020 Hand operation
(HAND OPERATION)
Value:
Not active (DISABLE)
Active (ENABLE)
Function:
In this parameter you can select whether it should be
possible or not to switch between Auto- and Hand
mode. In Auto mode the frequency converter is con-
trolled by external signals whereas the frequency con-
verter in Hand mode is controlled via a local reference
directly from the control unit.
Description of choice:
If Not active [0] is selected in this parameter, the Hand
mode function will be inactive. If Active [1] is selected
you can switch between Auto- and Hand mode. For
further information, see the Control Unit section.
024 Userdefined Quick Menu
(user quickmenu)
Value:
Not active (Disable)
Active (Enable)
Function:
In this parameter you can select the standard setup of
the Quick menu key on the control panel and the LCP
2 control panel.
Using this function, in parameter 025 Quick Menu set-
up the user can select up to 20 parameters for the
Quick Menu key.
Description of choice:
If not active [0] is selected, the standard setup of the
Quick Menu key is active.
If Active [1] is selected, the user-defined Quick Menu
is active.
025 Quick Menu setup
(quick menu setup)
Value:
[Index 1 - 20] Value: 0 - 999
= factory setting, () = display text, [] = value for use in communication via serial communication port
66
Function:
In this parameter you define which parameters are re-
quired in the Quick Menu when parameter 024 User-
defined Quick Menu is set to Active [1].
Up to 20 parameters can be selected for the user-de-
[0] fined Quick Menu.
[1]
NB!
Please note that this parameter can only
be set using an LCP 2 control panel.
See Order form.
Description of choice:
The Quick Menu is set up as follows:
1. Select parameter 025 Quick Menu setup and
press [CHANGE DATA].
2. Index 1 indicates the first parameter in Quick
Menu. You can scroll between the index
numbers using the [+ / -] keys. Select Index
1.
3. Using [< >] you can scroll between the three
figures. Press the [<] key once ad the last
number in the parameter number can be se-
lected using the [+ / -] keys. Set Index 1 to
100 for parameter 100 Configuration.
4. Press [OK] when Index 1 has been set to 100.
[0]
5. Repeat steps 2 - 4 until all parameters re-
quired have been set to the Quick Menu key.
[1]
6. Press [OK] to complete the Quick Menu set-
up.
If parameter 100 Configuration is selected at Index 1,
Quick Menu will start with this parameter every time
Quick Menu is activated.
Please note that parameter 024 User-defined Quick
Menu and parameter 025 Quick Menu setup are reset
to the factory setting during initialisation.
000
