IMBA-Q454-R10 User Manual
IMBA-Q454
MODEL:
IMBA-Q454-R10
ATX Motherboard for Intel® Core™2 Duo/ Quad with
1333/1066/800 MHz FSB, Dual Gigabit GbE, Intel® AMT 5.0, PCI,
PCIe x4, PCIe x16, VGA, SATA II with RAID 0,1,5,10, HD Audio,
RoHS Compliant

User Manual

Page i
Rev. 1.01 10 July, 2009

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology IMBA-Q454-R10

Summary of Contents for IEI Technology IMBA-Q454-R10

  • Page 1: User Manual

    IMBA-Q454-R10 User Manual IMBA-Q454 MODEL: IMBA-Q454-R10 ATX Motherboard for Intel® Core™2 Duo/ Quad with 1333/1066/800 MHz FSB, Dual Gigabit GbE, Intel® AMT 5.0, PCI, PCIe x4, PCIe x16, VGA, SATA II with RAID 0,1,5,10, HD Audio, RoHS Compliant User Manual Page i Rev.
  • Page 2 IMBA-Q454-R10 User Manual Revision Date Version Changes 10 July, 2009 1.01 Minor edit 6 March, 2009 1.00 Initial release Page ii...
  • Page 3 IMBA-Q454-R10 User Manual Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    2.3.1 Package Contents..................... 26 2.3.2 Optional Items....................27 3 CONNECTOR PINOUTS................... 29 3.1 P ..............30 ERIPHERAL NTERFACE ONNECTORS 3.1.1 IMBA-Q454-R10 Layout.................. 30 3.1.2 Peripheral Interface Connectors ..............31 3.1.3 External Interface Panel Connectors............... 32 3.2 I ..............33 NTERNAL ERIPHERAL ONNECTORS 3.2.1 ATX CPU Power Connector ................
  • Page 5 IMBA-Q454-R10 User Manual 3.2.10 PCI Express x4 Slot..................42 3.2.11 PCI Express x16 Slot..................44 3.2.12 PCI Slot......................46 3.2.13 SATA Drive Connectors ................. 49 3.2.14 S/PDIF Connector ..................50 3.2.15 Serial Port Connectors .................. 51 3.2.16 SPI Flash Connector..................52 3.2.17 USB Connectors.....................
  • Page 6 IMBA-Q454-R10 User Manual 4.6 E ........... 82 XTERNAL ERIPHERAL NTERFACE ONNECTION 4.6.1 Keyboard and Mouse ..................82 4.6.2 LAN ........................83 4.6.3 Parallel Device Connection................84 4.6.4 Serial Device....................85 4.6.5 USB ........................86 4.6.6 VGA Monitor....................87 4.6.7 Audio Connector ....................88 5 BIOS SETUP ........................
  • Page 7 IMBA-Q454-R10 User Manual 5.5.3 Hard Disk Drives ................... 128 5.5.4 CD/DVD Drives ..................... 129 5.5.5 Removable Drives ..................130 5.6 S ....................... 131 ECURITY 5.7 C ........................ 132 HIPSETS 5.7.1 Northbridge Chipset Configuration............... 133 5.7.2 Southbridge Chipset Configuration ............... 135 5.8 E...
  • Page 8 IMBA-Q454-R10 User Manual 8.4.3 Smart Fan Setting ..................184 8.4.3.1 On/Off Mode................... 184 8.4.3.2 PWM Mode..................... 184 8.4.3.3 Automatic Mode..................185 8.5 T ....................186 EMPERATURE 8.5.1 Refresh Time Setting..................187 8.5.2 High Limit Value and Low Limit Value Setting ..........188 8.6 C...
  • Page 9 Figure 3-16: Serial Port Connectors Pinout Locations.............52 Figure 3-17: SPI Flash Connector Pinouts.................53 Figure 3-18: USB Connector Pinout Locations .................54 Figure 3-19: IMBA-Q454-R10 External Interface Connectors...........55 Figure 3-20: Audio Connector .....................55 Figure 3-21: Ethernet Connector....................56 Figure 3-22: PS/2 Connector .......................57 Figure 3-23: Parallel Port Connector Location ................58...
  • Page 10 IMBA-Q454-R10 User Manual Figure 4-2: Remove the CPU Socket Protective Shield ............66 Figure 4-3: Open the CPU Socket Load Plate................66 Figure 4-4: Insert the Socket LGA775 CPU................67 Figure 4-5: Cooling Kit .........................68 Figure 4-6: Securing the Heat sink to the PCB Board ..............69 Figure 4-7: Installing a DIMM.......................71...
  • Page 11 IMBA-Q454-R10 User Manual Figure 6-15: LAN Driver File ..................... 150 Figure 6-16: LAN Driver Welcome Screen ................150 Figure 6-17: LAN Driver License Agreement ................151 Figure 6-18: LAN Driver Setup Options................... 151 Figure 6-19: LAN Driver Installation Ready Window.............. 152 Figure 6-20: LAN Driver Installation Progress................
  • Page 12 IMBA-Q454-R10 User Manual Figure 7-9: Enable Network Interface ..................172 Figure 7-10: Exit......................... 173 Figure 7-11: Intel® AMT Web Address ..................174 Figure 7-12: Intel® AMT Web Login Dialog................175 Figure 7-13: Intel® AMT Web Interface..................176 Figure 8-1: iSMM Installation Welcome Screen..............178 Figure 8-2: iSMM Installation Customer Information .............
  • Page 13 IMBA-Q454-R10 User Manual List of Tables Table 1-1: IMBA-Q454-R10 Specifications .................23 Table 2-1: Packing List.........................27 Table 2-2: Optional Items......................28 Table 3-1: Peripheral Interface Connectors ................32 Table 3-2: Rear Panel Connectors ....................32 Table 3-3: ATX Power Connector Pinouts .................33 Table 3-4: ATX Power Connector Pinouts .................35 Table 3-5: Audio Connector Pinouts ..................36...
  • Page 14 IMBA-Q454-R10 User Manual Table 4-1: Jumpers ........................72 Table 4-2: Clear CMOS Jumper Settings..................73 Table 4-3: iTPM Setup Jumper Settings ..................74 Table 5-1: BIOS Navigation Keys ....................92 Page xiv...
  • Page 15 IMBA-Q454-R10 User Manual BIOS Menus BIOS Menu 1: Main ........................93 BIOS Menu 2: Advanced ......................95 BIOS Menu 3: CPU Configuration ....................96 BIOS Menu 4: IDE Configuration....................97 BIOS Menu 5: IDE Master and IDE Slave Configuration ............99 BIOS Menu 6: IDE Master and IDE Slave Configuration ............103 BIOS Menu 7: Super IO Configuration..................

  • Page 16: Introduction

    IMBA-Q454-R10 User Manual Chapter Introduction Page 16...

  • Page 17: Imba-Q454-R10 Motherboard Overview

    1.1 IMBA-Q454-R10 Motherboard Overview Figure 1–1: IMBA-Q454-R10 The IMBA-Q454-R10 is an ATX form factor industrial PC motherboard. The ATX form factor is a relatively large form factor, providing room for extra features and capabilities including more powerful processors that benefit from the larger dimensions and better cooling of ATX computer cases.

  • Page 18: Benefits

    The system is always available and will reboot if the system crashes Powerful processor options are ideal for computing intensive applications Data is protected through fast and reliable SATA RAID storage 1.1.2 Features Some of the IMBA-Q454-R10 motherboard features are listed below: ATX form factor RoHS compliant LGA 775 CPU socket PCI and PCIe expansion slots Four DDR2 DIMMs up to 2.0 GB each supported...

  • Page 19: External Peripheral Interface Panel Dimensions

    IMBA-Q454-R10 User Manual Figure 1-2: IMBA-Q454-R10 Dimensions (mm) 1.1.4 External Peripheral Interface Panel Dimensions External peripheral interface connector panel dimensions are shown in Figure 1-3. Figure 1-3: External Interface Panel Dimensions (mm) Page 19...

