- Page 1 Instruction Manual NON-DISPERSION TYPE INFRARED GAS ANALYZER TYPE: ZRF Fuji Electric Co.,Ltd. INZ-TN1ZRFb-E...
-
Page 2: Preface
PREFACE Congratulations on your purchase of Fuji’s Infrared Gas Analyzer (Type: ZRF). • Before using, be sure to read this instruction manual carefully to ensure correct installation, operation and maintenance of the infrared gas analyzer. Note that incorrect handling may lead to trouble or personal injury. -
Page 3: Safety Precaution
SAFETY PRECAUTION First of all, read this “Safety Precaution” carefully, and then use the analyzer in the correct way. • The cautionary descriptions listed here contain important information about safety, so they should always be observed. Those safety precautions are ranked 2 levels; “DANGER” and “CAUTION”. Meaning Warning &... - Page 4 Caution on piping DANGER: In piping, the following precautions should be observed. Wrong piping may cause gas leakage. If the leaking gas contains a toxic component, there is a risk of serious accident being induced. Also, if combustible gas is contained, there is a danger of explo- sion, fire or the like occurring.
- Page 5 Caution on maintenance and check DANGER: • When doors are open during maintenance or inspection for adjusting the optical system, etc., be sure to purge sufficiently the inside of the gas analyzer as well as the measuring gas line with nitrogen or air, in order to prevent poisoning, fire or explo- sion due to gas leaks.
- Page 6 CAUTIONS ON USE Select a suitable installation place. Install the unit in a place with normal temperature and humidity, free from excessive change in temperature and from heat radiation and direct sunlight. This unit is designed for indoor installation. When it is installed outdoors, choose a place where it is not exposed to wind and rain.
-
Page 7: Table Of Contents
CONTENTS PREFACE ............................i SAFETY PRECAUTION ....................... ii CAUTIONS ON USE ........................v OUTLINE ..........................1 NAME AND DESCRIPTION OF EACH COMPONENT ............ 2 Name and description of each component on case ..............2 Name and description of components on indication/operation panel ........4 INSTALLATION ........................ -
Page 8: Outline
1. OUTLINE This is a multi-function, easy-to-operate non-dispersion type infrared gas analyzer for measuring the concentration of gases such as NO, SO , CO and CO. It utilizes a highly reputed mass flow type detector featuring high sensitivity and reliability, plus a microprocessor for easy operation. Zero point Self diagnosis and span easily... -
Page 9: Name And Description Of Each Component
⑮ Power terminal Infrared Gas Analyzer Type Range Output Power Supply 50/60Hz Ser No. Fuji Electric Co., Ltd Japan Rear panel ⑪ COMP1 (1st component) input/output terminal ⑫ COMP2 (2nd component) input/output terminal ⑭ AUTO CAL input/output ⑬ O input/output terminal... - Page 10 Part name Description ① Grip Used to pull out the interior (base). ② Knurled knob Used to fasten the instrument and case. ③ Power switch Turn ON to supply power to the internal components (excluding the pump). After 3 or 4 seconds the LED indicator lights up. (Refer to 4.2 for pump power supply.) ④...
-
Page 11: Name And Description Of Components On Indication/Operation Panel
2.2 Name and description of components on indication/operation panel 3 Unit indication lamp 4 Day indication 2 Main indication 5 Sub indication 1 Component indication 6 Range changeover key TU TH vol% RANGE MO WE FR vol% RANGE vol% RANGE 7 Function indicator lamp MEAS CAL SET... - Page 12 Part name Description ① Component indication Indicates kind of gas measured. ② Main indication Indicates measured concentration. Also indicates various setpoints for alarm function, auto calibration function (option), etc. ③ Unit indication lamp Indicates unit of measured gas concentration. ④ Day indication Indicates current day or day of starting by means of bar in auto calibration (option) setting mode.
-
Page 13: Installation
3. INSTALLATION DANGER • This unit is not explosion-proof type. Do not use it in a place with explosive gases to prevent explosion, fire or other serious accidents. CAUTIONS • This unit is heavy and should be mounted securely to prevent it from falling. •... -
Page 14: Piping Method
3.2 Piping method DANGER • Use clean pipes of which inside should not be stained with deposits of oil or fat. • Piping joints must be tightened firmly to avoid gas leakage. • Exhaust gas should be discharged to an outdoor safe place to prevent it from staying in the sampling device and indoors. -
Page 15: Sampling
(2) Piping diagram Shown next is an example of the configuration for measuring three components. (When using Zirconia O analyzer) Gas analyzer (ZRF) Sample gas inlet Sample gas outlet Arrange so that sample ga Flow meter outlet is at atmospheric pre... - Page 16 3.3.3 Preparation of standard gas Prepare standard gas for zero point and span point calibration. Zero gas Span gas Gas with concentration of 80% or more of full scale for each component (Span gas in measuring method is gas with concentration of 90% or more of full scale.) When using a Zirconia O analyzer, use air for zero gas.
