- Page 1 INSTALLATION AND USE MANUAL La San Marco Spa ENGLISH cod. 7770.033 EDITION March 2008 Page 1 of 36...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION AND GENERAL INSTRUCTIONS..........................3 INSTRUCTIONS FOR INSTALLATION ..............................3 SPECIAL INSTRUCTIONS FOR USE AND MAINTENANCE .......................3 MACHINE KEYPAD....................................4 ELECTRIC CONNECTION..................................5 HYDRAULIC CONNECTION ................................5 POSITION FOR ELECTRICAL –HYDRAULIC CONNECTION AND DIRECT DISCHARGE..............6 STARTING UP ......................................7 DISPENSING ......................................10 QUICK REFERENCE TO LOAD CREDIT ON CREDIT CARD......................14 FREE DRINKS FUNCTION.................................15 SHIFT DISPENSING ...................................16 CONTINUOUS DISPENSING WITH BUTTO N°12..........................16... -
Page 3: Introduction And General Instructions
In any case, regularly check the boiler even where the water is not very hard, and if necessary, have the resistors and tubing descaled by specialised technicians. Failure to clean La San Marco S.p.A. machines daily, especially for brewing unit and milk frother, using approved cleaning products and following specified cleaning procedure will result in void warranty and service contract. -
Page 4: Machine Keypad
MACHINE KEYPAD DISPLAY PLUS 10 PLUS 10 PLUS 10 PLUS 10 REFERENCE SELF LM SELF COF COFFEE GROUP Espresso 1 Espresso Espresso Espresso Espresso Macchiato 2 Espresso Espresso Macchiato Coffee Coffee 1 Coffee DISABLE DISABLE Cappuccino 2 Coffee DISABLE DISABLE Large coffee 1 Black Coffee Large coffee... -
Page 5: Electric Connection
ELECTRIC CONNECTION 120V-1+N-50/60HZ 400V-3+N-50/60HZ 200V-1+N-50/60HZ 200V-3 -50/60HZ 230V-1+N-50/60HZ 230V-3 -50/60HZ HYDRAULIC CONNECTION H2O IN H2O OUT (1-5 Bar) WATER FILTRE WATER SOFTNER Page 5 of 36... -
Page 6: Position For Electrical -Hydraulic Connection And Direct Discharge
POSITION FOR ELECTRICAL –HYDRAULIC CONNECTION AND DIRECT DISCHARGE Page 6 of 36... -
Page 7: Starting Up
Press n° 11 ON/OFF key to switch the machine ON After having connected the machine to the water and electric networks, turn the switch on (see diagram). The display shows: La San Marco La San Marco ZZZZ ZZZ ZZZ : Indicate the installation date ZZZZ ZZZ ZZZ REV.X.XXX : Indicate the Software release inserted... - Page 8 Press the key N°11( ON/OFF ), the display shows: Filling - up steam boiler During this stage the steam boiler is being filled up WARNING: In according to the machine configuration in this stage will be release the air inside the boiler by opening a steam nozzle, milker or hot water solenoid valve.
- Page 9 For machine configurations: waiters’ card The display shows Insert card For machine configurations: Self +Credit card The display shows: Insert coin 0000 For machine configuration: Self with coin box The display shows: Select Drink For machine configuration: Self with coin box + credit card. The display shows: Select Drink WARNING:...
-
Page 10: Dispensing
DISPENSING 1) Machine configurations Standard The display shows: Select Drink Place a cup under the adjustable in height coffee dispenser, and press the dose key required. The display shows: XXXXXX ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ where “XXXXXX”... - Page 11 3) Machine configurations Self The display shows: Select Drink Position the Cup Place a cup under the coffee dispenser and press the dose key required. The display shows: XXXXXX ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ where “XXXXXX” indicates the selected dose key name. The cursor indicates the amount of drink being dispensed.
- Page 12 5) Machine configuration Self with coin box. The display shows: SELECT DRINK If you press any dose key before insert the coin / token the display shows the selected drink price: XXXXXX Y.YY INSERT CREDIT where : “XXXXXX” indicates the selected dose key name. “...
- Page 13 6) Machine configuration Self with credit card and coin box. The display shows: SELECT DRINK If you press any dose key before insert the coin / token / Credit Card the display show the selected drink price: XXXXXX Y.YY INSERT CREDIT where : “XXXXXX”...