  • Page 20: Data Flow

    IMBA-Q454-R10 User Manual 1.2 Data Flow F igure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Block Diagram Page 20...

  • Page 21: Technical Specifications

    IMBA-Q454-R10 User Manual 1.3 Technical Specifications: IMBA-Q454-R10 motherboard technical specifications are listed in the table below. Specification/Model IMBA-Q454-R10 Form Factor LGA775 Intel® Core™2 Quad (Yorkfield) CPU Supported LGA775 Intel® Core™2 Duo (Wolfdale and Conroe) LGA775 Intel® Celeron® (Conroe L) 800 MHz, 1066 MHz or 1333 MHz Front Side Bus (FSB) Intel®...
  • Page 22 IMBA-Q454-R10 User Manual Specification/Model IMBA-Q454-R10 Expansion Four PCI slots PCIe One PCIe x4 slot One PCIe x16 slot (PCI Express Graphics interface) I/O Interface Connectors Audio Connectors One external audio jack (line-in, line-out, mic-in) Two internal audio connectors (front panel pin header and...

  • Page 23: Table 1-1: Imba-Q454-R10 Specifications

    FSB and 2.0 GB of 800 MHz DDR2 memory running 3DMark 2001SE 0ºC ~ 60ºC (requires cooler and silicone heat sink paste) Operating temperature 0% ~ 95% (non-condensing) Humidity Physical Specifications 305mm x 244mm Dimensions Weight GW/NW 1200g/600g Table 1-1: IMBA-Q454-R10 Specifications Page 23...

  • Page 24: Unpacking

    IMBA-Q454-R10 User Manual Chapter Unpacking Page 24...

  • Page 25: Anti-Static Precautions

    IMBA-Q454-R10 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IMBA-Q454-R10. Dry climates are especially susceptible to ESD. It is therefore critical to strictly adhere to the following anti-static precautions whenever the IMBA-Q454-R10, or any other electrical component, is handled.

  • Page 26: Unpacking Checklist

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the IMBA-Q454-R10 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 27: Optional Items

    IMBA-Q454-R10 User Manual Quantity Item and Part Number Image Quick Installation Guide Table 2-1: Packing List 2.3.2 Optional Items The IMBA-Q454-R10 is shipped with the following components: Item and Part Number Image CPU cooler (P/N: CF-520-RS) CPU cooler (P/N: CF-775A-RS)

  • Page 28: Table 2-2: Optional Items

    IMBA-Q454-R10 User Manual Item and Part Number Image PCIe 16X SDVO interface VGA graphic card SDVO-100VGA-R10 USB cable 4-port with bracket (P/N: CB-USB14-RS) USB cable, Dual port with bracket (P/N: CB-USB02-RS) Table 2-2: Optional Items Page 28...

  • Page 29: Connector Pinouts

    IMBA-Q454-R10 User Manual Chapter Connector Pinouts Page 29...

  • Page 30: Peripheral Interface Connectors

    IMBA-Q454-R10 User Manual 3.1 Peripheral Interface Connectors Section 3.1.2 shows peripheral interface connector locations. Section 3.1.2 lists all the peripheral interface connectors seen in Section 3.1.2. 3.1.1 IMBA-Q454-R10 Layout F igure 3-1 shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers.

  • Page 31: Peripheral Interface Connectors

    IMBA-Q454-R10 User Manual 3.1.2 Peripheral Interface Connectors T able 3-1 shows a list of the peripheral interface connectors on the IMBA-Q454-R10. Detailed descriptions of these connectors can be found below. Connector Type Label ATX power connector, CPU 4-pin ATX CPU12V1...

  • Page 32: External Interface Panel Connectors

    USB67 USB89 USB1011 Table 3-1: Peripheral Interface Connectors 3.1.3 External Interface Panel Connectors T able 3-2 lists the rear panel connectors on the IMBA-Q454-R10. Detailed descriptions of these connectors can be found in Section 3.1. Connector Type Label Audio connectors...

  • Page 33: Internal Peripheral Connectors

    Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the IMBA-Q454-R10. 3.2.1 ATX CPU Power Connector CN Label:...

  • Page 34: Atx Power Connector

    IMBA-Q454-R10 User Manual 3.2.2 ATX Power Connector CN Label: ATX1 24-pin ATX (2x24) CN Type: CN Location: F igure 3-3 CN Pinouts: T able 3-4 The ATX connector is connected to an external ATX power supply. Power is provided to the system, from the power supply through this connector.

  • Page 35: Audio Connector

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION +VCC5SB +5 V +12 V +5 V +12 V +5 V +3.3 V Table 3-4: ATX Power Connector Pinouts 3.2.3 Audio Connector CN Label: FP_AUDIO1 CN Type: 10-pin header CN Location:...

  • Page 36: Digital I/O Connector

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION Microphone left Microphone right PRESENCE Line out right SENSE_SEND Line out left Table 3-5: Audio Connector Pinouts 3.2.4 Digital I/O Connector CN Label: DIO1 CN Type: 10-pin header (2x5) CN Location:...

  • Page 37: Fan Connectors, Cpu And Northbridge

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-6: Digital I/O Connector Pinouts 3.2.5 Fan Connectors, CPU and Northbridge CN Label: CPU_FAN1, NB_FAN1 4-pin header CN Type:...

  • Page 38: Fan Connector, System

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION +12 VCC Rotation Signal Control Table 3-7: CPU Fan Connector Pinouts 3.2.6 Fan Connector, System CN Label: SYS_FAN1 CN Type: 3-pin header CN Location: F igure 3-7 CN Pinouts: T able 3-8 The cooling fan connector provides a 12 V, 500mA current to a system cooling fan. The connector has a "rotation"...

  • Page 39: Floppy Disk Connector

    34-pin header (2x17) CN Type: CN Location: F igure 3-8 CN Pinouts: T able 3-9 The floppy disk connector is connected to a floppy disk drive. The IMBA-Q454-R10 supports the following floppy disk drives: 360 KB 720 KB 1.2 MB 1.44 MB 2.88 MB...

  • Page 40: Front Panel Connector

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION REDUCE WRITE INDEX# MOTOR ENABLE A# DRIVE SELECT B# DRIVE SELECT A# MOTOR ENABLE B# DIRECTION# STEP# WRITE DATA# WRITE GATE# TRACK 0# WRITE PROTECT# READ DATA# SIDE 1 SELECT# DISK CHANGE# Table 3-9: 34-pin FDD Connector Pinouts 3.2.8 Front Panel Connector...

  • Page 41: Infrared Interface Connector (5-Pin)

    IMBA-Q454-R10 User Manual HDD LED Speaker Figure 3-9: Front Panel Connector Pinout Locations FUNCTION DESCRIPTION FUNCTION DESCRIPTION Power LED LED +5 V Speaker +5 V Ground Power Button Power Button+ Speaker Power Button- Reset HDD LED +5 V RESET- HDLED- Table 3-10: Front Panel Connector Pinouts 3.2.9 Infrared Interface Connector (5-pin)

  • Page 42: Pci Express X4 Slot

    IMBA-Q454-R10 User Manual The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces. Figure 3-10: Infrared Connector Pinout Locations PIN NO. DESCRIPTION IR-RX IR-TX Table 3-11: Infrared Connector Pinouts 3.2.10 PCI Express x4 Slot...

  • Page 43: Figure 3-11: Pcie X4 Connector Locations

    IMBA-Q454-R10 User Manual Figure 3-11: PCIe x4 Connector Locations SIDE A SIDE B NAME NAME NAME NAME +12 V +12 V +12 V +12 V +12 V SMCLK SMDAT +3.3 V +3.3 V +3.3 V 3.3 V RESET WAKE# REFCLK+...

