PNU # Parameterdescription
302 Digital input, term. 18
303 Digital input, term. 19
304 Digital input, term. 27
305 Digital input, term. 29
307 Digital input, term. 33
308 Term. 53, analogue input voltage
309 Term. 53, min scaling
310 Term. 53, max scaling
314 Term. 60, analogue input current
315 Term. 60, min scaling
316 Term. 60, max scaling
317 Time out
318 Function after timeout
319 Term. 42, analogue output
323 Relay output
327 Pulse ref./FB
341 Term. 46 digital output
342 Term. 46 Max. pulse output
343 Precise stop function
344 Counter value
349 Speed comp delay
4-Setup:
'Yes' means that the parameter can be programmed
individually in each of the four Setups, i.e. one single
parameter can have four different data values. 'No'
means that the data value will be the same in all Set-
ups.
Conversion index:
This number refers to a conversion figure to be used
when writing or reading via serial communication with
a frequency converter.
See Data character in Serial communication in the
Design Guide.
MG.27.E2.02 - VLT is a registered Danfoss trademark
Factory setting
Start
Reversing
Reset and coast
inverse
Jog
No function
Reference
0.0 V
10.0 V
No function
0.0 mA
20.0 mA
10 sec.
No function
0-I = 0-20 mA
MAX
Control ready
5000 Hz
Control ready
5000 Hz
Normal ramp stop
100000 pulses
10 ms
Data type:
Data type shows the type and length of the telegram.
Data type
3
4
5
6
7
9
4-setup Conv.
index
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes -1
Yes -1
Yes 0
Yes -4
Yes -4
Yes -1
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes -3
Description
Integer 16
Integer 32
Unsigned 8
Unsigned 16
Unsigned 32
Text string
Data
type
5
5
5
5
5
5
6
6
5
6
6
5
5
5
5
7
5
6
5
7
6
