Installation Procedure > In the case iR-ADV C5255/C5250/C5240/C5235 Series > Installing the Open I/F PCB

Checking the Contents

[1] PS Unit X 1
[2] Open I/F PCB X 1
[4] Power Cord
[5] Cross Ethernet
Cable 3.0m X1
Europe x 2
USA x 1
[4] Power Cord: The connector has a different shape depending on locations.
Use the correct power code to mach the location/area of installation.
Make sure not to leave unused power code at the site.
< CD/Guides >
• Media Pack

Check Items when Turning OFF the Main Power

Check that the main power switch is OFF.
1) Turn OFF the main power switch of the host machine.
2) Be sure that display in the Control Panel and the lamp of the main power supply are turned
off, then disconnect the power plug.
Installation Procedure > In the case iR-ADV C5255/C5250/C5240/C5235 Series > Installing the Open I/F PCB

Installation Procedure

[3] Interface Cable X 1
■ Installing the Open I/F PCB
1) Remove the Left Rear Cover.
• 2 Rubber Caps
• 2 Screws
• 5 Claws
[6] Shield Ethernet
Cable 3.0m X1
F-1-4
In the case iR-ADV C5255/C5250/C5240/C5235 Series
Rubber Caps
x2
x5
Rubber Caps
3
Claws
F-1-5
3