  • Page 44: Pci Express X16 Slot

    IMBA-Q454-R10 User Manual SIDE A SIDE B HSIp(3) HSIn(3) Table 3-12: PCIe x4 Pinouts 3.2.11 PCI Express x16 Slot CN Label: PCIEX16_1 PCIe x16 slot CN Type: CN Location: F igure 3-12 CN Pinouts: T able 3-13 (Side A) T able 3-14 (Side B) PCIe x16 expansion devices can be inserted into the PCIe x16 slot.

  • Page 45: Table 3-13: Pcie X16 Side A Pinouts

    IMBA-Q454-R10 User Manual NAME NAME NAME NAME JTAG2 HSIn(7) HSIn(12) JTAG3 JTAG4 HSIp(3) RSVD JTAG5 HSIn(3) HSIp(13) +3.3v HSIp(8) HSIn(13) +3.3v RSVD HSIn(8) PWRGD RSVD HSIp(14) REFCLK+ HSIp(4) HSIp(9) HSIn(14) REFCLK- HSIn(4) HSIn(9) HSIp(0) HSIp(15) HSIn(0) HSIp(5) HSIp(10) HSIn(15) HSIn(5)

  • Page 46: Pci Slot

    IMBA-Q454-R10 User Manual NAME NAME NAME NAME HSOn(4) HSOn(9) HSOp(0) HSOn(0) HSOp(15) HSOp(5) HSOp(10) HSOn(15) PRSNT#2 HSOn(5) HSOn(10) PRSNT#2 HSOp(1) RSVD#2 HSOn(1) HSOp(6) HSOp(11) HSOn(6) HSOn(11) Table 3-14: PCIe x16 Side B Pinouts 3.2.12 PCI Slot CN Label: PCI1, PCI2, PCI3 and PCI4...

  • Page 47: Figure 3-13: Pci Slot Location

    IMBA-Q454-R10 User Manual Figure 3-13: PCI Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION TRST -12 V +12 V +5 V +5 V INTA +5 V INTC INTB +5 V INTD RESERVED3 PRSNT1 +5 V RESERVED1 RESERVED4 PRSNT2 Page 47...
  • Page 48 IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION 3.3 V_AUX RESERVED2 +5 V +5 V AD30 AD31 +3.3 V AD29 AD28 AD26 AD27 AD25 AD24 +3.3 V IDSEL C/BE3 +3.3 V AD23 AD22 AD20 AD21 AD19 AD18 +3.3 V...

  • Page 49: Sata Drive Connectors

    IMBA-Q454-R10 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3 V AD14 AD13 AD11 AD12 AD10 C/BE0 +3.3 V +3.3 V +5 V +5 V REQ64 ACK64 +5 V +5 V +5 V +5 V Table 3-15: PCI Slot 3.2.13 SATA Drive Connectors...

  • Page 50: S/Pdif Connector

    IMBA-Q454-R10 User Manual Figure 3-14: SATA Drive Connector Locations PIN NO. DESCRIPTION Table 3-16: SATA Drive Connector Pinouts 3.2.14 S/PDIF Connector CN Label: SPDIF1 5-pin header CN Type: CN Location: F igure 3-15 CN Pinouts: T able 3-17 Page 50...

  • Page 51: Serial Port Connectors

    IMBA-Q454-R10 User Manual Use the SPDIF connector to connect digital audio devices to the system. Figure 3-15: SPDIF Connector Pinout Locations DESCRIPTION 5 V audio SPDIF out GND audio SPDIF in Table 3-17: SPDIF Connector Pinouts 3.2.15 Serial Port Connectors...

  • Page 52: Spi Flash Connector

    IMBA-Q454-R10 User Manual The 10-pin serial port connectors provide a RS-232 serial communications channels. The serial port connectors can be connected to external RS-232 serial port devices. Figure 3-16: Serial Port Connectors Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION...

  • Page 53: Usb Connectors

    IMBA-Q454-R10 User Manual Figure 3-17: SPI Flash Connector Pinouts DESCRIPTION DESCRIPTION CLOCK Table 3-19: SPI Flash Connector 3.2.17 USB Connectors CN Label: USB45, USB67, USB89 and USB1011 8-pin header (2x4) CN Type: CN Location: F igure 3-18 CN Pinouts: T able 3-20 The 2x5 USB pin connectors each provide connectivity to two USB 1.1 or two USB 2.0...

  • Page 54: External Interface Connectors

    PIN NO. DESCRIPTION DATA- DATA+ DATA+ DATA- Table 3-20: USB Port Connector Pinouts 3.3 External Interface Connectors F igure 3-19 shows the IMBA-Q454-R10 motherboard external interface connectors. The IMBA-Q454-R10 on-board external interface connectors are shown in F igure 3-19: Page 54...

  • Page 55: Audio Connector

    CN Location: F igure 3-19 The three audio jacks on the external audio connector enable the IMBA-Q454-R10 to be connected to external audio devices as specified below. Line In port (Light Blue): Connects a CD-ROM, DVD player, or other audio devices.

  • Page 56: Ethernet Connector

    IMBA-Q454-R10 User Manual 3.3.2 Ethernet Connector CN Label: LAN1_USB01, LAN2_USB23 RJ-45 CN Type: CN Location: F igure 3-19 CN Pinouts: T able 3-21 A 10/100/1000 Mb/s connection can be made to a Local Area Network. DESCRIPTION DESCRIPTION Table 3-21: Ethernet Connector Pinouts Figure 3-21: Ethernet Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow.

  • Page 57: Keyboard And Mouse Connector

    CN Location: F igure 3-19 CN Pinouts: T able 3-23 and F igure 3-22 The IMBA-Q454-R10 has two PS/2 connectors on the mounting bracket for easy connection to a PS/2 keyboard and PS/2 mouse. Figure 3-22: PS/2 Connector PIN NO. DESCRIPTION PIN NO.

  • Page 58: Parallel Port Connector

    IMBA-Q454-R10 User Manual 3.3.4 Parallel Port Connector CN Label: 26-pin box header CN Type: CN Location: F igure 3-19 CN Pinouts: T able 3-24 The 26-pin parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer.

  • Page 59: Serial Port Connector

    IMBA-Q454-R10 User Manual 3.3.5 Serial Port Connector CN Label: COM1 DB-9 connector CN Type: CN Location: F igure 3-19 CN Pinouts: T able 3-25 and F igure 3-24 The RS-232 serial connector provides serial connection in the RS-232 mode. DESCRIPTION...

  • Page 60: Vga Connector

    IMBA-Q454-R10 User Manual The USB combo port and LAN/USB combo port provides connectivity to five additional USB devices. USB devices connect directly to the USB connectors on the rear panel. DESCRIPTION DESCRIPTION +5 V +5 V Table 3-26: USB Connector Pinouts 3.3.7 VGA Connector...

  • Page 61: Installation

    IMBA-Q454-R10 User Manual Chapter Installation Page 61...

  • Page 62: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IMBA-Q454-R10. Dry climates are especially susceptible to ESD. It is therefore critical to strictly adhere to the following anti-static precautions whenever the IMBA-Q454-R10, or any other electrical component, is handled.

  • Page 63: Installation Considerations

    IMBA-Q454-R10 is installed. All installation notices pertaining to the installation of IMBA-Q454-R10 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the IMBA-Q454-R10 and injury to the person installing the motherboard. 4.2.1 Installation Notices...

  • Page 64: Cpu, Cpu Cooling Kit And Dimm Installation

    Running a CPU without a cooling kit may also result in injury to the user. The CPU, CPU cooling kit and DIMM are the most critical components of the IMBA-Q454-R10. If one of these component is not installed the IMBA-Q454-R10 cannot run. 4.3.1 Socket LGA775 CPU Installation...