-
Page 17: Wiring Method
3.4 Wiring method CAUTIONS : Turn OFF all the power before starting a wiring work to prevent a risk of electric shocks. : Be sure to enforce construction of specified grounding. The external terminals are provided on the rear of the instrument. Carry out wiring to each terminal according to the figure. - Page 18 3.4.2 COMP 1 (1st component) input/output terminal This output terminal is used with the standard single-component type, sample switching type or flow differential type. The wiring method is as follows. Instantantaneous value output signal 0 to 1V DC or 4 to 20mA DC Average value Range identification output signal...
- Page 19 COMP1, COMP 2 input/output terminal block <Instantaneous value output> Instantaneous value of 0 to 1V DC or 4 to 20mA DC is outputted. <Moving average output> (option) Specified 1 or 4 moving average value of 0 to 1V DC or 4 to 20mA DC is outputted. <Upper limit alarm contact output>...
- Page 20 3.4.4 O input/output terminals (option) This is the input/output terminal for the standard type O analyzer. The wiring method is as follows. Instantantaneous value output signal 0 to 1V DC or Range identification 4 to 20mA DC contact output (option) analyzer input Remote range signal...
- Page 21 3.4.5 AUTO CAL input/output terminal (option) This is the output terminal for the auto calibration function. The wiring method is as follows. Auto calibration Auto calibration contact output abnormal contact output Zero gas contact Remote start input output Span gas 1 contact output Span gas 2 contact output...
-
Page 22: Operation
4. OPERATION DANGER • When handling the standard gas such as calibration gas, read the instruction manual of the standard gas carefully and use the gas correctly. CAUTIONS • Avoid continuous operation with the casing drawn out. • During operation, avoid opening the casing and touching the internal parts. Otherwise, you may suffer a burn or shock hazard. -
Page 23: Preparation For Operation
4.2 Preparation for operation (1) Check of piping Check that piping has been made correctly. (2) Purging of analyzer interior When purging is necessary, then flow purge gas for about 3 hours before turning on power. Purge gas SAMPLE GAS INLET OUTLET INLET... -
Page 24: Start Of Measurement
(6) Concentration setting for calibration gas Next set the concentration for the calibration gas. Refer to 5.2 ① , ② for the procedure. (7) Zero calibration Flow zero calibration gas and calibrate the zero point. Refer to 5.2 ⑧ for the key operation for zero calibration. -
Page 25: Operation Of Indication/Operation Panel
5. OPERATION OF INDICATION/OPERATION PANEL 5.1 Outline of indication/operation panel This panel consists of the following functions. Function and key operation Main indication Sub indication Function lamp Page Measured value Range MEAS lamp Measurement mode FUNC Setting of calibration density Zero point calibra- Range CAL SET... - Page 26 Function and key operation Main indication Sub indication Function lamp Page (Option) Auto calibration Hour & minute Day of week AUTO CAL Present time setting flickers. FUNC Auto calibration Hour & minute Day of week AUTO CAL start time setting lamp flickers.
-
Page 27: General Operation
5.2 General operation The measuring mode is assumed when power is turned ON. The gas concentration appears on the main indication, while the range being used appears on the sub indication. Gas concentration indication Range indication Advice on Operation • When selecting the range High range is selected by pressing this key. - Page 28 • For releasing zero or span ZERO SPAN If a mistake has been made in zero or span calibration, then perform a Key was pressed by mistake. reset in the following way. The figure at the right shows an ZERO SPAN example.
-
Page 29: ① Calibration Concentration Setting (When Not Using Zirconia O 2 Analyzer)
q q q q q Calibration concentration setting (when not using Zirconia O analyzer) When not using a Zirconia O analyzer, then set a span value for the calibration concentration setting. (Zero point calibration concentration is fixed at zero.) Set the calibration gas concentration (span value). When FUNC key is pressed in the measuring status, the previously set span value will appear on the main indica- tion. - Page 30 Press the CAL key. “ ” appears in the main indica- tion and “ ” appears in the sub indication. At each press of the key, the setting is changed in the order of “ → → → ”. After selecting, press the ENT key. The data is stored in ∧...
