Specifications
Frequency Range
Signal Level Range
RF Input Connector
Input Impedance
LNB Power Supply
SWiM Power Supply
Communications
Battery
Operating Temperature
Storage Temperature
Battery Charging
Temperature
Display
Weight
Dimensions (H x W x D)
250 MHz to 2150 MHz
-10 to -69 dBmV
Replaceable "F" connector (2)
75 Ω
13 Volts / 18 Volts
21 Volts
Wi-Fi (802.11 b,g and n, 2.4 GHz); Bluetooth (4.0 and BLE dual mode); and Gigabit
Ethernet
USB flash drive (Linux format only)
6-cell, 10.8 Volt, 4.4 AH rechargeable Li-ion
-29° to +52° C (-20° to 126° F)
-40° to +65° C (-40° to 149° F)
5° to 37° C (-41° to 99° F)
240 x 160 pixel, backlit LCD
1225 grams (2.54 lbs)
350 x 126 x 61 mm (13.7 x 4.9 x 2.4 in)
Chapter 11
Appendix
AIM 2 Operation Manual
Page 107