  • Page 65: Figure 4-1: Intel Lga775 Socket

    The LGA775 socket is shown in F igure 4-1. Figure 4-1: Intel LGA775 Socket To install a socket LGA775 CPU onto the IMBA-Q454-R10, follow the steps below: WARNING: When handling the CPU, only hold it on the sides. DO NOT touch the pins at the bottom of the CPU.

  • Page 66: Figure 4-2: Remove The Cpu Socket Protective Shield

    IMBA-Q454-R10 User Manual Figure 4-2: Remove the CPU Socket Protective Shield Step 2: Open the socket. Disengage the load lever by pressing the lever down and slightly outward to clear the retention tab. Rotate the load lever to a fully open position.

  • Page 67: Figure 4-4: Insert The Socket Lga775 Cpu

    IMBA-Q454-R10 User Manual Step 5: Correctly position the CPU. Match the Pin 1 mark with the cut edge on the CPU socket. Step 6: Align the CPU pins. Locate pin 1 and the two orientation notches on the CPU. Carefully match the two orientation notches on the CPU with the socket alignment keys.

  • Page 68: Socket Lga775 Cf-520 Cooling Kit Installation

    WARNING: It is strongly recommended that you DO NOT use the original heat sink and cooler provided by Intel on the IMBA-Q454-R10. The cooling kit includes a support bracket that is combined with the heat sink mounted on the CPU to counterweigh and balance the load on both sides of the PCB.

  • Page 69: Figure 4-6: Securing The Heat Sink To The Pcb Board

    Step 6: Connect the fan cable. Connect the cooling kit fan cable to the fan connector on the IMBA-Q454-R10. Carefully route the cable and avoid heat generating chips and fan blades. Step 0:...

  • Page 70: Dimm Installation

    4.3.3 DIMM Installation WARNING: Using incorrectly specified memory modules may cause permanent damage the IMBA-Q454-R10. Please make sure the memory modules comply with the recommended memory specifications. WARNING: 1) Before removing the DDR2 DRAM module, make sure the AC power supply is completely turned off.

  • Page 71: Figure 4-7: Installing A Dimm

    IMBA-Q454-R10 User Manual Figure 4-7: Installing a DIMM Step 1: Open the DIMM socket handles. The DIMM socket has two handles that secure the DIMM into the socket. Before the DIMM can be inserted into the socket, the handles must be opened. See F igure 4-7.

  • Page 72: Jumper Settings

    T able 4-2 Jumper Location: F igure 4-8 If the IMBA-Q454-R10 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper Page 72...

  • Page 73: Figure 4-8: Clear Cmos Jumper

    IMBA-Q454-R10 User Manual cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2. If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault may be corrected by pressing the F1 to enter the CMOS Setup menu.

  • Page 74: Itpm Setup Jumper

    The location of the clear CMOS jumper is shown in F igure 4-8 below. Figure 4-9: iTPM Setup Jumper Locations 4.5 Chassis Installation To install the IMBA-Q454-R10 motherboard into the chassis please refer to the reference material that came with the chassis. Page 74...

  • Page 75: Airflow

    The IMBA-Q454-R10 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 76: Single Rs-232 Cable With Slot Bracket

    IMBA-Q454-R10 User Manual Figure 4-10: Dual RS-232 Cable Installation Step 3: Secure the bracket. The dual RS-232 connector has two D-sub 9 male connectors secured on a bracket. To secure the bracket to the chassis please refer to the reference material that came with the chassisStep 0: 4.5.3 Single RS-232 Cable with Slot Bracket...

  • Page 77: Sata Drive Connection

    0: 4.5.4 SATA Drive Connection The IMBA-Q454-R10 is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 78: Figure 4-12: Sata Drive Cable Connection

    IMBA-Q454-R10 User Manual Figure 4-12: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See F igure 4-13.

  • Page 79: Usb Cable (Dual Port) With Slot Bracket

    IMBA-Q454-R10 User Manual Figure 4-13: SATA Power Drive Connection 4.5.5 USB Cable (Dual Port) with Slot Bracket The IMBA-Q454-R10 is shipped with a dual port USB 2.0 cable. To connect the USB cable connector, please follow the steps below. Step 1: Locate the connectors.

  • Page 80: Usb Cable (Four Port)

    Step 3: Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the IMBA-Q454-R10, connect the cable connectors to the on-board connectors. See F igure 4-14. Figure 4-14: Dual USB Cable Connection Step 4: Attach the bracket to the chassis.

  • Page 81: Figure 4-15: Four Port Usb Cable Connection

    If the USB pins are not properly aligned, the USB device can burn out. Step 2: Align the connectors. Each cable has two connectors. Correctly align pin 1on each cable connector with pin 1 on the IMBA-Q454-R10 USB connectors. Step 3: Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the IMBA-Q454-R10, connect the cable connectors to the on-board connectors.

  • Page 82: External Peripheral Interface Connection

    4.6.1 Keyboard and Mouse The IMBA-Q454-R10 has a dual PS/2 connector on the external peripheral interface panel. The dual PS/2 connector is used to connect to a keyboard and mouse to the system.

  • Page 83: Lan

    Locate the RJ-45 connectors. The locations of the USB connectors are shown in Chapter 4. Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of the RJ-45 connectors on the IMBA-Q454-R10. See F igure 4-17. Page 83...

  • Page 84: Parallel Device Connection

    RJ-45 connector into the on-board RJ-45 connector. Step 0: 4.6.3 Parallel Device Connection The IMBA-Q454-R10 has a single female DB-25 connector on the external peripheral interface panel for parallel devices. Follow the steps below to connect a parallel device to the IMBA-Q454-R10.

  • Page 85: Serial Device

    Step 0: 4.6.4 Serial Device The IMBA-Q454-R10 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the IMBA-Q454-R10.

  • Page 86: Usb

    Step 0: 4.6.5 USB The external USB connectors provide easier and quicker access to external USB devices. Follow the steps below to connect USB devices to the IMBA-Q454-R10. Step 1: Locate the USB connectors. The location of the USB receptacle connectors are shown in Chapter 3.

  • Page 87: Vga Monitor

    Figure 4-20: USB Connector 4.6.6 VGA Monitor The IMBA-Q454-R10 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the IMBA-Q454-R10, please follow the instructions below.

  • Page 88: Audio Connector

    Step 0: 4.6.7 Audio Connector The three audio jacks on the external audio connector enable the IMBA-Q454-R10 to be connected to a stereo sound setup. To install the audio devices, follow the steps below. Step 1: Identify the audio plugs.

  • Page 89: Figure 4-22: Audio Connector

    IMBA-Q454-R10 User Manual Microphone (Pink): Connects to a microphone. Figure 4-22: Audio Connector Step 3: Check audio clarity. Check that the sound is coming through the right speakers by adjusting the balance front to rear and left to right. Step 0:...

  • Page 90: Bios Setup

    IMBA-Q454-R10 User Manual Chapter BIOS Setup Page 90...

  • Page 91: Introduction

    IMBA-Q454-R10 User Manual 5.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 92: Getting Help

    IMBA-Q454-R10 User Manual Function F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help...

  • Page 93: Main

    IMBA-Q454-R10 User Manual 5.2 Main The Main BIOS menu (Error! Reference source not found.) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot...

  • Page 94: Advanced

    IMBA-Q454-R10 User Manual Speed: Lists the processor speed Count: The number of CPUs on the motherboard System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [hh:mm:ss] Use the System Time option to set the system time.

  • Page 95: Cpu Configuration

    IMBA-Q454-R10 User Manual 5.3.10 USB Configuration ..............121 BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced Settings Configure CPU ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below sections may cause system to malfunction > CPU Configuration > IDE Configuration >...

  • Page 96: Bios Menu 3: Cpu Configuration

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Configure Advanced CPU Settings Module Version:3F.11 ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Manufacturer :Intel® Intel® Core™2 CPU 6300 @ 1.86GHz Frequency :1.86GHz FSB Speed :1068MHz Cache L1 : 64KB Select Screen ↑ ↓...

