Quick Installation Guide
Package Contents
IMBA-8650 package includes the following items:
1 x IMBA-8650 Single Board Computer
2 x IDE Cable
2 x RS-232 Cable
1 x RS-232 Cable
1 x RS-422/485 Cable
2 x SATA Cable
1 x SATA Power Cable
1 x I/O Shielding
1 x Mini Jumper Pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
IMBA-8650
Version 2.2
Mar 18, 2009
©2006 Copyright by IEI Technology corp.
All rights reserved.
$ % & $
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology IMBA-8650
Summary of Contents for IEI Technology IMBA-8650
-
Page 1: Quick Installation Guide
$ % & $ IMBA-8650 Quick Installation Guide Version 2.2 Mar 18, 2009 Package Contents IMBA-8650 package includes the following items: 1 x IMBA-8650 Single Board Computer 2 x IDE Cable 2 x RS-232 Cable 1 x RS-232 Cable 1 x RS-422/485 Cable... -
Page 2: Specifications
Specifications ATX Motherboard with Intel® Pentium® D/4, Celeron® D Socket 478 FSB 400/533/800MHz System Chipset: Intel® 865G + ICH5 BIOS : AWARD BIOS Label System Memory: 4 x 184-pin Dual Channel DDR 266/333/400MHz up to 4GB Ethernet: Intel 82541PI GbE (IMBA-8650GN) Realtek 8110SC GbE (IMBA-8650GR) I/O Interface: 8 x USB 2.0... -
Page 3: Ordering Information
Humidity: Operation: 5% ~ 95% non-condensing Dimension: 305 mm x 244 mm Weight: GW: 1200g; NW: 600g Ordering Information IMBA-8650GR-R22 ATX Motherboard with Intel Pentium D/4 Socket 478 FSB 800Mhz, AGP 8X, Realtek GbE, SATA and Audio IMBA-8650GN-R22 ATX Motherboard with Intel Pentium D/4 Socket 478 FSB 800Mhz, AGP 8X, Intel GbE, SATA and Audio 32200-000017-RS: FDD Cable CB-USB02-RS: Dual USB Cable... - Page 4 COM2,3,4,5,6 : Serial Port 2x5 Pin Header Connector (P=2.54mm) Description Description GROUND USB2,3 : Dual Ports USB Connector (P=2.54mm) Description Description USB POWER GROUND DATA0- DATA1+ DATA0+ DATA1- GROUND USB POWER CN3 : Audio AUX In Connector CN4 : Audio CD In Connector (P=2.54mm) (P=2.54mm) DESCRIPTION...
- Page 5 CN6 : 5.1 Channel Audio Connector (P=2.54mm) DESCRIPTION DESCRIPTION SUR OUT(L) CEN OUT GROUND GROUND SUR OUT(R) LFE OUT GROUND CN7: Front Panel Audio Connector (P=2.54mm) DESCRIPTION DESCRIPTION MIC IN GROUND MIC BIAS LINE OUT(R) LINE OUT (R) Return LINE OUT(L) LINE OUT (L) Return PIN 5-6 default...
- Page 6 FAN1, FAN2 : CPU Fan Connector IR1: IrDA Connector (P=2.54mm) (P=2.54mm) Description Description GROUND +12V (Control) IR-RX Rotation Signal GROUND IR-TX CIRRX DIO1: Digital Input / Output Connector (P=2.54mm) Description Description GROUND Input0 Output0 Input1 Output1 Input2 Output2 Input3 Output3 ATX1: ATX Power Connector DESCRIPTION DESCRIPTION...
-
Page 7: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
