IMBA-30104
Quick Installation Guide
Version 1.0
Jan. 13, 2009
Package Contents
IMBA-30104 package includes the following items:
1 x IMBA-30104 Single Board Computer
1 x ATA66 IDE Flat cable
1 x Dual RS-232 cable with bracket
4 x SATA cable
1 x Mini Jumper Pack
1 x IO Shielding
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology IMBA-30104
Summary of Contents for IEI Technology IMBA-30104
-
Page 1: Quick Installation Guide
IMBA-30104 Quick Installation Guide Version 1.0 Jan. 13, 2009 Package Contents IMBA-30104 package includes the following items: 1 x IMBA-30104 Single Board Computer 1 x ATA66 IDE Flat cable 1 x Dual RS-232 cable with bracket 4 x SATA cable... -
Page 2: Specifications
Specifications CPU: Intel® LGA775 socket Intel® Core System Chipset: Intel® 3010 + ICH7R BIOS: AMI BIOS Label System memory: 4 x 240pin Dual-channel DDR2 533/667 MHz DIMMs with ECC support up to 8GB Ethernet: Dual PCIe x1 interface Intel® 82574L GbE controller I/O Interface: 4 x RS-232 (1 on rear, 3 by pin header) 8 x USB2.0 (4 on rear, 4 by pin header) -
Page 3: Ordering Information
3.3V@ 1.03A, 5V@ 4.72A, 12V@ 0.31A (Intel® Core™ 2 Duo E6700 2.66GHz with 4 x DDR2 512MB with 667MHz) 3D Mark 2001SE Operating Temperature: 0 ~ 60°C( 32 ~ 140°F) Operating Humidity: 5%~95% non-condensing Dimension: ATX, 305mm x 244mm Weight : GW 1.3 Kg/NW : 0.8 Kg Ordering Information IMB-30104-R10: ATX Motherboard with Intel®... -
Page 4: Jumpers Setting And Connectors
Jumpers setting and Connectors LABEL FUNCTION J_CMOS1 CMOS state setting jumper KB_MS1 PS/2 KB/MS connector 3IN1_DSUB1 VGA COM1 and LPT port connectors LAN1_USB01 LAN and USB Port Connectors LAN2_USB23 AUDIO_CV1 Audio Input and Output Connectors FP_AUDIO1 Front Audio Connector CD_IN1 Internal CD-IN Connector SPDIF1 Internal SPDIF Connector... - Page 5 J_CMOS1 : Clear CMOS Setup J_CMOS1 DESCRIPTION Keep CMOS Setup (default)* (Normal Operation) Short 2-3 Clear CMOS Setup FP_AUDIO1 : Front Audio Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MIC_L MIC_R Audio Detect LINE out-R Jack Detection LINE out-L SPDIF1 : CD_IN1 : Internal SPDIF connector Internal CD IN Connector...
- Page 6 COM2 ~ COM4 : Internal Serial Port Connectors (RS-232) DESCRIPTION DESCRIPTION DCD# DSR# RTS# CTS# DTR# F_PANEL1 : External Switches and Indicators panel PIN DESCRIPTION PIN DESCRIPTION Power LED+ Speaker+ Power LED Speaker Power LED- PWRBTN+ Speaker- PWRBTN PWRBTN- RESET HDLED+ Reset+ HDDLED...
- Page 7 TPM1: Trusted Platform Module connector DESCRIPTION DESCRIPTION FWHPCLK LFRAME# PCIRST# VCC(+5V) LAD3 LAD2 VCC3(+3.3V) LAD1 LAD0 SMBCLK SMBDATA 3VDUAL(+3.3VSB) SERIRQ CLKRUN# LPCPD# LDRQ# PCIE_12V1: PCIe POWER Source Connector BAT1 : PIN NO. DESCRIPTION Coin battery holder VCC +5V DESCRIPTION BAT+ BAT-(GND) VCC +12V CPU12V1 : CPU POWER Connector...
-
Page 8: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