  • Page 97: Ide Configuration

    IMBA-Q454-R10 User Manual 5.3.2 IDE Configuration Use the IDE Configuration menu (Error! Reference source not found.) to change and/or set the configuration of the IDE devices installed in the system. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit...

  • Page 98: Ide Master, Ide Slave

    IMBA-Q454-R10 User Manual AHCI The SATA drive connected to the nth SATA drive port is specified as a normal SATA drive. IDE Master and IDE Slave When entering setup, BIOS automatically detects the presence of IDE devices. BIOS displays the status of the auto detected IDE devices. The following IDE devices are...

  • Page 99: Bios Menu 5: Ide Master And Ide Slave Configuration

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Primary IDE Master Select the type of device ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ connected to the system Device :Not Detected ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Type [Auto] LBA/Large Mode [Auto] Block (Multi-Sector Transfer) [Auto] Select Screen...
  • Page 100 IMBA-Q454-R10 User Manual 32Bit Data Transfer: Enables 32-bit data transfer. Type [Auto] Use the Type BIOS option select the type of device the AMIBIOS attempts to boot from after the Power-On Self-Test (POST) is complete. Not Installed BIOS is prevented from searching for an IDE disk drive on the specified channel.
  • Page 101 IMBA-Q454-R10 User Manual Block (Multi Sector Transfer) [Auto] Use the Block (Multi Sector Transfer) to disable or enable BIOS to auto detect if the device supports multi-sector transfers. Disabled BIOS is prevented from using Multi-Sector Transfer on the specified channel. The data to and from the device occurs one sector at a time.
  • Page 102 IMBA-Q454-R10 User Manual Auto BIOS auto detects the DMA mode. Use this value if the IDE EFAULT disk drive support cannot be determined. Single Word DMA mode 0 selected with a maximum data SWDMA0 transfer rate of 2.1 MB/s SWDMA1 Single Word DMA mode 1 selected with a maximum data transfer rate of 4.2 MB/s...

  • Page 103: Floppy Configuration

    IMBA-Q454-R10 User Manual S.M.A.R.T [Auto] Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and Reporting Technology (SMART) on the drive on the specified channel. S.M.A.R.T predicts impending drive failures. The S.M.A.R.T BIOS option enables or disables this function.

  • Page 104: Super I/O Configuration

    IMBA-Q454-R10 User Manual Floppy A Use the Floppy A/B option to configure the floppy disk drive. Options are listed below: Disabled 360 KB 51/4” 1.2 MB 51/4” 720 KB 31/2” 1.44 MB 31/2’ 2.88 MB 31/2” 5.3.4 Super I/O Configuration Use the Super I/O Configuration menu (Error! Reference source not found.) to set or...
  • Page 105 IMBA-Q454-R10 User Manual Serial Port1 Address [3F8/IRQ4] Use the Serial Port1 Address option to select the Serial Port 1 base address. Disabled No base address is assigned to Serial Port 1 I/O port address is 3F8 and the interrupt address is IRQ4...
  • Page 106 IMBA-Q454-R10 User Manual ASK IR Serial Port 2 mode is ASK IR Parallel Address [378] The Parallel Port Address BIOS option assigns the I/O port address of the parallel port. The following address options are available: No I/O port address is assigned to the parallel port...
  • Page 107 IMBA-Q454-R10 User Manual EPP + ECP The parallel port operates in the extended capabilities port (ECP) mode. The ECP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster...

  • Page 108: Hardware Health Configuration

    IMBA-Q454-R10 User Manual 5.3.5 Hardware Health Configuration The Hardware Health Configuration menu ( B IOS Menu 8) shows the operating temperature, fan speeds and system voltages. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Hardware Health Configuration Fan configuration mode ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...
  • Page 109 IMBA-Q454-R10 User Manual The fan mode setting options are listed below. Full On Mode Fan is on all the time EFAULT Automatic mode Fan is off when the temperature is low enough. Parameters must be set by the user. When the FAN Mode Setting option is in the Automatic Mode, the following parameters can be set.
  • Page 110 IMBA-Q454-R10 User Manual CPU Temp. Limit of Start [020] WARNING: Setting this value too high may cause the fan to start only when the CPU is at a high temperature and therefore cause the system to be damaged. The CPU Temp. Limit of Start option can only be set if the CPU FAN Mode Setting option is set to Automatic Mode.
  • Page 111 IMBA-Q454-R10 User Manual 0.125 PWM 0.25 PWM 0.5 PWM 1 PWM 2 PWM 4 PWM 8 PWM 15 PWM Hardware Health Monitoring The following system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored...

  • Page 112: Ahci Configuration

    IMBA-Q454-R10 User Manual 5.3.6 AHCI Configuration Use the AHCI Configuration Settings menu ( B IOS Menu 9) to report on the auto-detection of devices connected to the onboard SATA drive connectors. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 113: Bios Menu 10: Ahci Port N Configuration Menu

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit AHCI Port0 Select the type of device ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ connected to the system Device :Not Detected ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ SATA Port0 [Auto] S.M.A.R.T. [Enabled] Select Screen ↑ ↓ Select Item...

  • Page 114: Intel Amt Configuration

    IMBA-Q454-R10 User Manual 5.3.7 Intel AMT Configuration Use the Intel AMT menu (Error! Reference source not found.) to enable the system to be managed through the Intel® Active Management Technology (AMT) interface. The interface is implemented through LAN1. BIOS SETUP UTILITY...

  • Page 115: Me Subsystem Configuration

    IMBA-Q454-R10 User Manual 5.3.7.1 ME Subsystem Configuration Use the ME Subsystem Configuration menu (Error! Reference source not found.) to configure the Intel® Management Engine (ME) configuration options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit ME Subsystem Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...
  • Page 116 IMBA-Q454-R10 User Manual End of Post S5 HECI Message [Enabled] Use the End of Post S5 HECI Message option to enable or disable the Intel® AMT the HECI message to wake the system in an S5 sleep state. Disabled HECI bus cannot rouse system from an S5 state...

  • Page 117: Remote Access Configuration

    IMBA-Q454-R10 User Manual 5.3.8 Remote Access Configuration Use the Remote Access Configuration menu (Error! Reference source not found.) to configure remote access parameters. The Remote Access Configuration is an AMIBIOS feature and allows a remote host running a terminal program to display and configure the BIOS settings.
  • Page 118 IMBA-Q454-R10 User Manual Enabled Remote access configuration options shown below appear: -- Serial Port Number -- Serial Port Mode -- Flow Control -- Redirection after BIOS POST -- Terminal Type -- VT-UTF8 Combo Key Support -- Sredir Memory Display Delay These configuration options are discussed below.
  • Page 119 IMBA-Q454-R10 User Manual Redirection After BIOS POST [Always] Use the Redirection After BIOS POST option to specify when console redirection should occur. Disabled The console is not redirected after POST Redirection is active during POST and during Boot Boot Loader...

  • Page 120: Trusted Computing

    IMBA-Q454-R10 User Manual 5.3.9 Trusted Computing Use the Trusted Computing menu ( B IOS Menu 14) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Trusted Computing ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 121: Usb Configuration

    IMBA-Q454-R10 User Manual 5.3.10 USB Configuration Use the USB Configuration menu ( B IOS Menu 15) to read USB configuration information and configure the USB settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit USB Configuration Enables USB host ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 122: Pci/Pnp

    IMBA-Q454-R10 User Manual Disabled Legacy USB support disabled Legacy USB support enabled Enabled EFAULT Auto Legacy USB support disabled if no USB devices are connected USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller Disabled USB 2.0 controller disabled...

  • Page 123: Bios Menu 16: Pci/Pnp Configuration

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced PCI/PnP Settings Available: Specified IRQ ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ is available to be use the PCI/PnP devices WARNING: Setting wrong values in below sections Reserved: Specified IRQ may cause system to malfunction...
  • Page 124 IMBA-Q454-R10 User Manual IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. Available The specified DMA is available to be used by EFAULT...

