powersoft Mezzo Series User Manual page 7

Pinouts
Outputs (2 Channel Versions)
CH4 - CH3 Balanced Inputs
CH4 - CH3 Line Level Outputs (2 Channel Version)
Network Connector RJ45 pinout
Color code (TIA/EIA-568-B)
ORANGE / WHITE
ORANGE
GREEN / WHITE
BLUE
BLUE / WHITE
GREEN
BROWN / WHITE
BROWN
Ch 1
Ch 2
Ch 3
Ch 4
Ch 3
Ch 4
1 2 3 4 5 6 7 8
Pin
1
2
3
4
5
6
7
8
Outputs (4 Channel Versions)
CH2 - CH1 Balanced Inputs (4 Channel Version)
GPI
Ch 1
Ch 2
Ch 3
Ch 4
Ch 3
Ch 4
5V
I1
I2
I3
I4