-
Page 14: Quick Reference To Load Credit On Credit Card
QUICK REFERENCE TO LOAD CREDIT ON CREDIT CARD Insert the Owner card into the proper slit with the machine ON then press the key N°15 (Scroll) The display shows: SMART CARD MANAGER CREDIT LOAD INSERT SMART CARD Use “+ / -“ keys to change the value Use “Enter”... -
Page 15: Free Drinks Function
FREE DRINKS FUNCTION To Enable or Disable the free drinks functioning of the machine with credit card, coin mechanism or both configurations, proceed as follows: Turn the machine ON. Insert the owner, service or technician’s smart card into the proper slit. Press the key N°... -
Page 16: Shift Dispensing
SHIFT DISPENSING The machine delivers 10 drinks, that can be doubled by means of the Shift button, for a total number of 20 drinks . Press key No. 12 ( SHIFT ) once before selecting a dose, the display shows: SELECT DRINK Where “... -
Page 17: Decaffeinated Cycle
DECAFFEINATED CYCLE This function is activated by opening the decaffeinated coffee door, and the display shows : pour in the powdered coffee close the door Press the desired dose key and the display shows : XXXXXX ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ ▀ Where indicates that the selected dose will be dispensed without the activation of the grinders. -
Page 18: Extra Foamed Milk Function
EXTRA FOAMED MILK FUNCTION Extra milk function enables to dispense extra foamed milk in the following way: Press any milk-based key and keep it pressed, after 2 seconds foamed milk will start being dispensed. By releasing the pressed key, dispensing will be stopped. WARNING: This function is not enabled for self machine, for self machine with credit card, for self machine with coin mechanism, and for self with credit card + coin mechanism. -
Page 19: Access The Main Setting Menus With Password Or Smart-Card
ACCESS THE MAIN SETTING MENUS WITH PASSWORD OR SMART-CARD A) ACCESS THE MAIN SETTING MENUS WITH PASSWORD To enter the programming environments, a password is required which define the access rights to the different environments. The password must be composed with 5 numbers. To insert the passwords proceed as follows: Turn the machine OFF Keep N°12 “Enter”... - Page 20 B) ACCESS THE MAIN SETTING MENUS WITH SMART CARD To enter the programming environments , insert one of the following smart cards into the proper slit with the machine in off: : - WAIETR SMART CARD - ROASTER- SMART CARD - OWNER SMART CARD Press the N°...
-
Page 21: Programmable Parameters In According With Password Or Smart Cards
PROGRAMMABLE PARAMETERS IN ACCORDING WITH PASSWORD OR SMART CARDS Password or Password or Password or Smartcard Smartcard Smartcard WAITER ROASTER OWNER Info - Reset Dose Data System Data Dose Slight Adj. Dose Programming Calibration Machine Parameter Language M. Configuration Serial Ground Numbers Milker Milker Rinsing... -
Page 22: System Clock Programming
SYSTEM CLOCK PROGRAMMING N:B: The System Clock parameters are available only with the system clock enable. To enter in System clock programming, proceed as follows. WITH SMART-CARD: Insert the Owner or Waiter smart card into the proper slit and keep pressed the key N°12 (Enter) . WITH PASSWORD : Digit the Owner or Waiter password . -
Page 23: Automatic Rinsing Cycle
AUTOMATIC RINSING CYCLE 1) Automatic group rinsing. A timed rinsing cycle of the brewing chamber is automatically carried out 15 minutes after the last dispensed drink and every 180 minutes when the machine is in stand-by mode. The display shows: GROUP AUTOCLEANING PLEASE NOTE: 5 seconds before the starting of the rinse cycle the machine will BEEP !. -
Page 24: Read And Reset Data
READ AND RESET DATA To enter in Read and reset data , proceed as follows. WITH SMART-CARD: Insert the Owner smart card into the proper slit and with machine in OFF keep pressed the key N°12 (Enter) . WITH PASSWORD : Digit the Owner password . The display shows :♥... - Page 25 Enter X.XX: Indicates the total cashing of the machine. The total will be calculates if Total cashing the selling price has been set x.xx for each dose. Enter X.XX: Indicates the total token cashing of the machine. The total token will be calculates if the Total token cashing selling price of the token has been set x.xx...