  • Page 125: Boot

    IMBA-Q454-R10 User Manual 5.5 Boot Use the Boot menu ( B IOS Menu 17) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Settings Configure settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ during system boot. > Boot Settings Configuration >...
  • Page 126 IMBA-Q454-R10 User Manual Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Enabled Some POST procedures are skipped to decrease EFAULT the system boot time Quiet Boot [Disabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.

  • Page 127: Boot Device Priority

    IMBA-Q454-R10 User Manual Allows the Number Lock on the keyboard to be enabled automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit.

  • Page 128: Hard Disk Drives

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Device Priority Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ sequence from the available devices. > 1st Boot Device [1st Boot Device] > 2nd Boot Device [2nd Boot Device] > 3rd Boot Device...

  • Page 129: Cd/Dvd Drives

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Device Priority Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ sequence from the available devices. > 1st Boot Device [1st Boot Device] > 2nd Boot Device [2nd Boot Device] > 3rd Boot Device...

  • Page 130: Removable Drives

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ sequence from the available devices. > 1st Drive [CD/DVD 1] > 2nd Drive [CD/DVD 2] > 3rd Drive [CD/DVD 3] Select Screen ↑...

  • Page 131: Security

    IMBA-Q454-R10 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ sequence from the available devices. > 1st Drive [Removable Drive 1] > 2nd Drive [Removable Drive 2] > 3rd Drive...

  • Page 132: Chipsets

    IMBA-Q454-R10 User Manual Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed. If a supervisor password must be installed, select this field and enter the password. After the password has been added, Install appears next to Change Supervisor Password.

  • Page 133: Northbridge Chipset Configuration

    IMBA-Q454-R10 User Manual 5.7.1 Northbridge Chipset Configuration Use the Northbridge Chipset Configuration menu (Error! Reference source not found.) to configure the Northbridge chipset settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Northbridge Chipset Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Memory Remap Feature...
  • Page 134 IMBA-Q454-R10 User Manual Disabled Memory is not reserved for ISA expansion cards EFAULT Memory is reserved for ISA expansion cards Enabled Initiate Graphic Adapter Use the Initiate Graphic Adapter option to select the graphics controller used as the primary boot device. Select either an integrated graphics controller (IGD) or a combination of PCI graphics controller, a PCI express (PEG) controller or an IGD.

  • Page 135: Southbridge Chipset Configuration

    IMBA-Q454-R10 User Manual 5.7.2 Southbridge Chipset Configuration Use the Southbridge Configuration menu (Error! Reference source not found.) to configure the Southbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Options Southbridge Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Disabled Enabled ASF Support...
  • Page 136 IMBA-Q454-R10 User Manual Enabled The Alert Standard Format (ASF) controller is activated EFAULT and can communicate with a remote management server. I82574L LAN Boot [Disabled] The I82574L LAN Boot option enables remote boot of the system through LAN1. Cannot be booted remotely through this port...
  • Page 137 IMBA-Q454-R10 User Manual Last State The system returns to its previous state. If it was on, it EFAULT turns itself on. If it was off, it remains off. Resume on Keyboard/Mouse [Disabled] Use the Resume on Keyboard/Mouse BIOS option to enable activity on either the keyboard or mouse to rouse the system from a suspend or standby state.

  • Page 138: Exit

    IMBA-Q454-R10 User Manual 5.8 Exit Use the Exit menu (Error! Reference source not found.) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Exit Options Exit system setup after ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...
  • Page 139 IMBA-Q454-R10 User Manual Load Failsafe Defaults Use the Load Failsafe Defaults option to load failsafe default values for each of the parameters on the Setup menus. F8 key can be used for this operation. Page 139...

  • Page 140: Software Drivers

    IMBA-Q454-R10 User Manual Chapter Software Drivers Page 140...

  • Page 141: Available Software Drivers

    IMBA-Q454-R10 User Manual 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. The following drivers can be installed on the system: 6.3 Chipset Driver .................. 143 6.4 Graphics Driver ................

  • Page 142: Figure 6-1: Start Up Screen

    IMBA-Q454-R10 User Manual Step 2: The screen in F igure 6-1 appears. Figure 6-1: Start Up Screen Step 3: Click IMBA-Q454. Step 4: The list of drivers in F igure 6-2 appears.Step 0: Figure 6-2: Drivers Page 142...

  • Page 143: Chipset Driver

    IMBA-Q454-R10 User Manual 6.3 Chipset Driver To install the Intel® chipset driver, please follow the steps below. Step 1: Click "INF" in the drivers list. F igure 6-3. Step 2: Double-click "infinst_autol" in Figure 6-3: Intel® Chipset Driver Directory Step 3: The Welcome screen appears ( F igure 6-4).

  • Page 144: Figure 6-5: Intel® Chipset Driver License Agreement

    IMBA-Q454-R10 User Manual Step 5: The Intel® license agreement screen appears ( F igure 6-5). Figure 6-5: Intel® Chipset Driver License Agreement Step 6: Click Y to accept the agreement and continue. Step 7: The Readme file contents are displayed ( F igure 6-6).

  • Page 145: Graphics Driver

    IMBA-Q454-R10 User Manual Step 8: Click N to begin the installation. Step 9: When the setup is complete, the final screen appears ( F igure 6-7). Figure 6-7: Intel® Chipset Driver Complete Installation Screen Step 10: To exit the installation, click F...

  • Page 146: Figure 6-8: Graphics Driver File

    IMBA-Q454-R10 User Manual Figure 6-8: Graphics Driver File Step 3: Double-click the driver file Step 4: The version information file appears ( F igure 6-9). Figure 6-9: Graphics Driver Readme File Step 5: Click N to continue. Step 6: The welcome screen appears ( F igure 6-10).

  • Page 147: Figure 6-10: Graphics Driver Installation Welcome Screen

    IMBA-Q454-R10 User Manual Figure 6-10: Graphics Driver Installation Welcome Screen Step 7: Click N to continue. Step 8: The license agreement appears ( F igure 6-11). Figure 6-11: GMA Driver License Agreement Step 9: Click Y to continue. Page 147...

  • Page 148: Figure 6-12: Gma Driver Installing Notice

    IMBA-Q454-R10 User Manual Step 10: The Readme file appears ( F igure 6-12). Figure 6-12: GMA Driver Installing Notice Step 11: Click N to continue. Step 12: The driver installation progress is shown ( F igure 6-13). Figure 6-13: GMA Driver Installation Complete...

  • Page 149: Lan Driver

    IMBA-Q454-R10 User Manual Step 13: Click N to continue to the final screen. Figure 6-14: GMA Driver Installing Notice Step 14: For newly installed drivers to take effect, the computer must be restarted. Select "Yes" to restart the computer now (close any other programs first), or "No" to restart it later.

  • Page 150: Figure 6-15: Lan Driver File

    IMBA-Q454-R10 User Manual Figure 6-15: LAN Driver File Step 3: Double click PRO2KXP icon. Step 4: The welcome screen appears ( F igure 6-16). Figure 6-16: LAN Driver Welcome Screen Step 5: Click N to continue. Step 6: The license agreement appears ( F igure 6-17).

  • Page 151: Figure 6-17: Lan Driver License Agreement

    IMBA-Q454-R10 User Manual Figure 6-17: LAN Driver License Agreement Step 7: Accept the conditions of the license agreement and click N to continue. Step 8: The Setup Options screen appears ( F igure 6-18). Figure 6-18: LAN Driver Setup Options...

  • Page 152: Figure 6-19: Lan Driver Installation Ready Window

    IMBA-Q454-R10 User Manual Step 10: The drivers are ready to install. Click I to begin the installation process NSTALL F igure 6-19). Figure 6-19: LAN Driver Installation Ready Window Step 11: Click I to begin the driver installation. NSTALL Step 12: The window shows the installation is complete ( F igure 6-20).

