SMA & SMQ Commands manual
Index
Introduction
Output list
Using the commands
SV0x
Set Volume
SVU0x
Set Volume Up 3dB
SVD0x
Set Volume Down 3dB
SR0x
Set Routing
SRU0x
Set Routing Up
SRD0x
Set Routing Down
SM0x
Set Mute
GV0x
Get Volume
GR0x
Get Routing
GM0x
Get Mute
GTE
Get Temperature
2
2
3
4
4
4
4
5
5
5
6
6
6
6
1
Advertisement
Table of Contents
Related Manuals for AUDAC SMA
Summary of Contents for AUDAC SMA
- Page 1 SMA & SMQ Commands manual Index Introduction Output list Using the commands SV0x Set Volume SVU0x Set Volume Up 3dB SVD0x Set Volume Down 3dB SR0x Set Routing SRU0x Set Routing Up SRD0x Set Routing Down SM0x Set Mute GV0x...
- Page 2 Introduction Welcome to the command user manual of the AUDAC SMA & SMQ amplifiers. For more info about the SMA and SMQ amplifiers, see the corresponding user manual. This manual only describes the use of the commands for controlling the amplifiers through RS-232.
- Page 3 Command flow 1) The client sends a command to the SMA or SMQ 2) The SMA or SMQ acknowledges the command by returning the same command and a ‘+’ as Argument. 3) The SMA or SMQ updates all client’s with the new information All volume and routing settings are saved automatically with every change and will remain when the device is switched off.
- Page 4 SV0x Set volume of an output to a certain level Command: SVx, with x the output number whereof the volume should change. Arguments: Volume in neg dB, 0 is maximum volume, 70 is minimum volume Example Set volume of output 2 to -40dB Command #|Q001|web|SV02|40|U|return Answer...
- Page 5 SRU0x Set routing up for an output Command: SRU0x, with x the output where the routing (input) should increase for Arguments: 0 (none) Example Increase routing for output 1 (current is selected is input 1 which changes to input 2) Command #|Q001|web|SRU01|0|U|return Answer...
- Page 6 GV0x Get volume info for a certain output Command: GV0x, with x the number of the output Arguments: 0 (none) Example Get volume info for output 1 Command #|Q001|web| GV01|0|U|return Answer #|web|Q001| V01|20|U|return GR0x Get routing info for a certain output Command: GR0x, with x the number of the output Arguments: 0 (none) Example...
