Update Firmware From The Internet; Update Firmware From A Usb Flash Drive - DirecTV Advanced Installation Meter 2 Operation Manual

Update Firmware from the Internet

The AIM can update firmware from an Ethernet
connection or via Wi-Fi.
Make sure the Ethernet connection has been set
up and you have connected a Ethernet cable to the
port on the AIM.
If using Wi-Fi, make sure the Wi-fi network has
been set up. The AIM will then connect to the
network.
1. Select the Select update from Internet option
and press SELECT. The AIM connects to the
update server and shows the available updates.
2. Select the update version and press SELECT.
The firmware update process begins. A
message appears when the firmware update is
complete and the meter automatically restarts
with the new firmware.
Update Firmware from a USB Flash
Drive
1. Insert the USB flash drive that contains the
firmware update into the USB port on the meter.
2. Wait 15 seconds, then select the Select update
from USB option and press SELECT.
The available updates on the USB flash drive
appear. Choose which update you want to use
and press SELECT.
The firmware update process begins. A
message appears when the firmware update is
complete and the meter automatically restarts with the new firmware.
3. After the meter turns on and the HOME screen appears, you can remove the USB flash
drive from the USB port.
AIM 2 Operation Manual
Page 106