  • Page 153: Audio Driver

    IMBA-Q454-R10 User Manual Figure 6-20: LAN Driver Installation Progress Step 13: Click F to exit the setup program. S t e p 0 : INISH 6.6 Audio Driver To install the Realtek High Definition (HD) Audio driver, please follow the steps below.

  • Page 154: Driver Installation

    IMBA-Q454-R10 User Manual 6.6.2 Driver Installation To install the audio driver please follow the steps below. Step 1: Select "AUDIO" from the main menu. F igure 6-21). Step 2: Browse to the audio setup file directory ( Figure 6-21: Audio Setup File...

  • Page 155: Intel ® Matrix Storage Manager Driver

    IMBA-Q454-R10 User Manual Figure 6-23: Installation Wizard Finished Step 6: For the audio drivers to take effect, the computer must be restarted. Select "Yes" to restart the computer immediately after exiting the wizard, or "No" to restart it later. Click F to exit the InstallShield Wizard.

  • Page 156: Figure 6-24: Sata Raid Setup Program Icon

    IMBA-Q454-R10 User Manual Figure 6-24: SATA RAID Setup Program Icon Step 4: F igure 6-25 shows the InstallShield Wizard preparing to guide the user through the rest of the process. Figure 6-25: InstallShield Wizard Setup Screen Page 156...

  • Page 157: Figure 6-26: Matrix Storage Manager Setup Screen

    IMBA-Q454-R10 User Manual Step 5: F igure 6-26 shows the Matrix Storage Manager software configuring the installation process. Figure 6-26: Matrix Storage Manager Setup Screen Step 6: F igure 6-27 shows the Matrix Storage Manager welcome screen. Figure 6-27: Matrix Storage Manager Welcome Screen...

  • Page 158: Figure 6-28: Matrix Storage Manager Warning Screen

    IMBA-Q454-R10 User Manual Step 7: Click N and a warning appears ( F igure 6-28). Read the warning carefully and decide whether or not to continue the installation process. Figure 6-28: Matrix Storage Manager Warning Screen Step 8: Click N and a license agreement appears ( F igure 6-29).

  • Page 159: Figure 6-30: Matrix Storage Manager Readme File

    IMBA-Q454-R10 User Manual Step 9: Read the license agreement. To accept the terms and conditions stipulated in the license agreement shown, click Y and the Readme information file shown F igure 6-30 appears. Figure 6-30: Matrix Storage Manager Readme File...

  • Page 160: Intel® Amt (Heci) Driver

    IMBA-Q454-R10 User Manual Figure 6-31: Matrix Storage Manager Setup Complete Step 12: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH exit the wizard.

  • Page 161: Figure 6-32: Amt Heci Driver Directory

    IMBA-Q454-R10 User Manual Figure 6-32: AMT HECI Driver Directory Step 3: Double-click the setup file ( F igure 6-33). Step 4: The welcome screen appears ( F igure 6-33). Figure 6-33: AMT HECI Welcome Screen Step 5: Click N to continue.

  • Page 162: Figure 6-34: Amt Heci License Agreement

    IMBA-Q454-R10 User Manual Figure 6-34: AMT HECI License Agreement Step 7: Click Y to agree to the terms of the agreement and continue installation. Step 8: The IAMT Readme file appears ( F igure 6-35). Figure 6-35: AMT HECI Driver Readme File...

  • Page 163: Intel® Amt (Sol) Driver

    IMBA-Q454-R10 User Manual Step 10: Driver setup is complete. Figure 6-36: AMT HECI Driver Installation Complete Step 11: Click F to exit the InstallShield wizard. S t e p 0 : INISH 6.9 Intel® AMT (SOL) Driver The Intel® AMT Serial Over LAN (SOL) drivers allow remote management of the system through a serial port device redirected through the LAN interface.

  • Page 164: Figure 6-37: Iamt Driver Directory

    IMBA-Q454-R10 User Manual Figure 6-37: IAMT Driver Directory Step 3: The welcome screen appears ( F igure 6-38). Figure 6-38: IAMT Welcome Screen Step 4: Click N to continue. Step 5: The License Agreement appears ( F igure 6-39). Page 164...

  • Page 165: Figure 6-39: Iamt License Agreement

    IMBA-Q454-R10 User Manual Figure 6-39: IAMT License Agreement Step 6: Click Y to agree to the terms of the agreement and continue the installation. Step 7: The IAMT Readme file appears ( F igure 6-40). Figure 6-40: IAMT Readme File...

  • Page 166: Figure 6-41: Completed Installation

    IMBA-Q454-R10 User Manual Step 9: The final installation screen appears ( F igure 6-41). Figure 6-41: Completed Installation Step 10: Click F to complete the IAMT installation. S t e p 0 : INISH Page 166...

  • Page 167: Intel® Amt Setup

    IMBA-Q454-R10 User Manual Chapter Intel® AMT Setup Page 167...

  • Page 168: Intel ® Amt Setup Procedure

    9 4 6 H Step 5: The following dialog window is displayed after the OS is loaded to show the Intel® AMT status on the IMBA-Q454-R10 is enabled.S t e p 0 : Figure 7-1: Intel® Active Management Technology Status Dialog ®...

  • Page 169: Figure 7-2: Intel® Current Me Password

    IMBA-Q454-R10 User Manual Step 1: A screen prompts the user to press <Ctrl+P> after a single beep during boot-up process. To get into the Intel® MEBx settings, press <Ctrl+P>. Step 2: Enter the Intel® current ME password as required ( F igure 7-2).

  • Page 170: Figure 7-3: Change Intel® Me Password

    IMBA-Q454-R10 User Manual Figure 7-3: Change Intel® ME Password Step 4: Verify the new password by entering again ( F igure 7-4). 1 0 5 1 H 9 4 9 H Figure 7-4: Verify New Password Step 5: Select Intel® AMT Configuration and press Enter ( F igure 7-5).

  • Page 171: Figure 7-6: Provision Model

    IMBA-Q454-R10 User Manual Figure 7-6: Provision Model Step 7: When the screen in F igure 7-7 prompts, enter N and press Enter. 1 0 5 4 H 9 5 2 H Figure 7-7: Intel® AMT 5.0 Mode Step 8: A message prompts to confirm to Change to Small Business ( F igure 7-8).

  • Page 172: Figure 7-8: Enterprise

    IMBA-Q454-R10 User Manual Figure 7-8: Enterprise Step 9: Select TCP/IP (in Intel AMT Configuration) and press Enter. A message prompts for disabling network interface. Enter N to enable network interface. Figure 7-9: Enable Network Interface Step 10: Enable or disable DHCP. DHCP is enabled by default. If DHCP is disabled, enter...

  • Page 173: Using The Intel Amt Web Interface

    IMBA-Q454-R10 User Manual Static TCP/IP address (the static TCP/IP address and Intel® AMI Host Name must be different from those configured in the operating system) Subnet mask Default Gateway address (optional) Preferred Domain Naming Services (DNS) serer address (optional) Alternate DNS server address (optional)

  • Page 174: Figure 7-11: Intel® Amt Web Address

    IMBA-Q454-R10 User Manual To access an Intel® AMT client system from a remote console, follow the steps below. Step 1: Obtain the IP address of the client system. Step 2: On the remote management console, open a web browser. Step 3: If DHCP is enabled in the TCP/IP menu of the Intel®...

  • Page 175: Figure 7-12: Intel® Amt Web Login Dialog

    IMBA-Q454-R10 User Manual Figure 7-12: Intel® AMT Web Login Dialog Step 6: Enter admin as the user name ( F igure 7-12). 1 0 6 0 H 9 5 8 H Step 7: Enter the password changed in the Intel® MEBx configuration. The default...

