Levelflex M FMP45 4 to 20 mA HART
Material
Tolerance of probe length
Weight
Endress+Hauser
10.1.6 Mechanical construction
See TI00386F/00/EN, chapter "Material (not in contact with process)" and "Material (in contact
with process)".
over (m / ft)
up to (m / ft) 1 (3.2)
admissible tolerance - 5
(mm / inch) (- 0.2)
Levelflex M
Rod probe
Weight with F12 approx. 8.5 kg
or T12 housing
approx. 1.6 kg/m
Probe length
Flange weight
Weight with F23 approx. 12 kg
housing
approx. 1.6 kg/m
Probe length
Flange weight
Levelflex M
Rod probe
Weight with F12 approx. 9.5 kg
or T12 housing
approx. 1.6 kg/m
Probe length
Flange weight
Weight with F23 approx. 13 kg
housing
approx. 1.6 kg/m
Probe length
Flange weight
Rod probes
1 (3.2) 3 (9.8) 6 (20 )
3 (9.8 ) 6 (20)
- 10 - 20 - 30
- 0.4) (- 0.8) (- 1.2)
XT version (max. 280 °C)
Rope probe
approx. 8.5 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
approx. 12 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
HT version (max. 400 °C)
Rope probe
approx. 9.5 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
approx. 13 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
Rope probes
1 (3.2) 3 (9.8)
1 (3.2) 3 (9.8 ) 6 (20)
- 10 - 20 - 30
(- 0.4) (- 0.8) (- 1.2)
Coax probe
approx. 8.5 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
approx. 12 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
Coax probe
approx. 9.5 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
approx. 13 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
Technical data
6 (20 )
- 40
(- 1.6)
+
+
+
+
+
+
+
+
