hardware: the features, specifications,
block diagram, connectors, interface specification, and
hardware straps.
Section 2, "Getting Started,"
physical connections needed to boot the
MPC8349E-mITX-GP board.
Section 3, "MPC8349E-mITX-GP Software,"
software that is shipped with the platform.
Use this manual in conjunction with the following
documents:
•
MPC8349E PowerQUICC™ II Pro Integrated Host
Processor Family Reference Manual
(MPC8349ERM)
© Freescale Semiconductor, Inc., 2006. All rights reserved.
Preliminary-Subject to Change Without Notice
describes the
describes the board settings and
describes the
Document Number: MPC8349EMITXGPUG
1. MPC8349E-mITX-GP Board . . . . . . . . . . . . . . . . . . . 2
2. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3. MPC8349E-mITX-GP Software . . . . . . . . . . . . . . . . 34
4. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
WARNING
This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be
required to take adequate measures.
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
Rev. 0, 10/2006
Contents
NOTE

Advertisement

loading
Need help?

Need help?

Do you have a question about the MPC8349E-mITX-GP and is the answer not in the manual?

Questions and answers

Related Manuals for NXP Semiconductors MPC8349E-mITX-GP

Summary of Contents for NXP Semiconductors MPC8349E-mITX-GP

  • Page 1 The MPC8349E-mITX-GP reference design platform is a Contents 1. MPC8349E-mITX-GP Board ....2 system featuring the powerful PowerQUICC™ II Pro 2. Getting Started ......29 processor, which includes a built-in security accelerator.

  • Page 2: Mpc8349E-Mitx-Gp Board

    This section presents the features and block diagram, specifications, and mechanical data for the MPC8349E-mITX-GP board. Features This section presents the features, specification, and block diagram of the MPC8349E-mITX-GP board. The features are as follows: • CPU: Freescale MPC8349E running at 533/266 MHz (CPU/CSB (Coherent System Bus)) •...
  • Page 3 1.2.1 Reset and Reset Configurations The MPC8349E-mITX-GP reset module generates a single reset to reset the MPC8349E and other peripherals on the board. The reset unit provides power-on reset, hard reset, and soft reset signals in compliance with the MPC8349E hardware specification.
  • Page 4 Soft reset is generated by the COP/JTAG port. Assertion of SRESET causes the MPC8349E to abort all current internal and external transactions and set most registers to their default values. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor...
  • Page 5 (2A) or a thermal shutdown or under voltage lockout (UVLO) condition occurs. This interrupt pin generates an interrupt to IRQ3 of the MPC8349E. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 6 MPC8349E-mITX-GP Board 1.2.3 Clock Distribution Figure 4 Table 1 show the clock distribution on the MPC8349E-mITX-GP board. 66.666 MHz CLKIN 33/66 MHz 32-bit PCI Slot OCCR PCI_SYNC_OUT GPL5 CFG_CLKIN_DIV System PCI_SYNC_IN LCLKx 33 MHz to 133 MHz local bus Local Bus CLK...
  • Page 7 The MPC8349E reads the DIMM SPD data using the DIMM SCL (clock) and the SDA (data) signals through the I2C2 interface. Figure 5 shows the DDR SDRAM controller connection. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 8 32-bit local bus interface, there is a data buffer for all low-speed devices attached to the memory controller. The on-board single bank 8-Mbyte Flash memory module is connected to the local bus. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 9 Figure 6. Local Bus Connections 1.2.6 On-Board Flash Memory Through the general-purpose chip-select machine (GPCM), the MPC8349E-mITX-GP provides a total of 8 Mbyte of 90 ns Flash memory using one chip-select signal. The Flash memory is used with the 16-bit port size.
  • Page 10 C address of the DDR SPD EEPROM on I2C2 bus is 0x51. There are two PCF8574A I C I/O expander on the MPC8349E-mITX-GP board to provide general purpose I/O expansion via the I2C2 interface. The first PCF8574A (U8) has I2C2 address 0x38 and it is able to control the Green LED (D1) and Yellow LED (D2), set the VSC8201 to powerdown mode.
  • Page 11 1.2.8 10/100/1000 BaseT Interface On the MPC8349E-mITX-GP board, GMII mode is used on TSEC1 , which is connected to the on-board 10/100/1000 PHY (VSC8201). The TSEC I/O voltage is set to 3.3 V. The GMII (1000 BaseT) is a source synchronous bus.
  • Page 12 The MPC8349E has two internal USB modules (USB0 and USB1), a multi-port host (MPH) module, and a dual-role (DR) module. On the MPC8349E-mITX-GP board, USB1 connects to USB PHY (USB3300) through the 8-bit UTMI low pin count interface (ULPI). The USB3300 PHY connects to a USB Mini-AB type receptacle connector that serves as a host/device/OTG USB interface.
  • Page 13 This port can connect to a dedicated emulator for extensive system debugging. Several third-party emulators in the market can connect to the host computer through the MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor...
  • Page 14 Figure MPC8349E ITX Emulator Figure 11. Connecting the MPC8349E-mITX-GP Board to A Parallel Emulator The 16-pin generic header connector carries the COP/JTAG signals and the additional signals for system debugging. The pinout of this connector is shown in Figure...
  • Page 15 P15 RS-232-COM1 P18 ATX Power Pin 1 Figure 13. MPC8349E-mITX-GP Top View Connectors This section describes the MPC8349E-mITX-GP connectors and their pin assignments. 1.4.1 Case Connector The case connector (J10) connects to the case power switch, power LED, reset switch. •...
  • Page 16 SRESET HRESET 1.4.3 PCI Slot The MPC8349E-mITX-GP board has one 32-bit 3.3 V PCI expansion slot (P1) for an expansion card. WARNING Only the 3.3 V PCI Card is supported. Turn OFF power during insertion and removal of PCI card.
  • Page 17 Fan Connectors There are two fan connectors on the MPC8349E-mITX-GP board, one for powering a 5 V fan (J9) and the other for powering a 12 V fan (J5). For typical fans, the red wire is always positive (+) and the black wire is always negative (–).
  • Page 18 CLKIN: PCI_SYNC_OUT = 1:1, PCI_CLK_OUT[0:7] = CLKIN. 66 MHz CLKIN is used, 66 MHz PCI2. BOOT1 OFF(1) OFF (1): Default MPC8349E fetches the reset vector from Flash 0 (U4). ON (0): Reserved MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 19 OFF (1): Default Flash (U7) are not write protected. ON (0): Flash (U7) are write protected. Table 9 lists the connectors, jumpers, switches, and LEDs on the MPC8349E-mITX-GP board. Table 9. Lists of Connectors, Jumpers, Switches, and LEDs Reference Description Connectors Battery holder for RTC Background Debug Mode (BDM).
  • Page 20 [ jumper 2–3]. Default is not selected. Reset configuration word source selection jumpers Switches System reset button. Resets the MPC8349E-mITX-GP board. Power-on push button. Powers up the MPC8349E-mITX-GP board. LEDs D1/D2 SW0 and SW1. Controlled by the I2C expander connected to the MPC8349E USB port power indicator LED.
  • Page 21 PCI Operating Frequency An M66EN input pin determines the AC timing of the PCI interface. On the MPC8349E-mITX-GP board, the state of this signal can be driven to 0 by the J22 jumper to select 33 MHz AC timing. If J22.F is not driven to 0, the M66EN signal level is determined by the PCI agent card connected to PCI slot P1.
  • Page 22 2:1 2–3 — Reserved Must be cleared. 4–7 SPMF[0–3] System PLL 0000 16:1 multiplication 0001 Reserved factor 0010 0011 0100 (default) 0101 MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 23 10 0010 1 2.5:1 11 0010 1 2.5:1 00 0011 0 01 0011 0 10 0011 0 11 0011 0 16–31 — Reserved. Must be cleared. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 24 Local bus GPCM, 16 bits Local bus GPCM, 32 bits 12–15 Reserved — Must be cleared 16–17 TSEC1M TSEC1 Mode RGMII RTBI 10: Default GMII MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 25 00 0001 0 333 MHz 66.666 MHz 0100 266 MHz 01 0001 1 400 MHz 1.5:1 66.666 MHz 0011 200 MHz 01 0010 0 400 MHz MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 26 The 3.3 V power supply is reduced to 1.2 V and 2.5 V. The 1.2 V power is generated from a switching power supply for a CPU core. The 2.5 V power is generated from an LDO regulator for the DDR controller. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 27 PCI2 I/O space (16 Mbyte) 0xF000_0000–0xF000_FFFF Local bus LCS3 Reserved 0xF900_0000–0xF91F_FFFF Local bus LCS2 Reserved 0xF800_0000–0xF801_FFFF Local bus LCS1 Reserved 0xE000_0000–0xEFFF_FFFF Internal bus IMMR (1 Mbyte) — MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 28 C (room temperature) Storage temperature –25 C to 85 Relative humidity 5% to 90% (noncondensing) PCB dimensions: Length 6692 mils Width 6692 mils Thickness 61.4 mils MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...

