Order form
This section makes it easier for you to specify and
order a VLT 2800.
Choice of frequency converter
The frequency converter must be chosen on the basis
of the present motor current at maximum loading of
the unit. The frequency converter's rated output cur-
rent I must be equal to or greater than the required
INV.
motor current.
Mains voltage
VLT 2800 is available for two mains voltage ranges:
200-240 V and 380-480 V.
Select whether the frequency converter is connected
to a mains voltage of:
1 x 220 - 240 Volt mains voltage
Typical shaft output
P
INV.
Type [kW]
2803 0.37
2805 0.55
2807 0.75
2811 1.1
2815 1.5
2822 2.2
2840 3.7
3 x 200 - 240 Volt mains voltage
Typical shaft output
P
INV.
Type [kW]
2803 0.37
2805 0.55
2807 0.75
2811 1.1
2815 1.5
2822 2.2
2840 3.7
MG.27.E2.02 - VLT is a registered Danfoss trademark
Max. constant output current I
[HP] [A]
0.5 2.2
0.75 3.2
1.0 4.2
1.5 6.0
2.0 6.8
3.0 9.6
5.0 16
Max. constant output current I
[HP] [A]
0.5 2.2
0.75 3.2
1.0 4.2
1.5 6.0
2.0 6.8
3.0 9.6
5.0 16.0
- 1 x 220 - 240 V single-phase AC voltage
- 3 x 200 - 240 V three-phase AC voltage
3 x 380 - 480 V three-phase AC voltage
-
Max. constant output power at
INV.
Max. constant output power at
INV.
230 V S
INV.
[kVA]
0.9
1.3
1.7
2.4
2.7
3.8
6.4
230 V S
INV.
[kVA]
0.9
1.3
1.7
2.4
2.7
3.8
6.4