-
Page 31: ② Calibration Concentration Setting (When Using Zirconia O 2 Analyzer)
w w w w w Calibration concentration setting (when using Zirconia O analyzer) When a Zirconia O analyzer is provided, set the zero (air) point and the span calibration concentra- tion for each components of the O analyzer. Refer to 3.3.3. Preparation of standard gas for the concentration of calibration gas to be used. - Page 32 = Setting for each components = • Setting of span calibration concentration Press the CAL key in the status where the digit of the O analyzer main indication is flashing via the zero (air) point calibration concentration setting. The previously set span value will now appear on the main indication.
- Page 33 Press the CAL key. “ ” appears in the main indica- tion and “ “ appears in the sub indication. At each press of the key, the setting is changed in the order of “ → → → ”. ∧ After selecting, press the ENT key.
-
Page 34: ③ Alarm Value Setting (Option)
e e e e e Alarm value setting (option) Contents of alarm value Set the upper and lower limit alarms and output an alarm. setting indication Setting can be made for each component and each range. Press FUNC key in the measuring status and “ ”... - Page 35 To make the alarm function invalid For making the alarm function invalid, then set the upper limit alarm value to “ ” and the lower limit alarm value to “ ” for each component and each range. Note: Use the following hysteresis setting as a reference when setting the hysteresis for the alarm value.
-
Page 36: ④ Hold Setting
r r r r r Hold setting This is used when calibrating for holding the output signal FUNC at the value just before entering calibration. (The indica- tion is not held.) The hold function is settable for each component. Set to OFF when not using. HOLD Press the FUNC key in the measuring status and COMP... - Page 37 Hold function <Output hold functions after manual calibration> The following shows the output hold function after manual calibration (zero or span). The hold function is cleared automatically after 30 minutes or it can be cleared by key operation (manual). 1. Operation ZERO C A L key Calibration...
-
Page 38: ⑤ Remote Range Setting (Option)
t t t t t Remote range setting (option) This is used for selecting the range via an external signal. FUNC This setting should be OFF when remote range is not used. Press the FUNC key in the measuring status and “... -
Page 39: ⑥ Auto Calibration (Option)
y y y y y Auto calibration (option) As an option with this analyzer, the signals from the input/output terminals on the rear panel can be used for driving an external solenoid valve and introducing standard gas, whereby zero point and span can be calibrated automatically. - Page 40 Example where auto calibration gas flow mode 5 is set Auto calibration start time Auto calibration end time Under mesurement Under Under auto calibration mesure- Next process ment Substitution Span Span Span Zero gas gas 1 gas 2 gas 3 Gas flow time Auto calibration gas flow time...
- Page 41 y y y y y -1 Current time setting Set the current time and day of the week. FUNC Press the FUNC key in the measuring status. The AUTO CAL LED of the function indicating lamps SU TU TH will flash. MO WE FR The main indication shows the hour and minute via AUTO CAL...
- Page 42 y y y y y -2 Auto calibration start time setting When FUNC key is pressed at the current time indica- SU TU TH tion, the auto calibration start time and day will appear on MO WE FR the main and sub indications. The AUTO CAL LED of Flashes the function indicating lamps will flash.
- Page 43 y y y y y -3 Auto calibration cycle setting The calibration cycle is settable in either ‘days’ or ‘hours’. Press the FUNC key at the calibration start time indica- tion and “ ” will appear. The AUTO CAL LED of the function indicating lamps FUNC will flash.
- Page 44 y y y y y -4 Calibration gas flow time setting Press the FUNC key at the calibration cycle indication and “ ” will appear. The AUTO CAL LED of the function indicating lamps will flash. FUNC Press the key and the auto calibration gas flow time is settable.
- Page 45 y y y y y -5 Calibration gas flow mode setting Select a calibration gas flow mode according to the num- ber of components to be calibrated. Press the FUNC key at the calibration gas flow time indication and “ ”...
- Page 46 y y y y y -6 Auto calibration ON/OFF setting Select whether or not to carry out auto calibration. Set to “ ” when calibration will not be made. FUNC Press the FUNC key at the calibration gas flow mode indication and “...