  • Page 29: Getting Started

    Figure 21. Dimensions of the MPC8349E-mITX-GP Board Getting Started This section describes how to boot up the MPC8349E-mITX-GP board. The on-board Flash memory has been preloaded with a Flash image from the factory. Before powering up the board, set the on-board jumpers according to the settings listed in Section 2.1, “Board Jumper Settings,”...
  • Page 30 Getting Started Board Jumper Settings Figure 22 shows the top view of the MPC8349E-mITX-GP with pin 1 marked for each reference. Using Figure 22 as a guide, the default jumper settings are given in Table 19 starting at the left-hand top corner of the board and moving around the board in a clockwise manner.
  • Page 31 12 or greater than 14 row addresses are not supported. DIMM modules with fewer than 8 or greater than 11 column addresses are not supported. MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 32 Figure USB 2.0 Ethernet 10/100/1000 Not Used Connect Serial Port Cable Connect AC Adapter Connect Serial Port Cable to the PC Figure 24. External Connections MPC8349E-mITX-GP Reference Design Platform User’s Guide, Rev. 0 Freescale Semiconductor Preliminary—Subject to Change Without Notice...
  • Page 33 Getting Started Serial Port Configuration (PC) Before powering up the MPC8349E-mITX-GP system, configure the serial port of the attached computer as follows: Data rate: 115.2 Kbps, Number of data bits: 8, Parity: none, Number of Stop bits: 1, Flow Control: Disabled.

  • Page 34: Mpc8349E-Mitx-Gp Software

    MPC8349E-mITX-GP Software A board support package (BSP) is pre-installed on the MPC8349E-mITX-GP. This BSP consists of a bootloader (u-boot), a generic PPC Linux-based system, and associated file system which reside in the on-board Flash memory.

  • Page 35: Revision History

    LTIB to build the ISO image. Third-Party Application Software Many third-party applications are available for the MPC8349E-mITX-GP. They are typically built on top of the original BSP delivered by Freescale. To run demonstrations or to acquire details of Freescale’s third-party applications for this MPC8349E-mITX-GP, contact your local Freescale sales office.
