Motor voltage [V]
(Motor voltage [V])
DC link voltage [V]
(DC link voltage [V])
Thermal load motor [%]
(Motor thermal [%])
Thermal load [%]
(FC. thermal[%])
Running hours [Hours]
(RUNNING HOURS])
Digital input [Bin]
(Digital input[bin])
Analog input 53 [V]
(analog input 53 [V])
Analog input 60 [mA]
(analog input 60 [mA])
Pulse reference [Hz]
(Pulse ref. [Hz])
External reference [%]
(external ref. [%])
Status word [Hex] (Status word [hex])
Heatsink temperature [°C]
(Heatsink temp [°C])
Alarm word [Hex] (Alarm word [hex])
Control word [Hex] (Control word [Hex])
Warning word [Hex]
(warning word [Hex])
Extended status word [Hex]
(Ext. status [hex])
Communication option card warning
(COMM OPT WARN [HEX])
Pulse count
(PULSE COUNTER)
Power [W]
(POWER [W])
Function:
In this parameter you can select the data value that
you wish to display in the LCP 2 control unit display
line 2 when the frequency converter is switched on.
The display will also be included in the scrollbar in dis-
play mode. In parameters 010-012 Display readout you
can select a further three data values, which are dis-
played in display line 1.
Description of choice:
No readout can only be selected in parameters
010-012 Small display readout.
= factory setting, () = display text, [] = value for use in communication via serial communication port
62
Resulting reference [%] gives, as a percentage, the re-
sulting reference in the range from Minimum refer-
[11]
ence, Ref to Maximum reference, Ref
MIN
[12]
Reference [unit] gives the resulting reference with unit
Hz in Open loop. In Closed loop the reference unit is
selected in parameter 416 Process units.
[13]
Feedback [unit] gives the resulting signal value using
[14]
the unit/scaling selected in parameter 414 Minimum
feedback, FB
LOW
[15]
416 Process units.
Frequency [Hz] gives the output frequency of the fre-
[16]
quency converter.
Output frequency x scaling [-] equals the present output
[17]
frequency f multiplied by the factor set in parameter
M
008 Display scaling of output frequency .
[19]
Motor current [A] gives the phase current of the motor
measured as an effective value.
[20]
Torque [%] denotes the motor's present load in relation
to the motor's rated torque.
[21]
[22]
Power [kW] gives the present power that the motor is
absorbing in kW.
[25]
Power [HP] gives the present power that the motor is
[26]
absorbing in HP.
[27]
Motor voltage[V] gives the voltage supplied to the mo-
tor.
[28]
DC link voltage [V] gives the intermediate circuit voltage
of the frequency converter.
[29]
Thermal load motor [%] gives the calculated/estimated
load on the motor. 100 % is the cut-out limit.
[30]
Thermal load [%] gives the calculated/estimated ther-
mal load on the frequency converter. 100 % is the cut-
[31]
out limit.
[32]
Running hours [Hours] gives the number of hours that
the motor has tun since the last reset in parameter 619
Reset of running hours counter.
Digital input [Binary code] gives the signal status from
the 5 digital inputs (18, 19, 27, 29 and 33). Terminal
18 corresponds to the bit on the extreme left. `0' = no
signal, `1' = signal connected.
Analog input 53 [V] gives the voltage value of terminal
53.
Analog input 60 [mA] gives the present value of termi-
nal 60.
Pulse reference [Hz] gives the reference in Hz connec-
ted to terminal 33.