-
Page 47: ⑦ Key Lock On/Off Setting
u u u u u Key lock ON/OFF setting This function is intended to prevent erroneous key operation. By pressing the key lock at “ ” keys other than the FUNC key will be inoperable. To release the function, set at “ ”. -
Page 48: ⑧ Zero Calibration
i i i i i Zero calibration This is used for adjusting the zero point. Flow the zero gas and wait until the indication stabilizes. When the Zirconia O analyzer is used, use air as the zero gas. Note1) ZERO When the indication has stabilized, select the measuring range to be calibrated by using the keys. -
Page 49: ⑨ Span Calibration
o o o o o Span calibration Carry out span calibration by flowing calibration gas at the concentration set as a span value. Flow the calibration gas at 0.5 r/minute. Wait until the indication stabilizes, and then conduct span SPAN calibration. -
Page 50: Maintenance Mode
6. MAINTENANCE MODE This mode should be used only for maintenance, inspection, repair or adjustment. When operation for maintenance mode is required, contact our office in advance. The maintenance mode refers to setting and adjustment in the following five modes. •... -
Page 51: Response Time Setting
6.1 Response time setting Press CAL key while “ ” display lamp is flickering, and “ ” will be displayed. At this time, the sub display lamp flickers. Press COMP key to select desired setting component. Next, set the response time of the electric system. Numerical value (1-199, O : 1-49) is set from the top digit （ ... -
Page 52: Optical Balance Adjustment
6.3 Optical balance adjustment When the sample cell is reassembled after having been detached for cleaning or the like, this optical zero adjustment should be performed before use. When this mode is assumed, the input signal from the measurement detector is displayed on the main indicator while the input signal from the interference compensating detector is displayed on the sub indicator. -
Page 53: Interference Compensation Coefficient Setting
6.4 Interference compensation coefficient setting This is used for adjusting the interference compensation when there is much interference. In this mode, adjust so that an indicated value is within 2% of gas concentration of full scale while flowing interference gas (0°C or 2°C saturated H O). -
Page 54: Indication And Clearing Of Integrated Drift Value
6.5 Indication and clearing of integrated drift value When the “ ” indication flashing, press the CAL key and indicate the zero point drift amount on the main indicator and the span point drift amount on the sub indicator for each component. Select the range with the keys and the integrated zero point and span point drift values will be indicated for that... -
Page 55: Maintenance
7. MAINTENANCE DANGER • When the inner case needs to open for adjustment of the optical system, etc., the inside of the analyzer and the measuring gas line should be purged completely with zero gas to avoid poisoning, fire or explosion due to gas leaks. CAUTIONS •... -
Page 56: Periodical Inspection
7.2 Periodical inspection 7.2.1 How to clean sample cell (pipe cell) This instrument has been carefully adjusted before shipment from the factory. If it should require readjustment, then please contact Fuji. (1) Turn off the power switch, stop the flow of sample gas and flow zero gas for a few minutes. - Page 57 7.2.2 How to clean sample cell (block cell) (1) Turn off the power switch, stop the flow of sample gas and flow zero gas for a few minutes. Loosen the knurled knobs on the front panel and pull out the analyzer interior by Knurled knob means of the grips.
- Page 58 Infrared-ray transmitting window Retaining ring O ring Sample gas inlet Call Gas inlet pipe fixing screw Cap unt Sample gas outlet The infrared-ray transmitting window and retaining ring are attached with an adhesive. Fig. 7-1 Sample cell structure...
- Page 59 Use the exclusive cells assembling tool (furnished). Cell assembling tool Retaining ring O ring retainer Outer O ring Inner O ring Infrared-ray transmitting window Sample gas outlet Sample gas inlet Sample cell section Reference cell section Bolt hole (for bolt which fastens together distribu- tion cell and detector) Sample cell structure (for cells with length of 32, 16, 8, 4, 2mm)
- Page 60 7.2.3 Optical zero adjustment method (Optical balance method) When the sample cell is reassembled after having been removed for cleaning or the like, this adjustment should be carried out before use. Following is the adjustment procedure. (1) First carry out electrical zero adjustment. With the power turned off, detach the connectors CN2 and 3 (for 1st component) and CN4 and 5 (for 2nd component) leading from the detector which are connected with the main PCB (2).
- Page 61 7.2.4 Interference compensation adjusting method Since this adjustment requires highly trained technique, please contact Fuji if it becomes necessary. Adjust the interference compensation if the effect of interference is large (more than ±2%FS of full Dry nitrogen 0.5r/min. scale). 1) In case standard type and flow differential type systems (1) After warming up the instrument, supply dry nitrogen at a rate of 0.5r/minute from...
- Page 62 2) In case of sample switching system (1) After warming up the instrument, supply Dry nitrogen 1r/min. dry nitrogen at a rate of 1r/minute from the measured gas inlet. Detach the pipe from the reference cell gas inlet (light source side) and flow dry nitrogen at 1r/minute.
-
Page 63: Error Codes And Remedies
If the cause of any fault cannot be determined despite reference to the instruction manual, be sure to contact your dealer or Fuji Electric’s technician in charge of adjustment. If the instrument is disassembled carelessly, you may have a shock hazard or injury. - Page 64 Error codes and countermeasures Error code Contents of error code State of analyzer Cause Check and countermeasure Trouble with digital Not operated until • Malfunction due to • Turn ON the power supply. circuit (memory read/ trouble is removed. noise When the analyzer operates write impossible) •...