  • Page 176: Figure 7-13: Intel® Amt Web Interface

    IMBA-Q454-R10 User Manual Figure 7-13: Intel® AMT Web Interface NOTE: To enhance the platform manageability of theIMBA-Q454-R10, work with the Independent Software Vendors (ISV) to implement the Intel® AMT management utility on the system. Page 176...

  • Page 177: Ismm Setup

    IMBA-Q454-R10 User Manual Chapter iSMM Setup Page 177...

  • Page 178: Ismm Introduction

    8.2 iSMM Installation Follow the steps below to install the iSMM application. Step 1: Insert the utility CD that came with the IMBA-Q454-R10 into a CD drive connected to the system. Step 2: Click the setup.exe in the IEI iSMM folder.

  • Page 179: Figure 8-2: Ismm Installation Customer Information

    IMBA-Q454-R10 User Manual Step 4: Click N to continue the installation process. Step 5: The customer information in F igure 8-2 appears. 9 6 1 H Figure 8-2: iSMM Installation Customer Information Step 6: Fill out the information and click N...

  • Page 180: Voltage Page

    IMBA-Q454-R10 User Manual Step 8: Click N to start the software installation. Step 9: After the driver installation process is complete, a confirmation screen appears. Step 10: Click F to complete the software installation. Step 0: INISH 8.3 Voltage Page...

  • Page 181: Refresh Time Setting

    IMBA-Q454-R10 User Manual 8.3.1 Refresh Time Setting The iSMM refreshes the voltage values according to the refresh time period set by the user. Follow the steps below to set the refresh time: Step 1: Click on the Voltage Page tab.

  • Page 182: Fan Page

    IMBA-Q454-R10 User Manual Step 2: Check the high or low limit value to have the system use the beep warning when the specified system voltage is greater or smaller than the high limit or low limit F igure 8-6). (Make sure to enable beep/audio alarm on the Load/Save Page.

  • Page 183: Refresh Time Setting

    IMBA-Q454-R10 User Manual 8.4.1 Refresh Time Setting The iSMM refreshes the fan speed values according to the refresh time period set by the user. Follow the steps below to set the refresh time: Step 1: Click on the Fan Page tab.

  • Page 184: Smart Fan Setting

    IMBA-Q454-R10 User Manual Step 2: Check the high or low limit value to have the system use the beep warning when the specified fan speed is greater or smaller than the high limit or low limit F igure 8-9). (Make sure to enable beep/audio alarm on the Load/Save Page.

  • Page 185: Automatic Mode

    IMBA-Q454-R10 User Manual Figure 8-11: Smart Fan Setting – PWM Mode 8.4.3.3 Automatic Mode In the Automatic Mode, the user can set the temperature that decides the fan activity. The following value can be set ( F igure 8-12): 9 7 8 H Fan Start (°C): the fan starts when the temperature reaches the set value...

  • Page 186: Temperature Page

    IMBA-Q454-R10 User Manual Figure 8-12: Smart Fan Setting – Automatic Mode 8.5 Temperature Page The IEI iSMM application monitors the current CPU temperature and system temperature and shows the temperature on the Temperature Page ( F igure 8-13). The following 9 7 9 H sections describe the Temperature Page in details.

  • Page 187: Refresh Time Setting

    IMBA-Q454-R10 User Manual Figure 8-13: Temperature Page 8.5.1 Refresh Time Setting The iSMM refreshes the CPU and system temperature according to the refresh time period set by the user. Follow the steps below to set the refresh time: Step 1: Click on the Temperature Page tab.

  • Page 188: High Limit Value And Low Limit Value Setting

    IMBA-Q454-R10 User Manual 8.5.2 High Limit Value and Low Limit Value Setting The high limit value and low limit value of each temperature can be set by the user. When the temperature is greater than the high limit value or less than the low limit value, the temperature value shows in red.

  • Page 189: Cash Drawer Page

    IMBA-Q454-R10 User Manual 8.6 Cash Drawer Page The Cashdrawer Page of the IEI iSMM application allows users to view and control the cash drawers connected to the IMBA-Q454-R10. F igure 8-17 shows an example of the 9 8 6 H status of the cash drawers: No.

  • Page 190: Watchdog Timer Page

    IMBA-Q454-R10 User Manual 8.7 Watchdog Timer Page The IEI iSMM application allows users to set watchdog timer on the WDT Page ( F igure 9 8 7 H 8-17). Figure 8-17: WDT Page Set Timeout Set the watchdog timer value. The value is a period of time that the system will shut down if the timer is not reset in that period of time.

  • Page 191: Dio Page

    IMBA-Q454-R10 User Manual 8.8 DIO Page The IEI iSMM application monitors the current voltage of the digital input and digital output and shows the information on the DIO Page ( F igure 8-18). The digital output information 9 8 8 H can be set and written to an internal register to control the state driven on the output pin.

  • Page 192: Load/Save Page

    IMBA-Q454-R10 User Manual Step 3: Click Write to write to an internal register to control the state after finish setting the output pin. Step 0: 8.9 Load/Save Page The IEI iSMM application allows the user to save the settings of all the high limit/low limit values and smart fan setting as an *.ini file.

  • Page 193: Abios Options

    IMBA-Q454-R10 User Manual Appendix BIOS Options Page 193...
  • Page 194 IMBA-Q454-R10 User Manual Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview ......................... 3 6 2 H 9 9 0 H 　 System Time [hh:mm:ss] ....................3 6 3 H 9 9 1 H 　...
  • Page 195 IMBA-Q454-R10 User Manual 　 HECI Message [Enabled]....................1 15 3 9 5 H 1 0 2 3 H 　 End of Post S5 HECI Message [Enabled] ............... 1 16 3 9 6 H 1 0 2 4 H 　 ME-HECI [Enabled] ......................
  • Page 196 IMBA-Q454-R10 User Manual 　 GbE LAN Support (I82567LM) [Disabled] ............... 1 36 4 3 0 H 1 0 5 8 H 　 Suspend Mode [S1 (POS)]....................1 36 4 3 1 H 1 0 5 9 H 　 Restore on AC Power Loss [Last State] .................

  • Page 197: B Terminology

    IMBA-Q454-R10 User Manual Appendix Terminology Page 197...
  • Page 198 IMBA-Q454-R10 User Manual AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 199 IMBA-Q454-R10 User Manual Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module.
  • Page 200 IMBA-Q454-R10 User Manual Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 201: C Digital I/O Interface

    IMBA-Q454-R10 User Manual Appendix Digital I/O Interface Page 201...

  • Page 202: Introduction

    IMBA-Q454-R10 User Manual C.1 Introduction The DIO connector on the IMBA-Q454-R10 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 203: Assembly Language Samples

    IMBA-Q454-R10 User Manual C.3 Assembly Language Samples C.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. Sets the digital port as input...

  • Page 204: D Watchdog Timer

    IMBA-Q454-R10 User Manual Appendix Watchdog Timer Page 204...
  • Page 205 IMBA-Q454-R10 User Manual NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 206 IMBA-Q454-R10 User Manual NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 207: E Compatibility

    IMBA-Q454-R10 User Manual Appendix Compatibility Page 207...

  • Page 208: Compatible Operating Systems

    The compatible items described here have been tested by the IEI R&D team and found to be compatible with the IMBA-Q454-R10 E.1 Compatible Operating Systems The following operating systems have been successfully run on the IMBA-Q454-R10. Microsoft Windows Vista Microsoft Windows XP (32-bit) Microsoft Windows 2000 Fedora 9.0...

  • Page 209: Compatible Memory Modules

    The memory modules listed below have been tested on the IMBA-Q454-R10 other memory modules that comply with the specifications may also work on the IMBA-Q454-R10 but have not been tested. The following memory modules have been successfully tested on the IMBA-Q454-R10. Manufacturer Model Capacity...

  • Page 210: F Hazardous Materials Disclosure

    IMBA-Q454-R10 User Manual Appendix Hazardous Materials Disclosure Page 210...

  • Page 211: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    IMBA-Q454-R10 User Manual F.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
