- Page 1 Digital Wheelchair Scale w/ Seat 350-10-4 Software Revision 11439 Operation Manual 151806 - Rev B...
-
Page 3: Table Of Contents
Course descriptions and dates can be viewed at www.ricelake.com or obtained by calling 715-234-9171 and asking for the training department © 2014 Rice Lake Weighing Systems. Specifications subject to change without notice. All rights reserved. Rice Lake Weighing Systems is an ISO 9001 registered company. - Page 4 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars. Wheelchair Scale with Seat Operation Instructions...
-
Page 5: Introduction
Introduction The Rice Lake 350-10-4 Digital Wheelchair Scale with seat is a user-friendly, quality scale, designed for safe weighing of the handicapped and mobility challenged individuals. Movement compensation technology ensures sound, accurate weighments. The scale has roll on ramp access and a comfortable seat. -
Page 6: Safety
Do not operate or work on this equipment unless you have read and understand instructions in the manual. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals. Proper care is your responsibility. -
Page 7: Scale Assembly
Scale Assembly Unpacking Your Scale Place the unopened box in an open area that has ample room for unpacking the scale. Parts contained in the shipping box include: • The scale • This manual • Small box containing AA batteries (6) and scale feet. Repacking If the Digital Wheelchair Scale with seat must be returned for modification, calibration or repair, it must be properly packed with sufficient packing materials. -
Page 8: Attaching The Feet To The Scale
Attaching the Feet to the Scale The Rice Lake Digital Wheelchair Scale comes with four feet that must be attached to the scale base for proper operation. The four feet are located in the parts box in the original shipping box. Prior to laying the scale base on the floor, use the following steps to attach the feet to the scale. -
Page 9: Handle Setup
Handle Setup 1. Loosen the handles and unfold and set upright (handles shown in Figure 3-3). 2. Tighten the two hinges on the wheelchair scale by rotating the two handles. This will secure the handrail mounted indicator. Figure 3-3. Secure the Handrail by Tightening the Durable Hinges 3. - Page 10 straighten out and rest on the scale platform. Figure 3-5. Secure Bracket 5. Ensure the retaining bracket is secure (as shown in Figure 3-5). Caution The retaining bracket must click into place. If it doesn’t click it may not be secure and any weight applied to it may cause it to collapse.
-
Page 11: Inserting Batteries
Inserting Batteries The six AA batteries that come with the scale offer an average of 25 hours of continuous use. To install the batteries: 1. Open the battery chamber cover by loosening the thumbscrew. 2. Insert batteries into the battery chamber as shown in Figure 3-7. Figure 3-7. -
Page 12: Scale Operation
Scale Operation The Rice Lake Digital Wheelchair Scale with seat display has various front panel keys as shown in Figure 4-1. Figure 4-1. Front Panel Display Keys Key Descriptions Table 4-1 describes each of the key functions. Name Function On/Off Switches the scale on or off. -
Page 13: Weighing
Used to adjust height input (0.5 in/0.5 cm) while in BMI mode. Adjusts the value of the flashing digit/number. Table 4-1. Rice Lake Digital Wheelchair Scale Key Functions Caution The keys on the front panel display are very sensitive so only a gentle pushing motion is required to obtain results. -
Page 14: Toggle Tare
Toggle Tare Use the following steps to use the Toggle Tare function. 1. When the weight is set to , press the key. TARE 2. The default tare value is displayed (default is programmed to be 33.0 lb/15.0 kg), while the zero is flashing. -
Page 15: Rs-232 Communication
PATIENT BMI 20.8 USB Connection The Rice Lake Digital Wheelchair Scale with seat has the capability of connecting to a PC using a USB connection and a USB cable (not included). That connection location is shown in Figure 5-1. USB Connection... - Page 16 The USB driver can be downloaded from the Rice Lake Weighing Systems website at the following location; http://www.ricelake.com/software.aspx Select Medical/Health Scales, Software and Get Downloads. Opening any product will show a USB Driver download.
- Page 17 6. If you want to verify the installation, you can view the driver by looking at the device manager of your system. 7. To print a ticket using the USB driver, open the software driver (shown above) and the port assigned to that driver is shown.
-
Page 18: Troubleshooting And Testing
Table 6-1. Troubleshooting Table for the Rice Lake Scale Line Maintenance The following section provides instructions for maintaining and cleaning the Rice Lake line of scales. Maintenance operations other than those described in this section should be performed by qualified service personnel. -
Page 19: Digital Wheelchair Scale Specifications
Wheelchair Scale w/ Seat 1000 lb (453 kg) 0.2 lb (0.1kg) Certifications and Approvals RoHS Compliant Dimensions Platform Dimensions 48.5 in W x 29.5 in L x 2.3 in H Wheelchair Scale with Seat Operation Manual - Rice Lake Digital Wheelchair Scale Specifications... -
Page 20: For More Information
For More Information System Manuals • 350-10-4 Digital Wheelchair Scale w/ Seat Technical Manual, PN 152418 Web Site • http://www.ricelake.com/health Contact Information Hours of Operation Knowledgeable customer service representatives are available 6:30 a.m. - 6:30 p.m. Monday through Friday and 8 a.m. -
Page 21: Digital Wheelchair Scale Limited Warranty
Rice Lake Digital Wheelchair Scale Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years. - Page 22 Wheelchair Scale with Seat Operation Manual...
- Page 24 230 W. Coleman St. Rice Lake, WI 54868 USA U.S. 800-472-6703 Canada/Mexico 800-321-6703 International 715-234-9171 Europe +31 (0) 88 2349171 www.ricelake.com www.ricelake.mx www.ricelake.eu www.ricelake.co.in m.ricelake.com PN 151806, Rev B 08/2014...
