3. Mounting the wall frame
The fan is mounted on the surface on walls or in ceilings. Suitable
for Ø100 mm duct, but Ø125 mm can also be used.
a) The cable bushing is situated in the top part of the wall frame.
Electrical connection can either be performed from the rear
(concealed) or from the top (external), see also fig. 2b
Make a hole in the gasket with a pricker or similar sharp tool.
b) Position the wall frame so that the cable bushing
is uppermost +/-45°.
c) Screw the wall frame to the substrate with the screws provided
(3 in total).
Use the Cover Plate accessory, art. no. 115463, if there is not
enough space for screw fixing.
5
3a
3b -45°
3c
3 stk.
+45°