-
Page 26: Doses Slight Adjust Programming
DOSES SLIGHT ADJUST PROGRAMMING PLEASE NOTE : TO ACCESS TO THE DOSES SLIGHT ADJUST THE MACHINE MUST BE AT THE SET-UP TEMPERATURE. To enter in doses slight adjust programming mode, proceed as follows. WITH SMART-CARD: Insert the Owner or Roaster smart card into the proper slit and with the machine in OFF keep pressed the Key N°... -
Page 27: Set Doses Price Programming
SET DOSES PRICE PROGRAMMING PLEASE NOTE : TO ACCESS TO THE SET DOSES PRICE THE MACHINE MUST BE AT THE SET-UP TEMPERATURE. To enter in Set doses price programming mode, proceed as follows. WITH SMART-CARD: Insert the Owner smart card into the proper slit and with the machine in OFF keep pressed the Key N°... -
Page 28: Shift Doses Slight Adjust Programming
SHIFT DOSES SLIGHT ADJUST PROGRAMMING PLEASE NOTE : TO ACCESS TO THE SHIFT DOSES SLIGHT ADJUST THE MACHINE MUST BE AT THE SET-UP TEMPERATURE THE SHIFT DOSES PROGRAMMING IS ENABLE FOR STANDARD AND WAITERS CONFIGURATION MACHINES ONLY. By means of the Shift button, is possible to adjust other 10 doses for a total number of 20 drinks . To enter in Shift doses slight adjust programming mode, proceed as follows. -
Page 29: Set Shift Doses Price Programming
SET SHIFT DOSES PRICE PROGRAMMING PLEASE NOTE : TO ACCESS TO THE SET SHIFT DOSES PRICE THE MACHINE MUST BE AT THE SET-UP TEMPERATURE. To enter in Set shift doses price programming mode, proceed as follows. WITH SMART-CARD: Insert the Owner smart card into the proper slit and with machine in OFF keep pressed the key N°12 (Enter) . -
Page 30: Automatic Cleaning Of Coffee Group
AUTOMATIC CLEANING OF COFFEE GROUP 1► 2► 3► Keep ( N° “12” key ) Press “1” key to start the Open the machine door pressed for five seconds cleaning cycle GROUP CLEANING SELECT CLEANING SELECT CLEANING OPEN FRONT PANEL AND CLEAN GROUP 6►... -
Page 31: Automatic Cleaning Of Milk Frother
ONLY IN CASE THAT AFTER THE AUTOMATIC CLEANING PROCESS THE MILK FROTHER IS NOT PROPERLY DISPENSING, CARRY OUT A MANUAL CLEANING ( SEE THE FOLLOWING PAGE ). FOR CLEANING OPERATIONS , LA SAN MARCO STRONGLY RECOMMEND TO USE THE FOLLOWING DETERGENT PRODUCTS: CLEANING TABLETS MILK FROTHER CLEANER 100 Tablets ( 1.2gr.) Code N°... -
Page 32: Manual Cleaning Of Milk Frother And Coffee Outlet
MANUAL CLEANING OF MILK FROTHER AND COFFEE OUTLET 2► 3► 1► Remove the cover from the Remove the milk frother Remove the screw that fix coffee outlet and the coffee outlet from its the cover of the coffee outlet holder 5►... -
Page 33: Other Recommended Cleaning
OTHER RECOMMENDED CLEANING HOPPER CLEANING GROUND BIN CLEANING Once a month clean the hopper Once a day rinse the ground by means of a cloth and bin in a sink approved food detergent Page 33 of 36... -
Page 34: Machine Functions Messages
MACHINE FUNCTIONS MESSAGES 1) Full grounds bin alarm. Grounds Bin Full Cause: grounds bin full. The number of coffee grounds in the bin has reached the value set in the programming phase. Result: shutdown of the coffee based dispensing keys. Solution: remove the grounds bin and empty it, replace the bin when the display shows: Grounds bin Open... - Page 35 Solution: press the ( Clean/Deca ) N°12 key to reset the alarm and put decaffeinated into the decaf door. PLEASE NOTE: In case of other message, please, contact a La San Marco Spa. Authorised Service Centre 8) Message of coffee boiler heating temperature not reached.
- Page 36 The LA SAN MARCO S.p.A. product you have purchased is subject to Directive 2002/96/EC of the European Parliament and the Council of the European Union on waste electrical and electronic equipment (WEEE) and, in jurisdictions adopting that Directive, is marked as being put on the market after August 13, 2005, and should not be disposed of as unsorted municipal waste.
