7.3 Battery Charging Profile Chart

Battery Type
Float Charge @ 25°C:
Bulk/Absorption Charge @ 25°C:
Set to 30 minutes every morning.
Applied for 2 hours if the battery
voltage drops below 12.3 volts.
Equalization Charge @ 25°C:
Applied for 2 hours every 28 days
and if the battery voltage drops
below 12.1 volts.
Absorption Charge voltage for
LiFePO :
4
Set to 30 minutes every morning
Float Charge voltage for LiFePO
If a charging cycle is unable to complete in a single day, it will continue the following day. The
terms SEALED/GEL, AGM, FLOODED and LFP are generic battery designations. Choose the
charging profile that works best with your battery manufacturer's recommendations.
To confirm the battery profile,
press and hold the A Button
for 3 seconds.
Non-volatile memory: Any
settings made on the GP-
PWM-10 will be saved even
when the power has been
disconnected from the
controller.
Refer to the Battery Charge
Profile Chart below for details
on each profile.
SEALED
/GEL
13.7V (+/- 0.1V)
14.1V
(+/- 0.1V)
N/A
:
4
GP-PWM-10
AGM FLOODED
14.4V
14.4V
(+/-
(+/- 0.1V)
0.1V)
14.9V
N/A
(+/-0.1V)
N/A
N/A
