cover plate
Instructions for Use
suitable for Viega Eco Plus universal shower WC element, model
8161.20
Model
8040.18
en_INT
Year built:
from 08/2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8040.18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viega 8040.18

Summary of Contents for Viega 8040.18

  • Page 1 Instructions for Use suitable for Viega Eco Plus universal shower WC element, model 8161.20 Model Year built: 8040.18 from 08/2015 en_INT...
  • Page 2 cover plate 2 from 15...

  • Page 3: Table Of Contents

    Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Standards and regulations Intended use 2.2.1 Areas of use Product description 2.3.1 Overview Handling Assembly information 3.1.1 Installation dimensions 3.1.2 Required tools Assembly...

  • Page 4: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.

  • Page 5: About This Translated Version

    About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.

  • Page 6: Product Information

    VDE 0100 Intended use 2.2.1 Areas of use This cover plate is only suitable for the Viega Eco Plus universal shower WC element (model 8161.20). The cover plate can only be used in combination with the following shower WC models: Geberit AquaClean 8000 WC complete system (article number 146.182.xx.x)

  • Page 7: Product Description

    Product information Product description 2.3.1 Overview Fig. 1: Components cover plate model 8040.18 cover frame seal cover plate closing cap flexible hose ½ inch ball valve ½ inch mounting bracket for the earthed wall socket cover plate 7 from 15...

  • Page 8: Handling

    Handling 3 Handling Assembly information 3.1.1 Installation dimensions Fig. 2: Dimensions cover plate model 8040.18 3.1.2 Required tools The following tools are required for mounting: fork or ring spanner: 17 mm / 19 mm flat-blade screwdriver Spirit level Knife (cutter)

  • Page 9: Assembly

    Preparing mounting The locating surface for the cover plate must be mounted flush with the finished wall surface. Close water supply pipe to the Viega Eco Plus Universal shower WC element. Remove ½ inch plug. Seal ½ inch flexible hose and then screw into the T-piece.
  • Page 10 WC and secure with a nut. DANGER! Risk of electrocution – Disconnect the electrical connection to the Viega Eco Plus Universal shower WC from the mains. – Installation only by companies specialising in electrical work in compliance with the valid national regulations, see Ä...
  • Page 11 Handling Loosen the four nuts on the element (size 17). Loosen the four front nuts on the sides of the locating surface. Align all four points flush with the finished wall surface by unscrewing and screwing the threaded screws. Check the alignment with spirit level. Tighten the rear nuts at all four points (size 17), in the process, secure the threaded screws with a slotted screwdriver.
  • Page 12 Handling Unscrew the threaded rods for the fixing of the WC element to the required size and counter with nuts (size 19). cover plate 12 from 15...

  • Page 13: Mounting The Cover Plate

    Handling 3.2.2 Mounting the cover plate Insert the seal on the front into the cover frame. Apply the silicone seal to the rear of the cover frame. Align the cover frame and attach it to the element by the supplied Phillips-head screws.
  • Page 14 Handling Place the cover plate on the element. Lead the flexible hose through the left-hand notch in the cover plate. Insert the earthing plug of the shower WC through the right-hand opening of the cover plate and into the earthing socket. cover plate 14 from 15...

  • Page 15: Mounting Wc Ceramic

    Mount shower WC ceramic according to the manufacturer's instruc- tions. Use the connecting material supplied for the water and elec- trical connection. Open the water supply pipe to the Viega Eco Plus Universal shower WC element. Open the ball valve of the shower WC / shower WC top.
